Mobile All-In-One Livestream Multi-Mount
Floor Stand
Instruction Manual
SKU: STAND-LIVE1M
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-live1m
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-LIVE1M and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-LIVE1M

  • Page 1 Mobile All-In-One Livestream Multi-Mount Floor Stand Instruction Manual SKU: STAND-LIVE1M Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-live1m GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 Connect Legs (E) to Base (G) using M6x25mm Screws (S-B) and 5mm Allen Wrench (T-B). Attach Casters (O) and Locking Casters (P) to Legs (E). Secure assembled base to Adjustable Pole (A) using M6x20mm Screws (S-A) and 4mm Allen Wrench (T-A).
  • Page 4 STEP 2 Slide Cable Clip x2 (H), Locking Pole Ring x4 (Q), Lower Arm x2 (I), and Dual Connector (K) onto Adjustable Pole (A) following the order shown below. Tighten set screw of Locking Pole Ring (Q) using 4mm Allen Wrench (T-A). Height Adjustment Twise the Height Adjuster (A1) on Pole (A) to raise or lower the Pole.
  • Page 5 STEP 3 Connect Upper Arm (J) to right side Lower Arm (I), then install VESA Plate (F) to Upper Arm (J). Secure by tightening set screws using 4mm Allen Wrench (T-A). STEP 4 Attach Upper Arm (J) to left side Lower Arm (I), and secure by tightening set screws using 4mm Allen Wrench (T-A).
  • Page 6 STEP 5 Connect Upper Arm (J) to Dual Connector (K), then connect a second Upper Arm (J), as shown below. Install Threaded Connector (S) to Upper Arm (J).Secure by tightening set screws using 4mm Allen Wrench (T-A). STEP 6 Screw Ball Head (T) onto Threaded Connector (S), then screw Ring Light (B) onto Connector.
  • Page 7 STEP 7 Connect Mic Boom (C) to remaining mounting hole in Dual Connector (K). Twist Mic Mount (N) onto Mic Boom (C). Optional: Mic Boom (C) can be desk mounted using Mic Boom Clamp (M). If needed, install the 5/8” Adapter, as shown.
  • Page 8 STEP 8 For VESA Plate (F), choose between Monitor or Laptop Holder. Monitor: Attach Screws (M-A or M-B) and M5 Washers (M-C) in the top VESA holes on monitor, using a Phillips screwdriver. Slide onto VESA Plate (F) and attach remaining two Screws (M-A or M-B) and M5 Washers (M-C).
  • Page 9 Optional VESA Plate (F) can be adjusted using 4mm Allen Wrench (T-A) to allow monitor to tilt, turn, and swivel. STEP 9 Twist Ball Head (T) onto Threaded Connector (S), then connect Phone/Tablet Holder (L). NOTE: Ball Head (T) can also be used to mount cameras, and other multi-media devices.
  • Page 10 STEP 10 Remove bottom covers from Lower Arms (I) and Upper Arms (J) by sliding off. Organize cables and slide covers back on.
  • Page 11 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 12 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
