H3C MSR 5600 Installation, Quick Start

H3C MSR 5600 Routers Installation Quick Start (For MSR 56-60[80])-6PW110
H3C MSR 5600路由器 快速安装指南(For MSR 56-60[80])-6PW110
Tool list 工具参考
The installation tools are not provided with the router. Prepare them yourself.
路由器不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Flathead screwdriver Phillips screwdriver Needle-nose pliers
一字螺丝刀 十字螺丝刀 尖嘴钳
OFF
Diagonal pliers Heat gun ESD wrist strap
斜口钳 热吹风 防静电腕带
Installation accessories 安装附件介绍
Grounding cable M6 screw Cage nut
(provided) (user supplied) (user supplied)
地线(标配) M6机柜螺钉(用户自备) 浮动螺母(用户自备)
Mounting brackets for Mounting brackets for Air filter (optional)
an MSR 56-60 router an MSR 56-80 router 防尘网(选配)
(provided) (provided)
MSR56-60挂耳(标配) MSR56-80挂耳 (标配)
Wire-stripping pliers Multimeter
剥线钳 万用表
1
1
2
2 3
3
4
4
5
5
6 6
7
7
8
8 G
G
Network cable tester Marker
测线仪 记号笔
M4 countersunk- M3 countersunk-
head screw head screw
(provided) (optional)
M4沉头螺钉(标配) M3沉头螺钉(选配)
Removable cable tie
(user supplied)
可拆卸式扎带
(用户自备)
BOM: 3104A0C9
Wear an ESD wrist strap, and make sure the wrist strap makes good skin contact
and is reliably grounded.
操作者需佩戴防静电腕带，确保防静电腕带与皮肤良好接触，并确认防静电腕带已经良好接地。
Mounting the router on a workbench 安装路由器到工作台
Mount the router on a workbench
将路由器安装到工作台
Installing an air filter 安装防尘网
Air filters are optional components. Skip this step if you are not to install an air filter.
防尘网为选装配件，无需使用该配件的用户请跳过本步骤。
