Initial setup

1. Mount the Edge Controller on the tabletop stand (optional), and then connect the required cables, a USB
keyboard, and a USB mouse.
2. Press the power button for 1 second to turn on the Edge Controller.
For Edge Controllers with Microsoft Windows:
Complete the Microsoft Windows setup by following the prompts. Consult your network administrator for help
with configuring network and system settings.
For Edge Controllers with no OS installed:
Note
Edge Controllers with no preinstalled OS accept the installation of Oracle
Linux or other Linux distributions.
a. After powering on the Edge Controller, press ESC on a connected keyboard during device bootup to enter
BIOS setup utility.
b. Click Setup Utility, click Security (left side), click Secure Boot, and then disable Secure Boot if installing
Linux.
c. Select Boot (left side), scroll down and select USB Boot, and then enable USB Boot.
Press F10 to save changes and exit BIOS.
d.
e. Connect your bootable Linux USB drive.
Power cycle the Edge Controller to reboot, press ESC to enter BIOS, select Boot Manager, and then select
f.
your bootable Linux USB drive.
g. Power cycle the Edge Controller to boot into the Linux USB setup.

Powering on and off

To power off the Edge Controller, use the Shut Down function provided in the operating system software or press and
hold the power button for 1 second.

System recovery (Microsoft Windows Edge Controllers only)

Performing a system recovery removes all data and the current operating system, and then restores the Edge
Controller to its out-of-box state.
1. Power on the Edge Controller and wait for a blue screen that briefly appears prior to the OS loading.
2. Select the OS Restore option and follow the prompts.
