- Page 1 ™ COMM+232/EX USER’S MANUAL Part Number 3085 Sealevel Systems, Inc Phone: (864) 843-4343 P.O. Box 830 Fax: (864) 843-3067 Liberty, SC 29657 USA www.sealevel.com...
-
Page 2: Table Of Contents
Contents ™ COMM+232/EX ..............1 USER’S MANUAL .................1 Part Number 3085 ..............1 ................ 1 NTRODUCTION ..................1 VERVIEW ’ ................1 NCLUDED ............1 ACTORY EFAULT ETTINGS ................2 ETUP ..............2 DDRESS ELECTION ..............3 NABLE ISABLE IRQ S ................3 ELECTION .................4 NTERRUPT ODES ................. - Page 3 Figure 3 - Header E1 and E2, IRQ Selection .......... 3 Figure 4 - Header E3 and E4, Interrupt Mode Selection....... 4 Figure 5 - Asynchronous Communications Bit Diagram ..... 13 © Sealevel Systems, Inc. SL9109 Revision 7/2006 Sealevel Systems, Incorporated. All rights reserved.
-
Page 4: Comm+232/Ex
RS-232 interface for modems, printers, plotters, or any other RS-232 device. What’s Included The COMM+232/EX is shipped with the following items. If any of these items are missing or damaged, contact the supplier. • COMM+232/EX Serial I/O Adapter •... -
Page 5: Card Setup
Card Setup Card Setup The COMM+232/EX contains several jumper straps which must be set for proper operation. Address Selection Each port on the COMM+232/EX occupies eight consecutive I/O locations. A DIP-switch is used to set the base address for these locations. -
Page 6: Port Enable / Disable
Card Setup Port Enable / Disable Each port on the COMM+232/EX can be enabled or disabled with switch position 8 on the DIP-switch. The port is enabled with the switch ‘On’ or ‘Closed’ and disabled when ‘Off’ or ‘Open’. If any port is disabled, be sure to disable the interrupt request for that port by removing the IRQ jumper. -
Page 7: Interrupt Modes
If using any Windows operating system with this interface, the single interrupt per port mode should be selected. Some DOS applications will allow the sharing of interrupts. Sealevel Systems COMM+232/EX Page 4... -
Page 8: Installation
Installation Installation The COMM+232/EX can be installed in any of the PC expansion slots, but to access the ‘AT’ or (E)ISA IRQs (10 - 15) it must be installed in one of the 16 bit slots. The COMM+232/EX contains several jumper straps for each port which must be set for proper operation prior to installing the adapter into the computer. -
Page 9: Technical Description
Technical Description Technical Description The COMM+232/EX adapter utilizes the 16550 UART chip. This chip features programmable baud rate, data format, interrupt control and has a 16 byte transmit and receive FIFO. Features • Addressable as COM1: - COM4: or any other I/O address up to 3FF Hex. -
Page 10: Connector Pin Assignments
The most common way to do this is connect RTS to CTS and RI. Also, connect DCD to DTR and DSR. Terminating these pins, if not used, will help insure you get the best performance from your adapter. Sealevel Systems COMM+232/EX Page 7... -
Page 11: Specifications
IPC 610-A Class-III standards are adhered to with a 0.1 visual A.Q.L. and 100% Functional Testing. • All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel. -
Page 12: Appendixa - Troubleshooting
4. Make sure the Sealevel Systems adapter is securely installed in a motherboard slot. 5. Use the supplied diskette and User Manual to verify that the Sealevel Systems adapter is configured correctly. The supplied diskette contains a diagnostic program ‘SSD’ that will verify if an adapter is configured properly. - Page 13 2E8-2EF is typically reserved for COM4: Please refer to your included diskette for any post production manual updates and application specific information. 8. Always use the Sealevel Systems diagnostic software when Troubleshooting a problem. This will eliminate the software issue from the equation.
-
Page 14: Appendixb - How T O Get Assistance
Please refer to this to answer many common questions. This section can be found at http://www.sealevel.com/faq.htm 4. Sealevel Systems maintains a Home page on the Internet. Our home page address is www.sealevel.com. The latest software updates, and newest manuals are available via our FTP site that can be accessed from our home page. -
Page 15: Appendixc - Electrical Interface
(ground) to determine binary logic states. The RS-232 and the EIA/TIA- 574 specification define two types of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The COMM+232/EX is a DTE device. Sealevel Systems COMM+232/EX Page 12... -
Page 16: Appendixd - Asynchronous Communications
The data rate and communication parameters for asynchronous communications have to be the same at both the transmitting and receiving ends. The communication parameters are baud rate, parity, number of data bits character, stop bits (i.e. 9600,N,8,1). Sealevel Systems COMM+232/EX Page 13... -
Page 17: Appendixe - Silk -Screen
Appendix E - Silk-Screen Appendix E - Silk-Screen 4.2" 5.0" 3.9" Sealevel Systems COMM+232/EX Page 14... -
Page 18: Appendixf - Schematic
Appendix F - Schematic Appendix F - Schematic Sealevel Systems COMM+232/EX Page 15... -
Page 19: Appendixg - Compliance Notices
Always use cabling provided with this product if possible. If no cable is provided or if an alternate cable is required, use high quality shielded cabling to maintain compliance with FCC/EMC directives. Sealevel Systems COMM+232/EX Page 16... -
Page 20: Warranty
Sealevel Systems assumes no liability for any damages, lost profits, lost savings or any other incidental or consequential damage resulting from the use, misuse of, or inability to use this product. Sealevel Systems will not be liable for any claim made by any other related party.
