- Page 1 Technical Information Manual Revision n. 5 9 September 2005 MOD. EASY3000/4000 EMBEDDED ASSEMBLY POWER SUPPLY SYSTEM MANUAL REV.5 NPO: 00105/03:A1676A.MUTx/05...
- Page 2 User. It is strongly recommended to read thoroughly the CAEN User's Manual before any kind of operation. CAEN reserves the right to change partially or entirely the contents of this Manual at any time and without giving any notice.
-
Page 3: Table Of Contents
2.3.5 Control signals ............................12 A1676A C ......................12 OMMUNICATION TIMING 2.4.1 Foreword ..............................12 2.4.2 Communication mode ..........................12 2.4.3 Requested parameters present on EASY3000 LV and HV boards ...............13 2.4.4 Timing................................13 2.4.5 Timing examples ............................13 EASY C ......................14 RATE ONFIGURATION 2.5.1 Installation and set up ..........................14 2.5.2... - Page 4 Document type: Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 4.1.1 Injury Precautions ............................25 ................25 AFETY ERMS AND YMBOLS ON THE RODUCT ............................26 NSTALLATION ..........................26 PERATING MODES ....................26 UTPUT CONTROL AND MONITORING ........................26 NTERLOCK OPERATION LIST OF FIGURES .
-
Page 5: Easy3000 Embedded Assembly System
(SY1527 or SY2527) and the remote boards in the EASY3000 crate: its role is to configure the EASY3000 channels as if they belong to the supply unit slot in which the branch controller is located. All the channels of the EASY3000 boards will be considered as channels of the branch controller, thus hugely increasing the number of channels the system can handle. -
Page 6: The Caen Multichannel Power Supply System Overview
The SY1527 system is the fully equipped experiment version of a new line of power supply systems which represent CAEN's latest proposal in the matter of High Voltage and Low Voltage Power Supplying. This system outlines a completely new approach to... -
Page 7: Table 1.2 - Technical Specifications Of The
Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 Power Supply Unit and one board. The system allows also to deal with power supply solutions composed by “branch controllers” (housed in the system main frame) and on- detector “remote boards”... -
Page 8: The Mod. A1676A Branch Controller
EASY3000/4000 crate. It configures the EASY3000/4000 channels as if they belong to the slot in which the branch controller is located: the channels of the EASY3000/4000 boards operate as channels of the A1676A. -
Page 9: A1676A Front Panel
Document type: Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 A1676A Front Panel Mod. V560E Mod. A1676A HVCK SYNC DATA HVCK SYNC HEADER DATA CONNECTOR HVCK SYNC DATA HVCK SYNC DATA HVCK SYNC DATA HVCK SYNC... -
Page 10: A1676A Technical Specifications
The A1676A Branch Controller board can control up to six remote crates through the CANbus protocol (250 kbit/sec). Remote crates controlled by the A1676A can house different sets of EASY3000/4000 boards, then it is necessary to configure the Branch Controller firmware through a set up file containing all the information about number, type and position of the boards in remote crates. -
Page 11: A1676A Front Panel Switches
Document type: Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 HVCKH4 HVCKH0 HVCKH2 HVCKL4 HVCKL0 HVCKL2 SYNCH4 SYNCH0 SYNCH2 SYNCL4 SYNCL0 SYNCL2 DATAH4 DATAH0 DATAH2 DATAL4 DATAL0 DATAL2 RECH4 RECH0 RECH2 RECL4 RECL0 RECL2 RECL3 RECL5... -
Page 12: Control Signals
The A1676A board can handle, via the CANBUS protocol, up to 6 remote crates in parallel (EASY bus). The remote crates, which can be of two different kinds developed so far, EASY3000 and EASY4000, can house respectively up to 23 and 20 nodes (EASY power supply boards, optional Fan Units and A34xx AC/DC Converters). -
Page 13: Requested Parameters Present On Easy3000 Lv And Hv Boards
The parameters request takes place through cycles, from the first channel of the first board until the last channel of the last board in the crate. 2.4.3 Requested parameters present on EASY3000 LV and HV boards It is possible to distinguish between channel 0 parameters and other channel parameters:... -
Page 14: Easy Crate Configuration
