NGPS – User's Manual
NGPS
High-Stability and High-Precision
New Generation
Power Supply Series
User's Manual
All Rights Reserved
© CAEN ELS s.r.l. & Energy Technology s.r.l.
Rev. 1.10 – November 2022
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NGPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Caen NGPS

Summary of Contents for Caen NGPS

  • Page 1 NGPS – User’s Manual NGPS High-Stability and High-Precision New Generation Power Supply Series User’s Manual All Rights Reserved © CAEN ELS s.r.l. & Energy Technology s.r.l. Rev. 1.10 – November 2022...
  • Page 2 NGPS – User’s Manual This product is & compliant. CAEN ELS s.r.l. Energy Technology s.r.l. via Vetraia, 11 via della Solidarieta’, 2/1 55049 Viareggio (LU) – Italy 40056 Valsamoggia (BO) – Italy Mail: info@caenels.com Mail: power@ocem.com Web: www.caenels.com Web: www.ocem.eu...
  • Page 3 NGPS 150-70E(H) • NGPS-CAX 100-100E • NGPS-CAX 200-40E • NGPS-CAX 200-50E • NGPS-CVF 30-300E And it is also applicable to the basic functions of the following custom NGPS Power Supplies models: • • NGPS 600-15EH ** NGPS-CAI 300-18EH • •...

  • Page 4: Table Of Contents

    NGPS – User’s Manual Table Of Contents INTRODUCTION ....................11 NGPS O ..................11 VERVIEW NGPS ..................14 AT A LANCE .................. 17 ODES OF PERATION Regulation Mode ..................17 Control Mode ................... 17 Update Mode .................... 18 ..............19...
  • Page 5 NGPS – User’s Manual Control Page ..................50 Config Page ..................50 Advanced Page ................. 51 NGPS UTILITIES ..................... 53 MECHANICAL DIMENSIONS ............... 54 TECHNICAL SPECIFICATIONS ..............56...
  • Page 6 NGPS – User’s Manual Document Revisions Document Revision Date Comment February 7 2016 Draft Release February 22 2016 Pre Release Version March 15 2016 Visual PS information added and corrected May 27 2016 Added Safety Information and Installation Chapter 2. Removed...
  • Page 7 Water Pressure drop 1.5 bar Water Flow 1.5 l/min The following symbols are used within this manual or are reported on the NGPS box and along this manual: CAUTION Risk of Electrical Shock Caution: Documentation must be consulted in all cases...
  • Page 8 User. It is strongly recommended to read thoroughly this User's Manual before any kind of operation. CAEN ELS s.r.l. and Energy Technology s.r.l. reserve the right to change partially or entirely the contents of this Manual at any time and without giving any notice.
  • Page 9 NGPS – User’s Manual Disposal of the Product The product must never be dumped in the Municipal Waste. Please check your local regulations for disposal of electronics products.
  • Page 10 • Return the product to the manufacturer for service and repair to ensure that safety features are maintained. • Installation shall be made by Qualified Personnel according to the Electrical Codes and Standards. • Operation of the NGPS units shall be carried out by professional skilled personnel.

  • Page 11: Introduction

    1.1 NGPS Overview High performances, high efficiency, high stability, easiness of configuration and maintenance are the key features of the NGPS power supply series, generated by the joint effort of CAEN ELS and OCEM – Power Electronics. The NGPS is an independent current (or voltage) digitally controlled monopolar power supply module.
  • Page 12 NGPS 200-30E NGPS 200-60E NGPS 300-25E NGPS 300-30E NGPS 400-30E NGPS-CAX 100-100E NGPS-CAX 200-40E NGPS-CAX 200-50E NGPS-CVF 30-300E Table 1a: Standard NGPS models Model Name Current (A) Voltage (V) Max. Power (kW) NGPS 160-30EH NGPS 160-60EH NGPS 200-25EH NGPS 400-30EH...
  • Page 13 480 V (AC) Table 2: NGPS versions The NGPS module is composed of a single 19-inch standard crate. The power unit implements a completely digital control loop, with a Pulse Width Modulation (PWM) generation technique that allows adapting the system to any load condition.

