WF197131; WF197132; WF197133
Notice:
1. 50% Tighten before fixing all screws, Allen wrench is
recommended instead of an electric drill.
2. Place the item on a flat ground to adjust and make sure
it remains stable.
3. Tighten up all screws with tools gradually.
4. If the screws are not aligned with holes during asembly,
please loosen all the other screws to 50% and continue
the assembly process.
5. If the item is not stable, please loosen all the screws,
adjust it on a flat ground and tighten up all screws again.
6. Note: If one or some screws are fully tightened during
assembly, chances are the others will not be aligned with
holes. In addition, all the holes are designed to be relatively
larger to provide more space for the adjustment of the screws.
All manuals and user guides at all-guides.com
ASSEMBLY INSTRUCTION
