C4-104.ULTRA
User Manual | 3541
1
© Sealevel Systems, Inc.
3541 Manual | SL9150 12/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C4-104.ULTRA and is the answer not in the manual?

Questions and answers

Summary of Contents for SeaLevel C4-104.ULTRA

  • Page 1 C4-104.ULTRA User Manual | 3541 © Sealevel Systems, Inc. 3541 Manual | SL9150 12/2022...
  • Page 2: Table Of Contents

    APPENDIX C – ELECTRICAL INTERFACE ......................15 APPENDIX D – ASYNCHRONOUS COMMUNICATIONS .................. 16 APPENDIX E – SILK SCREEN ..........................17 APPENDIX F – COMPLIANCE NOTICES ......................18 WARRANTY ................................ 19 ....................................© Sealevel Systems, Inc. 3541 Manual | SL9150 12/2022...
  • Page 3: Introduction

    RS-485 is optimized for ‘Multi-Drop’ or ‘Party-line’ operations selecting data from multiple peripherals (as many as 31 devices can be connected on an RS-485 bus). The C4-104.ULTRA is optimized for RS-485 with automatic driver enable, and automatic suppression of RS-485 ‘Echo’ as options, further simplifying integration.
  • Page 4: Before You Get Started

    Before You Get Started What’s Included The C4-104.ULTRA is shipped with the following items. If any of these items is missing or damaged, contact the supplier. C4-104.ULTRA Serial I/O Adapter Advisory Conventions Warning The highest level of importance used to stress a condition where damage could result to the product, or the user could suffer serious injury.
  • Page 5: Card Setup

    Card Setup The C4-104.ULTRA contains two DIP-Switches and a jumper strap for each port, which must be set for proper operation. Address Selection Each port on the C4-104.ULTRA occupies sixteen consecutive I/O locations. A DIP-switch is used to set the base address for these locations. The following table shows the addressing options available. If different address options are required, please contact Sealevel Systems Technical Support about a custom PAL option.
  • Page 6 Header E1 (IRQ Selection) The C4-104.ULTRA has a single interrupt selection jumper for all four of the ports, which should be set prior to use, if an interrupt is required by your application software. Consult the user manual for the application software being used to determine the proper setting.
  • Page 7 921.6K bps Programmable Features Each of the ports on the C4-104.ULTRA can be individually configured as an RS-232, RS-422, or RS-485 interface. This is a software selectable feature. Electrical Interface selection (RS-232/422/485), RS- 422/485 termination, and RS-485 ‘Echo’ control are selected via the ‘Control’ port (Base + 8). If the Sealevel Software Windows drivers are used, this is accomplished as a function of the Device Manager.
  • Page 8 Typically, each end of the RS-485 bus must have line-terminating resistors (RS-422 terminates at the receive end only). One of the unique features of the C4-104.ULTRA is its ability to select this termination via a control word in the control port. It is completely software selectable, thus reducing the complexity of cabling typically found in RS-485 implementations.
  • Page 9: Installation

    Only users running Windows 7 or newer should utilize these instructions for accessing and installing the appropriate driver via Sealevel’s website. If you are utilizing an operating system prior to Windows 7, please contact Sealevel by calling 864.843.4343 or emailing support@sealevel.com...
  • Page 10: Physical Installation

    For additional software support, including QNX, please call Sealevel Systems’ Technical Support, (864) 843- 4343. Our technical support is free and available from 8:00 AM - 5:00 PM Eastern Time, Monday through Friday. For email support contact: support@sealevel.com.
  • Page 11: Technical Description

    Technical Description The C4-104.ULTRA provides 4 RS-232/422/485 software programmable ports from a single PC-104 adapter. The C4-104.ULTRA utilizes the 16C864 UART. This chip features programmable baud rates, data format, interrupt control and industry leading 128-byte transmit and receive FIFOs. Connector Pin-outs...
  • Page 12: Specifications

    10 to 90% R.H. Non-Condensing Manufacturing All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel. Power Consumption...
  • Page 13: Appendix A - Troubleshooting

    IRQs, many other adapters (i.e. SCSI adapters & on-board serial ports) do not. Make sure the Sealevel Systems adapter is using a unique IRQ The IRQ is typically selected via an on-board header block. Refer to the section on Card Setup for help in choosing an I/O address and IRQ.
  • Page 14: Appendix B - How To Get Assistance

    If possible, please have the adapter installed in a computer ready to run diagnostics. 3. Sealevel Systems provides an FAQ section on its web site. Please refer to this to answer many common questions. This section can be found at http://www.sealevel.com/faq.asp.
  • Page 15: Appendix C - Electrical Interface

    0 (space) and -12 volts (-3 to -10 volts) denotes a binary 1 (mark). The RS-232 and the EIA/TIA-574 specification defines two type of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface. RS-422 The RS-422 specification defines the electrical characteristics of balanced voltage digital interface circuits.
  • Page 16: Appendix D - Asynchronous Communications

    The communication parameters are baud rate, parity, number of data bits per character, and stop bits (i.e. 9600,N,8,1 © Sealevel Systems, Inc. 3541 Manual | SL9150 12/2022...
  • Page 17: Appendix E - Silk Screen

    Appendix E – Silk Screen © Sealevel Systems, Inc. 3541 Manual | SL9150 12/2022...
  • Page 18: Appendix F - Compliance Notices

    Always use cabling provided with this product if possible. If no cable is provided or if an alternate cable is required, use high quality shielded cabling to maintain compliance with FCC/EMC directives. © Sealevel Systems, Inc. 3541 Manual | SL9150 12/2022...
  • Page 19: Warranty

    Sealevel's commitment to providing the best I/O solutions is reflected in the Lifetime Warranty that is standard on all Sealevel manufactured I/O products. We are able to offer this warranty due to our control of manufacturing quality and the historically high reliability of our products in the field. Sealevel products are designed and manufactured at its Liberty, South Carolina facility, allowing direct control over product development, production, burn-in and testing.