Such time does not depend on the number of active EASY bus (from 1 to 6) 2.4.5.2 A3009 For example we consider the A3009 board (which is housed inside the EASY3000 crate); such board (1 Board = 1 Node) has 13 channels. The number of parameters per channel is as follows: ch0 7 parameters ch1..12 6 parameters... -
Page 15: Fig . 2.3 - Easy Rackb
The EASY Rack Builder shows six empty EASY crates, by clicking on the “Crate button” (see the arrow in fig. 2.3) it is possible to choose between EASY3000 and EASY4000 crates (according to the crates connected to the A1676A to be configured). -
Page 16: Fig . 2.4 - Easy Rackb
Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 Fig. 2.4 – EASY Rack Builder with populated racks When the crate configuration is complete, it is necessary to save the file; go to: EASY Rack Configuration > Save as…... -
Page 17: Easy3000 And Easy4000 Crates
3. EASY3000 and EASY4000 crates EASY3000 crate overview The EASY3000 crate is designed to house Power Supply and ADC boards of EASY3000 family; it supports mechanically EASY boards and distributes control signals and power supplies. It is handled by one of six branches of the A1676A – Branch Controller. -
Page 18: Easy 3000 Crate Panel First Issue
Document type: Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 Table 3.1 – EASY 3000 crate connections second issue Name Description J1,J2 48V SERVICE connectors (in parallel); input of 48 V supply for auxiliary low voltages in boards J3..6... -
Page 19: Easy4000 Crate Overview
The EASY4000 crate is designed to house some custom PS boards that do not fit into the EASY3000 crates; it supports mechanically up to 9 PS boards and distributes control signals and power supplies. The crate has ten slots: slot 0 (the leftmost) is available for test purposes, while slot 1..9 are suitable to host PS boards. -
Page 20: A1676A - Easy3000/4000 Crate Connection
There are two different ways for connecting the A1676A Branch controller with up to six EASY3000/4000 crates; the first type of connection uses a 50-wires flat cable between the A1676A and the first crate as well as between the subsequent crates, as shown in... -
Page 21: Fig . 3.4 - Connecting A1676A
Document type: Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 EASY EASY EASY EASY EASY EASY 3000 3000 3000 3000 3000 3000 INPUT INPUT INPUT INPUT INPUT INPUT FLAT 50p FLAT 50p FLAT 50p FLAT 50p... -
Page 22: Fig . 3.5 - Connecting A1676A
Document type: Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 EASY EASY EASY EASY EASY EASY 3000 3000 3000 3000 3000 3000 COM3 COM3 COM3 COM3 COM3 COM3 DB50 A1676A Fig. 3.5 – Connecting A1676A and the crates with split cable The main advantage of this solution is the lower number of wires (9 for crates). -
Page 23: Power Sources
3.3.1 Mod. A3486 AC/DC Converter for Hostile Areas The CAEN Mod. A3486 is a two channel 220/400 Vac – 48 Vdc converter, which allows to integrate into the EASY channels control also the management of the 48 V power supplies. Each channel provides a 2 kW output and can be tracked in order to obtain one 4 kW output. -
Page 24: Mod. A3484 And A3485 Ac/Dc Converters
3.3.2 Mod. A3484 and A3485 AC/DC Converters CAEN can provide 2 types of 48 V power sources (Mod. A3484 and A3485), which allow to integrate into the channels control also the management of the 48 V power supplies. The modules are implemented in a 3U / 19” Euro Rack and have Single (A3484) or Dual (A3485) 48V output. -
Page 25: Safety Information And Installation Requirements
Document type: Title: Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 4. Safety information and installation requirements General safety information This section contains the fundamental safety rules for the installation and operation of the boards. Read thoroughly this section before starting any procedure of installation or operation of the product. -
Page 26: Installation
ON the SY1527 system processor will scan all the slots in the crate to find out where the module is plugged and what kind of module it is. The A1676A must be connected to the EASY3000 remote crates through the control lines. The control connectors are placed on the A1676A front panel and on the EASY3000 front panel. - Page 27 Revision date: Revision: User's Manual (MUT) EASY3000/4000 Embedded Assembly SYstem 01/09/2005 PASSIVE INTERLOCK: it is necessary to short circuit pin 1 (“GND”, the first from left to right) with pin 2 (“K=katode”), and pin 3 (“A=anode”) with pin 4 (“VCC”), or put a 50 Ohm termination between pin 3 and pin 4.