  • Page 14: Ngps At A Glance

    On the front side (Figure 1, no differences between air- and water-cooled units) of the NGPS power supply are placed: a circuit breaker, a colour graphic display with navigation switch for the local control and monitor of the module, three communication sockets (2 SFPs and one Ethernet ports), four status LEDs and one USB device connector.
  • Page 15 Exclusively for water cooled models, on the rear panel are present two plugs to the hydraulic system also (input plug the left one – output plug the right one), highlighted in Figure 3: Water cooled NGPS rear view.
  • Page 16 NGPS – User’s Manual Installation The corresponding mating hydraulic plug (to be plugged into the power units) is the PLCD17006, which is as follows: • Material: Acetal; • Pressure Range: Vacuum to 120 psi, 8.3 bar; • Color: White; •...

  • Page 17: Modes Of Operation

    1V. Control Mode The NGPS unit can be controlled in three main different ways, hereafter listed: • LOCAL control: the unit can be controlled directly via the front panel color display and the navigation switch. When the unit is set in LOCAL mode, it is possible to perform readings and monitor the unit from the remote interface also but any setting command is denied;...

  • Page 18: Update Mode

    NGPS – User’s Manual Installation Update Mode The current or voltage setting of the unit can be performed in four different modes: • NORMAL: the update of the set-point (current or voltage, depending on the regulation mode, see Section 1.3.1) is performed as soon as a new set-point is received via the remote, local or fast interfaces;...

  • Page 19: Interlock And Status Signals

    NGPS – User’s Manual Installation 1.4 Interlock and Status Signals The NGPS module has four configurable dry-contact input interlocks and two output status signals that are directly available on the D-Sub 15 Pin Female connector on the rear panel (Figure 4).
  • Page 20 NGPS – User’s Manual Installation WARNING Magnetic Relay Contact ( C-TAP, NO-TAP & NC-TAP) and shall not float Solid State Relay Terminals (Terminal #1 & #2) more than ±60 VDC above/below chassis ground. Interlocks input and return pins shall not float more than ±60 VDC above/below chassis ground.

  • Page 21: Interlock Enable/Disable Mask

    Interlock Identification Name The NGPS also allows associating a name to the interlocks in order to read form the remote interface or to display on the local display the interlock condition name. The intervention names are stored in the field #93 for Interlock #1, in field #95 for Interlock #2, in field #97 for Interlock #3 and in field #99 for Interlock #4.

  • Page 22: Remote Sensing

    Do not connect +S to – or –S to +. The NGPS mounts a voltage-sensing connector on the rear panel that allows using the voltage sensing feature, especially when using the power supply in C.V.
  • Page 23 It is strongly suggested to use twisted cables when using the remote sensing feature in order to minimize possible noise pick-up. The NGPS is shipped with the mating connector for the remote sensing in the factory-default configuration: +S and + pins are shorted as well as –S with –. This configuration performs the remote sensing directly at the output connector of the power unit.
  • Page 24 NGPS – User’s Manual Introduction In order to perform remote sensing at different points – e.g. the load terminals – it would be necessary to connect Pin #1 and Pin #4 as in Figure 7 NGPS Power Cables OUTPUT CONNECTOR...

  • Page 25: Trigger And Analog Control Inputs

    Introduction 1.6 Trigger and Analog Control inputs On the rear side of the NGPS there are two BNC input connectors, as shown in Figure 8, which can be used as trigger and analog control inputs. Figure 8: Trigger and analog input connectors Trigger Input The trigger input accepts TTL (5V) and LVTTL (3.3V) compatible signals and...

  • Page 26: Analog Control Input

    Figure 9: Trigger thresholds Analog Control Input The analog control input allows controlling the NGPS unit almost as an “amplifier”. This input is labelled as “AN CTRL”. This input accepts signals ranging from 0V to +10V and generates an output which is proportional to the input signal: zero output for a 0V input and Full-Scale output for a +10V input.

  • Page 27: Front Panel Indicators

    LED and to turn-on the module output again (only if the fault condition/cause has been removed); • C.C. (blue): if turned on, the NGPS is working in constant-current mode. When off, it is regulating the output voltage (see Section1.3.1).

