3.2 Installing and removing from DIN rail

The IXrouter3 can be easily installed on a standard DIN rail. (1) Hang the device on the rail and
(2) push the unit down until you feel a click. To remove the unit, (A) pull/rotate the device up and
(B) lift off the rail.
Figure 4: DIN-rail installation

3.3 Installing a SIM card

The SIM card slot suits a Full-Size SIM card (size 2FF).
To insert, push the SIM card into the slot until you feel a click.
This is approximately when the card is fully submerged 1 mm
inside the device. Release the card and the card will stay in the
device. The side of the SIM card where you see a golden colored chip should be aligned with the
outside of the enclosure as depicted on the router and in the figure on the right.
To remove, push the SIM card firmly into the slot until you hear a click. Releasing will cause the
SIM card to partially eject, allowing you to easily take out the card.
10
