Black All-In-One Livestream Desk Mount
Instruction Manual
SKU: STAND-LIVE2L
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-live2l
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-LIVE2L
Summary of Contents for Vivo STAND-LIVE2L
- Page 1 Black All-In-One Livestream Desk Mount Instruction Manual SKU: STAND-LIVE2L Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-live2l GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. Failure to do so may result in serious injury. 19.8lbs 9.9lbs 2.2lbs 15.4lbs Phillips (9kg) (4.5kg) (1kg) (7kg) Screwdriver LAPTOP CAMERA & LIGHT MONITOR MICROPHONE (per screen) TIPOVER WARNING SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER: •... - Page 4 STEP 2 (Continued) OPTION A: Clamp Installation OPTION B: Grommet Installation For thinner desktops, re-attach Clamp (E2) to Cut Grommet Soft Pad (M) along perforated Clamp Brace (E1) and tighten the bolts using lines, then remove adhesive backing and stick to 4mm Allen Wrench (T-A).
- Page 5 STEP 3 Slide Dual Arm (G) and Mic Arm (I) onto Bottom Pole (B) and tighten using 6mm Allen Wrench (T-B). Use Pole Connector (D) to secure Top Pole (A) to Bottom Pole (B) with M6x10 Screw (S-F) and 4mm Allen Wrench (T-A).
- Page 6 STEP 4 (MONITOR ATTACHMENT) Attach VESA Plate (F) to the back of the monitor using Screws (M-A through M-D) and Washers (M-E). If needed, use Spacers (M-F). Slide VESA Plate (F) onto Dual Arm (G) and secure using VESA Cap (S-J), M3x8 Screws (S-K), and a phillips screwdriver.
- Page 7 STEP 4 (CAMERA MOUNT ATTACHMENT) Attach Camera Adjustment Handles (O) to Camera Mounts (J) using M4x8 Screws (S-G) and a phillips screwdriver. Remove adhesive backing from Mic Soft Pads (K) and stick to Camera Mounts (J). For some cameras, 1/4” to 3/8” Adapters (S-H) maybe required. Slide Camera Mounts (J) onto Single Arms (H) and secure using VESA Thumbscrew (S-C).
- Page 8 STEP 4 (MIC BOOM ATTACHMENT) Option A: For arm mounting, slide Mic Boom (C) onto Mic Arm (I) with D12 Washer (S-I). Insert Mic Thumb Screw (S-A) into Mic Arm (I) to secure into place. Thread Mic Mount (R) onto Mic Boom (C). Option B: For desktop mounting, attach Mic Clamp (L) to to desktop.
- Page 9 STEP 4 (LAPTOP TRAY ATTACHMENT) Place Laptop Mounts (U) underneath each side of Laptop Tray (T), aligning square holes in Laptop Mounts (U) with the edge and long slot on each side of Laptop Tray (T). Insert Laptop Arm Clips (V) through top to secure Laptop Mounts (U).
- Page 10 STEP 5 Adjust tilt joint using 6mm Allen Wrench (T-B). Adjust monitor height by using 6mm Allen Wrench in VESA Caps (S-J).
- Page 11 STEP 6 Insert Arm Cable Clips (Q) under Dual Arm (G) and Single Arms (H). Route cables through Arm Cable Clips (Q) and Pole Cable Clips (P). Store Allen Wrenches (T-A and T-B) in Cable Clips (P). Adjust as desired.