  • Page 28: Earth Leakage Current

    Earth Fuse An earth fuse is present on the rear side of each NGPS and it is rated at 5 A, 500 V (F5AH500VAC). The blowing of this fuse generates a fault condition of the power unit and the fuse needs to be replaced in order to get rid of the fault condition before resetting the NGPS internal status register.

  • Page 29: Overpower - Ovp

    NGPS 200-50 (i.e. the maximum power supply output voltage is 50V, see Table 1a: Standard NGPS models). By setting a current of 100A to the load, the output voltage would reach a value of 100V, which obviously is not feasible with this model. Indeed, once the power unit supplies 50A to the load, it has already reached the maximum output voltage condition.

  • Page 30: Dc-Link Undervoltage

    NGPS – User’s Manual Introduction The threshold value [°C] can be modified by experienced users. A reset fault operation needs to be executed on the status register of the NGPS before turning the output on again. DC-Link Undervoltage The NGPS is internally composed by a power AC-DC section cascaded with a DC-DC stage.

  • Page 31: Custom Models

    5x20 [mm] rated at 2 A. For the NGPS-AUX models, the single-phase input feeds the circuitry of the power supply dedicated to the control, while the power part is fed via the 3-phase input.
  • Page 32 NGPS – User’s Manual Introduction Figure 14: NGPS-AUX additional single-phase input This connector presents the specifications as hereafter presented. The PUSH-IN connectors mates with standard Semi-Rigid Polyamide (PA) tubing.

  • Page 33: Installation

    (e.g. broken switch or connectors) and that all the panels and the display are not scratched or cracked. Keep all packing material until the inspection has been completed. If a damage is detected, compile the RMA form (available to the CAEN ELS web site).

  • Page 34: Mounting

    NGPS – User’s Manual Introduction 2.3 Mounting The NGPS is a rack-mount device since the unit form factor is designed to be installed in a standard 19-inch cabinet. CAUTION The unit(s) shall be installed assuring that the main circuit breaker on the front panel can be always easily operated by user personnel.

  • Page 35: Ac Input Power Connection

    NGPS – User’s Manual Local Control 2.4 AC Input Power Connection CAUTION Connection of this power supply to an AC power source should be made by electrician or other qualified personnel. Do not exceed the torque specified on input stud terminals (0.8 Nm).
  • Page 36 NGPS – User’s Manual Introduction Recommended Cable Size for Input Connection are listed in : AC cable Table 9 size. Recommended copper Current RMS per phase Input voltage wire size 208 V 34 A 6 mm 400 V 18 A...
  • Page 37 NGPS – User’s Manual Local Control Figure 16: Protective cover mounting Figure 17: AC mains cable fastener...

  • Page 38: Ac Source Requirements

    NGPS – User’s Manual Introduction AC Source Requirements The NGPS power supplies are designed for 208 V AC, 400 V AC or 480 V AC input range depending on the model (see : NGPS versions); accepted input Table 2 frequency is in the range from 47 Hz to 63 Hz. Installation category shall be CAT II, so the maximum voltage impulse on the network mains must be below 2500 V.

  • Page 39: Lug Terminal Connection

    In those cases, a detailed design of the lines shall be prepared by a Qualified Installer according to standards (e.g. IEC 60364-5-52). Voltage ratings of the cable shall be rated for the maximum output voltage of the NGPS power supply.
  • Page 40 After securing both output connections, it is necessary to mount the metallic protective cover, since the power supply delivers high current and/or hazardous voltage (i.e. in case of NGPS with output voltage ratings > 60 V) on these output terminals. Figure 19: Metallic protective cover on the output terminal connections...

