Loose Parts
Use the chart below to verify that all parts have been shipped. Part numbers not shown are available on the dealer
extranet.
Dealer Pack
Part #
323-7
98-5975
3290-357
103-3013
—
103-2106
1-603511
Literature Pack
Part #
—
—
—
—
Uncrate the Unit
Remove the tractor and the mower deck from their
crates.
Checking Tire Pressure
1. Check the tire pressure in the drive tires. Proper
inflation for drive tires is 12-16 psi (83-110 kPa).
2. Adjust the tire pressure within 12-16 psi (83-110
kPa) range to make the tire circumferences match as
closely as possible.
3. For FMD Deck Serial Nos. 599,999 and lower:
Check the tire pressure in the pneumatic front caster
tires. Adjust the tire pressure to 16 psi (110 kPa).
For FMD Deck Serial Nos. 600,000 and higher:
The front caster tires are semi-pneumatic. No
adjustment is necessary.
© 2008—Exmark Mfg. Co., Inc.
P.O. Box 808
Beatrice, NE 68310
Description
Screw, Hex 3/8-16 x 1 1/4 inch
Washer, Spring Disc
Nut, Whizlock 3/8-16 inch
Decal, Turf Tracer
Warranty Registration Reminder
Key, Exmark Logo
Key, Standard
Description
Manual, Operator's
Manual, Parts
Sheet, Belt Installation
Manual, Engine Operators
Qty.
8
Installing the mower deck to the
8
tractor.
8
Installing the Turf Tracer decal on the
1
belt shield.
Fill out the online warranty registration
form and place keys into literature
1
pack.
1
Qty.
1
Read before operating the machine.
1
1
For units with Kawasaki engines–Read
1
before operating the machine.
Installing the Mower Deck
1. Locate the drive wheel release valves on the rear
corner of the hydrostatic pumps.
2. With a 5/8 inch wrench, turn both valves one turn
counterclockwise to release the drive system.
3. Roll the tractor to the mower deck assembly and
allow the tractor assembly to tip backward until the
rear of the engine deck contacts the ground.
4. Carefully remove the two hairpins and spacers from
the front deck support pins and lower the front of
the deck to the ground.
5. Carefully remove the two hairpins from the rear deck
support pins and lower the rear of the deck to the
ground. See Figure 1.
6. Install the mower deck support frame to tractor
engine deck and secure using eight 3/8-16 x 1 1/4
TURF TRACER
Setup Instructions
For Serial Nos. 790,000 & Higher
Use
Use
Part No. 4500-363 Rev. A
Printed in the USA
All Rights Reserved
®
