H3C MSR 5600 Routers Installation Quick Start (For MSR5620)-6PW103
H3C MSR 5600路由器 快速安装指南(For MSR5620)-6PW103
Tool list 工具参考
The installation tools are not provided with the router. Prepare them yourself.
路由器不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Flathead screwdriver
Phillips screwdriver
一字螺丝刀
十字螺丝刀
Diagonal pliers
Blow dryer
斜口钳
热吹风
Installation accessories 安装附件介绍
Grounding cable
Load-bearing screw
地线
承重螺钉
Front mounting
Cage nut
brackets
(user supplied)
前挂耳
浮动螺母(用户自备)
!
Wear an ESD wrist strap, and make sure it makes good skin contact and is reliably
grounded.操作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认防静
电腕带已经良好接地。
Needle-nose pliers
Wire-stripping pliers
尖嘴钳
剥线钳
ESD wrist strap
Network cable tester
防静电腕带
测线仪
M4 screw
Rear mounting brackets
M4 螺钉
后挂耳
M6 screw
Removable cable tie
(user supplied)
(user supplied)
M6 螺钉(用户自备)
可拆卸式扎带(用户自备)
Mounting the router in a rack 安装路由器到机柜
Attach cage nuts and rear mounting brackets to the rack. 安装浮动螺母及后挂耳。
Multimeter
万用表
Marker
记号笔
Determine and mark the cage nut installation positions on the rack for attaching the front
mounting brackets.确定前挂耳浮动螺母安装孔位，用记号笔标记。
BOM: 3104A0HG
