Peavey SP 3G Specification Sheet

Sound reinforcement enclosure with sound guard hf protection system
Hide thumbs


Advertisement

Quick Links

SPECS
P E A V E Y
SP
3G
Sound Reinforcement
Enclosure with
Sound Guard
HF
Protection System

SPECIFICATIONS

Frequency Response, 1 Meter
On-Axis, Swept-Sine in Anechoic
Environment:
54 Hz to 17 kHz
Low-Frequency Cut-Off (-3 dB point):
54 Hz
Usable Low-Frequency Limit
(-10 dB point):
47 Hz
Power Handling:
Full-Range:
350 W continuous (52.9V RMS)
700 W program
1,400 W peak
Bi-amp Low:
350 W continuous (52.9 V RMS)
700 W program
1,400 W peak
Bi-amp High:
150 W continuous (34.6 V RMS)
300 W program
600 W peak
Sound Pressure Level, 1 Watt, 1
Meter in Anechoic Environment:
Full-Range:
99 dB (2.8 V)
Bi-amp Low:
100 dB (2.8 V)
Bi-amp High:
99 dB (2.8 V)
Maximum Sound Pressure Level
(1 meter):
Full-Range:
125 dB continuous
131 dB peak
Bi-amp Low:
126 dB continuous
132 dB peak
Bi-amp High:
120 dB continuous
127 dB peak
Radiation Angle Measured at -6 dB
Point of Polar Response:
500 Hz to 1.6 kHz:
Horizontal: 122
-15
Vertical:
152
-38
E L E C T R O N I C S
1.6 kHz to 5 kHz:
Horizontal: 79
21
Vertical:
83
22
5 kHz to 16 kHz:
Horizontal: 87
10
Vertical:
45
4
Directivity Factor, Q (Mean):
8
4.3
Directivity Index, Di (Mean):
8.3 dB
2.8 dB
Transducer Complement:
1505-8 KADT Black Widow
6.5" Pro mid-range driver
22XT compression driver
Box Tuning Frequency:
58 Hz
Crossover Frequency (internal
passive):
800 Hz
Minimum Recommended Active
Crossover Frequency and Slope for
Bi-amping:
800 Hz at 18 dB/octave
Time Offset:
0.14 mS (delay Lows)
Impedance (Z):
Full-Range Nominal:
Full-Range Minimum:
Lows Nominal:
Highs Nominal:
Input Connections:
Two paralleled 1/4" phone jacks for
full-range
One 1/4" phone jack for bi-amp low
One 1/4" phone jack for high and mid bi-
amp
Enclosure Materials & Finish:
®
woofer
3/4" plywood enclosure covered with black
carpet and protective polymer corners
Expanded metal grille to protect the mid
and low drivers
Mounting Provisions:
One SA-1 stand mount on bottom of
enclosure.
Dimensions (H x W x D):
33.50" x 21.50" x 22.50"
(85.1 cm x 54.6 cm x 57.1 cm)
Rear width 14.25" (36.1 cm)
8
5.3
8
8
®