  • Page 41: Hydraulic Plug Connection

    Local Control 2.6 Hydraulic Plug Connection In order to properly cool the model, each NGPS needs to be connected to the hydraulic system by mean of the plugs on the rear panel of the module (Figure 3: Water cooled NGPS rear view. Plugs for the). As mentioned in Section 141.2, the corresponding mating hydraulic plug (to be plugged into the power units) is the PLCD17006 and is described in detail.
  • Page 42 (see below), and secondly one module has to be configured as Master and all the others as Slaves. Each step is described below. HARDWARE CONNECTION 1. Each NGPS has to be properly mounted on a 19’’ rack (N.B. do not connect AC main at this point); CAUTION Use a support bar to provide adequate support for the power supply.
  • Page 43 NGPS – User’s Manual Local Control 3. Connect the SFP transceiver modules in daisy-chain mode:...
  • Page 44 Being a daisy-chain, the user can connect the optical cables plugs to SFP plugins in any order. N.B.: use the SFP1 connection on each module. 4. Remove the earth fuse from each NGPS, except one (selected as Master). 5. Connect each module to the AC main.
  • Page 45 ) and select “Advanced”: 2. In the “Advanced” window, select “Parallel”; 3. The NGPS with the earth fuse has to be selected as “Master” and the OFF/ON selection on “ON” and then press “Return” on the right side: 4. The other NGPSs have to be selected as “Slave” and the OFF/ON selection on “ON”...

  • Page 46: Local Control

    The control mode (LOCAL / REMOTE) can be set on the configuration page of the local menu. 3.1 Navigation Switch Each NGPS power supply module is equipped with a Navigation Switch on the front panel of the unit, as shown in Figure 20...

  • Page 47: Display

    Local Control 3.2 Display The colour display on the NGPS power supply unit allows users to visualize information about the power supply status and to control the unit in order to use it locally. User friendly menus and sub-menus can be navigated by means of the navigation switch.

  • Page 48: Home Screen

    NGPS – User’s Manual Local Control Home Screen The NGPS Home Screen ( ) is the first loaded page upon power-up (or Figure 21 power-cycling of the module) and contains information on: Left Side • the NGPS model; • the module IP address;...

  • Page 49: Menu Page

    The Menu Page is reachable by performing any action on the navigation switch when in the Home Screen. The Menu Page gives access to all the local features of the NGPS power supply unit. There are five different options (sub-page/action) that can be selected as shown in...

  • Page 50: Control Page

    The Control Page is reachable by selecting the corresponding rectangle from the Menu Page. The Control Page gives access to the main settings of the NGPS power supply unit. An example of a Control Page visualization is shown in Figure 23...

  • Page 51: Advanced Page

    NGPS – User’s Manual Local Control Advanced Page The Advanced Page is reachable by selecting the corresponding rectangle from the Menu Page. This page allows selecting further sub-pages: Figure 25: Advanced Page • Network Page This page allows to locally set the power supply Ethernet IP address, the Network Mask and the Gateway.
  • Page 52 ▪ Heatsink 2 temp refers to the temperature of the HF transformers. • SFP info Not Applicable for the NGPS. • Parallel It allows to configure the NGPS for parallel operation (see Section 2.8...

  • Page 53: Ngps Utilities

    Two different software are available for operation with the NGPS power supply: Device Manager and Visual PS. Concerning the former, it is a software useful for the detection of the NGPS units connected to the local network, as well as to check and eventually modify their network configuration (as an alternative to the use of the local interface, see Section3.2.3.3).

  • Page 54: Mechanical Dimensions

    – User’s Manual Mechanical Dimensions NGPS 5. Mechanical Dimensions The mechanical dimensions of the air cooled NGPS unit are shown in Figure Figure 30: Air cooled NGPS mechanical drawings...
  • Page 55 NGPS – User’s Manual Technical Specifications The mechanical dimensions of the water cooled NGPS unit are shown in Figure Figure 31: Water cooled NGPS mechanical drawings...

  • Page 56: Technical Specifications

    – User’s Manual Technical Specifications NGPS 6. Technical Specifications The main technical specifications for the NGPS models are hereafter presented: Technical Specifications NGPS : Standard NGPS models Output current range See Table 1a and 1b : Standard NGPS models Output voltage range...
  • Page 57 NGPS – User’s Manual Technical Specifications Technical Specifications NGPS User-configurable "dry" contacts External Interlocks/States Magnetic relay Solid-state relay Modularity Parallel connection (up to 4) Drivers EPICS Point-by-point current waveform User-definable interlock thresholds, active levels and Extra-features timings Firmware remote update (with password) 19”...
