BendPak HD-7PXW Service Manual

Four post lift

Hide thumbs Also See for HD-7PXW:

Installation and operation manual (56 pages)

Installation and operation manual (68 pages)

page of 32

/ 32
Bookmarks

Quick Links

Download this manual

Service Manual

SERVICE PARTS & DIAGRAMS

BENDPAK

HD-7PXW

PRODUCT SKU

5175516

DRAWING Nº

5260514

Need help?

Do you have a question about the HD-7PXW and is the answer not in the manual?

Questions and answers

Summary of Contents for BendPak HD-7PXW

Page 1 Bend Pak product. It provides comprehensive information on identifying serviceable parts and components and assists in troubleshooting problems and performing assembly /disassembly procedures. BendPak, Inc. Corporate Office Customer Service Desk / Warranty Parts Orders Domestic Sales & Service International Sales &...
Page 2 5260514 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY SEE COLORS & GRAPHICS FOR LABEL PLACEMENT REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:40 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 3 3528.0mm DRIVE THRU 4.090in 4.764in 103.9mm 121.0mm 157.874in FRONT VIEW 145.315in 4010.0mm 3691.0mm 121.881in 3095.8mm 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: HD-7PXW PRODUCTION LIFT VER E (CE CERT) SIZE DWG. NO. 5260514 SCALE: 1:50 SHEET 2 OF 3...
Page 4 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY THREAD M16 HARDWARE ONTO LADDER BOLTS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:60 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 5 5215171 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5245386 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT ASSEMBLE ITEMS AS SHOWN SCALE: 1:25 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 6 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: HD-7PX/7500 POWER SIDE RAMP ASSEMBLY SIZE DWG. NO. 5215171 SCALE: 1:10 SHEET 2 OF 2...
Page 7 5216155 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5245384 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 8 5216157 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5245384 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 9 PROPRIETARY AND CONFIDENTIAL HOSES AND CABLES IN REPRESENTATIONAL FORM THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY (*) LENGTH FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:25 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 10 PROPRIETARY AND CONFIDENTIAL REFER TO MODEL FOR ADDITIONAL INFORMATION THE INFORMATION CONTAINED IN THIS DRAWING IS 5250166 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING SCALE: 1:45 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 11 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5250335 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 12 PROPRIETARY AND CONFIDENTIAL REFER TO MODEL FOR ADDITIONAL INFORMATION THE INFORMATION CONTAINED IN THIS DRAWING IS 5215170 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 13 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5245382 5245395 THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 14 SHOWN IN REPRESENTATIONAL FORM ONLY THE INFORMATION CONTAINED IN THIS DRAWING IS 5250166 5250342 THE SOLE PROPERTY OF BENDPAK INC. ANY (*)LENGTH FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 15: Additional Contact Information
Tel: +86 534-5421821 No. 7, Taishan Rd., Industrial Park, Ningjin County, Shandong, China 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # AUTHORIZED COMPONENT PROVIDER 1) Ningjin Hydraulic Hose 5570129 +86 534-5421821 OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
Page 16 PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 5250341 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250342 (*)ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 17 PROPRIETARY AND CONFIDENTIAL ITEM 1 QTY FOR REFERENCE ONLY THE INFORMATION CONTAINED IN THIS DRAWING IS 5250342 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THREAD 5535358 WITH 5545342 ONTO CABLES FOR SHIPMENT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 18 PROPRIETARY AND CONFIDENTIAL ITEM 1 QTY FOR REFERENCE ONLY THE INFORMATION CONTAINED IN THIS DRAWING IS 5250342 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THREAD 5535358 WITH 5545342 ONTO CABLES FOR SHIPMENT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 19 PROPRIETARY AND CONFIDENTIAL ITEM 1 QTY FOR REFERENCE ONLY THE INFORMATION CONTAINED IN THIS DRAWING IS 5250342 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THREAD 5535358 WITH 5545342 ONTO CABLES FOR SHIPMENT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 20 PROPRIETARY AND CONFIDENTIAL ITEM 1 QTY FOR REFERENCE ONLY THE INFORMATION CONTAINED IN THIS DRAWING IS 5250342 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THREAD 5535358 WITH 5545342 ONTO CABLES FOR SHIPMENT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 21 5600193 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:30 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 22 5600206 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS 5245386 THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
Page 23 5601822 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:15 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 24 5601823 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:15 THE WRITTEN PERMISSION OF BENDPAK INC.
Page 25 5601138 5620669 BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5601139 5620670 MATERIAL: HR ASTM A36 OR Q235 GB/T 700 REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
Page 26 Application: INSTALLATION MANUAL Detailed Description: Print Settings for BendPak Manuals Unless otherwise specified, use these settings for printing BendPak manuals: Color. Black and white. • Size. A4 (210 to 297 mm), 8.5 by 11 inches (216 to 279 mm), or •...
Page 27 4 Post Lifts Product Decal Positioning DANGER VISUALLY CONFIRM THAT ALL PRIMARY SAFETY LOCKS ARE ENGAGED BEFORE ENTERING WORK AREA. Suspension components on this lift are intended to raise and lower lift; they are NOT load-holding devices. Do not go under an elevated lift until visual confirmation is made that the lift is engaged on its Safety Locks.
Page 28 Contact the participant for information pertaining to certified attachments, accessories, or configuration-modifying components. BendPak lifts are supplied with concrete fasteners meeting the criteria as prescribed by ASTM E488/ E488M-18. Lift buyers are responsible for any special regional, structural, and/or seismic anchoring requirements specified by any other agencies and/or codes such as the Uniform Building Code (UBC) and/or International Building Code (IBC).
Page 29 Print Process: Offset Lithography - 200 line-screen or 300 p.p.i. for digital Lamination: Clear laminate non-glare medium matte over-lami- nate (No gloss) for abrasion, chemical and ultra violet protection. Santa Paula, CA USA Santa Paula, CA USA www.bendpak.com www.bendpak.com MODEL NUMBER MODEL NUMBER DESCRIPTION DESCRIPTION...
Page 30: Does Not Print
4 Post Lifts Product Decal Positioning GRAY DOES NOT PRINT DIE-CUT LINE PN 5906044 DOES NOT PRINT American_Owned_50_Years_Logo.pdf: Trim: 4"W x 3"H Material: 4 Mil. Permanent White Adhesive Vinyl Ink: U.V. protected CMYK 4/C Process Finish: Matte Overlaminate (No Gloss) Print Process: Offset Lithography - 200 line-screen or 300 p.p.i.
Page 31 4 Post Lifts Product Decal Positioning M, E, C SEE NEXT PAGE **FOR ALI APPROVED Back of Post FOR LABEL (Top to Bottom) LIFTS ONLY PLACEMENT HEIGHT G, D, I, J or K, F Side of Post Front of Post (Front &...
Page 32 4 Post Lifts Product Decal Positioning Views of Powerside Post BACK OF SIDE OF FRONT OF POST POST POST CALIFORNIA PROPOSITION 65 WARNING WARNING! This product can expose you to chemicals including styrene and vinyl chloride which are on the list of over 900 chemicals identiﬁed by the State of California to cause cancer, birth defects or reproductive harm.
