CA6150 Carbon Monoxide Alarm
QUICK START GUIDE
Display CO Level
Button
Test/Reset/Mute
Button
The Defender CA6150 Carbon Monoxide Alarm is Underwriters Laboratories Tested and
Listed to the ANSI/UL 2034 residential safety standard. The CA6150 also provides
added protection for your health, and enables you to monitor the current and peak CO
levels as low as 10 PPM, and the duration of the peak level, at the touch of a button.
This alarm is not designed to measure compliance with OSHA or commercial standards.
85dB Horn
Mounting Screw
Large Alpha-Numeric LCD
Secure-Lock Mounting Plate
- 1 -
Alarm LED
Power LED
Service LED
OM5-6150-00
2022-02-08
Advertisement
Related Manuals for Defender CA6150
Summary of Contents for Defender CA6150
- Page 1 Button The Defender CA6150 Carbon Monoxide Alarm is Underwriters Laboratories Tested and Listed to the ANSI/UL 2034 residential safety standard. The CA6150 also provides added protection for your health, and enables you to monitor the current and peak CO levels as low as 10 PPM, and the duration of the peak level, at the touch of a button.
-
Page 2: Recommended Location Of Alarms
1. RECOMMENDED LOCATION OF ALARMS CO poisoning can happen anywhere in the building, but because most CO poisoning cases occur while people are sleeping, the best location for the CO alarm is in or near the sleeping area. If there is more than one sleeping area in the dwelling or on a different floor, or if bedroom doors are closed during Bedroom... -
Page 3: Installation Instructions
3. INSTALLATION INSTRUCTIONS Follow these steps in this order to install the CO alarm: 1. Fasten the mounting plate to the wall at eye level, about 5’ off the floor. Slide alarm down onto mounting plate. Connection between mounting plate and alarm will automatically turn activation switch ON. - Page 4 4. CONDENSED OPERATION INSTRUCTONS OPERATION: The CO alarm is operational once the activation switch is slid to position. If the alarm’s power is active, the green LED will POWER flash once every 60 seconds, and the LCD readout will continuously display ON, or the current CO level if 30 PPM or more is detected.
- Page 5 LCD DISPLAY FUNCTION: When alarm is operating normally, the LCD will display ON or the current CO level if 30 PPM or more is detected. The LCD will display after ten years of operation to alert you that it is time to replace the alarm. Continuously Displays “On”...
