- Page 1 P ROPRIETARY AND CONFIDENTIAL Explore the next sense Getting Started Guide Lens Evaluation Kit LH112/122 July 2020...
- Page 2 Getting Started Guide The Lenses are delivered as kits with two different lenses, a cover and a holder. The holder comes in two versions LH112 used for XR112 and XM112 and LH122 used for XM122. This getting started guide will show you how to setup the lens evaluation kit.
-
Page 3: Kit Content
P ROPRIETARY AND CONFIDENTIAL Kit content 1. LH112 1. LH122 The Lens Kit from Acconeer is delivered including 4 parts. Lens and PCB holder HBL Lens (Hyperbolic Lens) FZP Lens (Fresnel Zone Plate) Flat cover A cconeer apologize for our choice of White on White. - Page 4 P ROPRIETARY AND CONFIDENTIAL How to Assemble LH112 XR112 in the holder XM112 in the holder First thing you need to do is to fit the PCB into the Holder, which can be used with Both XR112 (To the left) and Acconeers XB/XM112 (To the right).
- Page 5 To the right is an example how to NOT place the sensor. Ensure that the BT antenna always is placed in the gap of the holder to ensure best performance. © 2018 by Acconeer...
- Page 6 P ROPRIETARY AND CONFIDENTIAL How to Assemble LH112 and 122 LH112 LH122 XC112 XM112 XM122 Cover Cover Cover 8,3 N/A 8,3 N/A 8,2 N/A Both the lenses can be fitted in the holder in 2 different positions. D1 or D2. The positioning numbering is identical for LH122.
- Page 7 P ROPRIETARY AND CONFIDENTIAL Performance Table LH112 Acconeer has verified both the XM112 with Max. Gain (dB HPBW-E HPBW-H lenses on both EVK variants. The (degree)** (degree)** LH112 holder expected performance can be viewed in the table to the right.
- Page 8 P ROPRIETARY AND CONFIDENTIAL Performance Table LH122 Acconeer has verified both the XM122 with Max. Gain (dB HPBW-E HPBW-H lenses on both EVK variants. The (degree)** (degree)** expected performance can be LH122 holder viewed in the table to the right.
-
Page 9: Performance Table
XR112 Cover - 0.3 - 0.3 LH122 holder Max. Gain HPBW-E HPBW- (degree)* H(degree) XM122 XM122 XM122 Cover - 0.04 *Maximum gain is relative to the free-space scenario. **Cover is only placed at D1. ***Simulated results © 2018 by Acconeer... - Page 10 P ROPRIETARY AND CONFIDENTIAL End Result LH112 FZP Lens in D1 The Correct Assembled Lens HBL Lens in D1 EVK should look like one of the examples in the pictures depending on chosen position. XM /XB112 used XR1 12 used...
- Page 11 FZP Lens in D1 EVK should look like one of the examples in the pictures depending on chosen position. XM 122 used XM 122 used HBL Lens in D2 Cover, only in D1 XM 122 used XM /XB112 used © 2018 by Acconeer...
