3.3 RS232 Serial Port

Board Type:
RS485 Port Count:
Communication Distance:
Data Bits:
Stop Bits:
Parity:
Baudrate:
Figure 7 RS232 Serial Port Connection Diagram
13
GC0
1 Port
10 m
7-8
1-2
None-Even-Odd
300 bps to 200 kbps
DM100 SERIES – HARDWARE MANUAL
