  • Page 1 AQ 12 Enclosure Operating Manual www.peavey.com...
  • Page 2 FCC CAUTION: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 3 * Pole mount molded-in for 1 3/8” diameter poles Applications The Peavey AQ™12 has a variety of applications such as sound reinforcement, public address, side fill system, karaoke or musical playback. A typical signal source for the line-Gain inputs of the AQ™12 would be a sound reinforcement mixing console (mixer) or the output from a CD player, MP3 player or tape deck.
  • Page 4 enable the speaker system to provide an accurate and neutral sound for any type of music. The DSP processing uses 56 bit double-precision to insure accurate and transparent sound processing, and the input/output sections use a 48 kHz sam- pling rate at 24 bits for maximum fidelity. Low-jitter clocking and professional grade components insure the sound quality is superb.

  • Page 5: Rear Panel

    MP3 player or tape deck. The high-pass filtered signal from the XS™12 Sub would then be sent to a full-range powered speaker system, easing the burden of deep bass from this speaker system. Rear Panel REAR PANEL BOTTOM VOLTAGE SELECTOR SWITCH (1) The AQ™12 has a voltage selector switch to allow switching between an input power voltage of 120VAC to a _ PAGE _1_ range from 220VAC to 240VAC, all at either 50 or 60 cycles per second (Hz).

  • Page 6: On/Off Switch

    switch (3) activated to turn on the powered AQ™12 speaker system. IEC POWER CORD CONNECTION (2) This receptacle is for the IEC line cord (normally supplied with the correct pins and wiring for your locale) that provides AC power to the unit. It is very important that you ensure the PVs 12 Sub has the proper AC line volt- age supplied.

  • Page 7: Mic/Line Switch

    position. The ON position is with the top side of the switch pushed “in” or nearly flush with the rear panel. TOP OF REAR PANEL - OPERATING CONTROLS, INPUTS & OUTPUTS Rear Panel AQ12 LEVEL (4) LEVEL (4) Controls the gain or output level of the input signal from the input jack (6). It is used to directly set the system Controls the gain or output level of the input signal from the input jack (6).

  • Page 8: Power Led

    BT LEVEL (11) Controls the gain or output level of the input signal from the Bluetooth® signal feed. It is used to directly set the system output level for a given Bluetooth® input signal. SIG LED (12) Illuminates green when a signal source is present at either the analog input jack (6), or the Bluetooth® signal source.
  • Page 9 Cautions The unit must be disconnected from the AC power source before any work is done on it. Refer all servicing to qualified service personnel. The back plate can become hot to the touch. Do not block or cover the fan or the exhaust louvers from ventila- tion.
  • Page 10 When installing or de-installing the speaker on the stand, it is a good practice to have a helper if possible, it can be hard to “thread the needle” and mate the stand cup to the stand pole while holding the AQ™12 speaker system at arm’s length.
  • Page 11 1. Press mode button (10) on the back of the speaker to make the speaker discoverable. The pairing LED should start blinking. 2. Go to your devices Bluetooth® screen and select the available Peavey speaker. Once paired, the pairing LED should light continuously.
  • Page 12 Disconnecting AC Power to the AQ™12 We recommend that the Power switch (3) be used to turn the unit off first, and then the AC power cord can be removed, this minimizes stress to the power amplifiers and the transducers from turn-off transients. The pow- er switch has an arc suppression capacitor to help during turn-off, and tends to make a clean disconnect from the AC power, while the power cord IEC connector can make intermittent contact before finally becoming fully disconnected, e.g., as when wiggling the cord.

  • Page 13: Troubleshooting

    If the AQ™12 has been subjected to direct sunlight or excessive heat, the built-in thermal protection may have been triggered. If so, turn off the AQ™12 and let it cool for a sufficient amount of time. If there is still no output, contact your authorized Peavey dealer or the Peavey International Service Center. Hum or Buzz If the AQ™12 is producing a hum or buzz, this can be AC outlet related.
  • Page 14 The system shall utilize a 12” heavy-duty woofer and a Peavey® DX™14 1.4” titanium diaphragm dynamic compression driver. The nominal radiation pattern shall be 110° in the horizontal plane, and 80° in the vertical plane. Axis of the vertical main polar lobe is angled down 10 degrees, resulting in the angular pattern with respect to straight ahead being +30, -50 degrees.
  • Page 15 34 lbs. Power requirements shall be: 200 Watts nominal, 120 VAC, 50/60 Hz Domestic and 220- 240 VAC, 50/60 Hz (Export). The loudspeaker system shall be called a Peavey® AQ™12 * Before DSP compression and limiting engages...
  • Page 16 Specifications Frequency Response: 68 Hz to 19 kHz, +/- 6 dB, anechoic environment Usable Low Frequency limit (-10 dB point anechoic): 55 Hz Nominal sensitivity (1W @1M, swept sine input in anechoic environment): 95 dB (average) Maximum Sound Pressure Gain (1 meter): 125 dB SPL peak with music Radiation Angle measured at -6 dB point of polar response: Nominal: 110 degrees horizontal X 80 degrees vertical...
  • Page 17 Nominal Amplifier Frequency Response: +1, -3 dB from 20 Hz to 20 kHz Hum and Noise: Greater than 90 dB below rated power THD and IM: Typically less than 0.7 % Power requirements of Peavey AQ™12 System: Nominal 200 Watts, 120 VAC 60 Hz...
  • Page 20 Warranty registration and information for U.S. customers available online at www.peavey.com/warranty or use the QR tag below Features and speci cations subject to change without notice. Peavey Electronics Corporation 5022 Hartley Peavey Drive Meridian, MS 39305 (601) 483-5365 FAX (601) 486-1278 Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005...
