Seagate Technology ST2000VT000 Product Manual

Video 2.5 hdd

Advertisement

Video 2.5 HDD
Product Manual
Standard models
ST2000VT000
ST1000VT001
ST500VT003
100813461, Rev. H
March 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST2000VT000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Seagate Technology ST2000VT000

  • Page 1 Video 2.5 HDD Product Manual Standard models ST2000VT000 ST1000VT001 ST500VT003 100813461, Rev. H March 2018...
  • Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SeaTools and 3D Defense System are either a trademark or registered trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
  • Page 3: Table Of Contents

    Contents Seagate® Technology Support Services ..............5 Introduction .
  • Page 4 Contents Configuring and Mounting the Drive ..............22 Handling and Static-Discharge Precautions .
  • Page 5 Figures Figure 1 Typical 1D - 5V Startup and Operation Current Profile ........... 11 Figure 2 Typical 2D - 5V Startup and Operation Current Profile .
  • Page 6: SeagateĀ® Technology Support Services

    Seagate® Technology Support Services For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Video 2.5 Product Manual, Rev. H...
  • Page 7: Introduction

    Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate® Video 2.5 HDD model drives: Standard models ST2000VT000 ST1000VT001 ST500VT003 These drives provide the following key features: • 1000 Gs non-operating shock and 400 Gs of operating shock.
  • Page 8: Drive Specifications

    The specification summaries listed in the following tables are for quick reference. For details on specification measurement or definition, refer to the appropriate section of this manual. Table 1 Drive Specifications Summary Drive Specification ST2000VT000 ST1000VT001 ST500VT003 Formatted capacity 500GB...
  • Page 9: Formatted Capacity

    Drive Specifications Table 1 Drive Specifications Summary (continued) Drive Specification ST2000VT000 ST1000VT001 ST500VT003 Non-Operational Shock 1000 Gs at 1 ms max 5–200 Hz: 2.0 Gs Vibration, operating 201–500 Hz: 1.0 Gs Vibration, non-operating 5–500 Hz: 5.0 Gs Non-recoverable read errors...
  • Page 10: Physical Organization

    7.0 (± 0.2) / 0.276 (± 008) Width (mm/in) 69.85 (± 0.25) / 2.750 (± 0.010) Length (mm/in) 100.35 (+0.20/-0.25) / 3.951 (+0.008/-0.010) 90 / 0.198 (ST2000VT000 ) Typical weight (g/lb) 85 / 0.187 (ST1000VT001 & ST500VT003) Cache buffer 128MB Seek time Seek measurements are taken with nominal power at 25°C ambient temperature.
  • Page 11: Start/Stop Times

    Drive Specifications Start/stop times Table 3 Start/stop times Capacity 1-disk models 2-disk models 1-disk models 2-disk models Typical seek times (ms) Typical Max @ 25°C Power-on to ready (sec) Standby to ready (sec) Power Specifications The drive receives DC power (+5V) through a native SATA power connector (refer to Figure 2.7.1 Power consumption...
  • Page 12 Drive Specifications 2.7.1.1 Typical current profiles The typical 5V startup and operation current profile is shown in Figure 1 Figure Figure 1 Typical 1D - 5V Startup and Operation Current Profile Seagate Video 2.5 Product Manual, Rev. H...
  • Page 13 Drive Specifications Figure 2 Typical 2D - 5V Startup and Operation Current Profile Seagate Video 2.5 Product Manual, Rev. H...
  • Page 14: Conducted Noise

    Drive Specifications 2.7.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. • Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 20 MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current.
  • Page 15: Environmental Specifications

    Drive Specifications Environmental Specifications This section provides the temperature, humidity, shock, and vibration specifications for Video 2.5 HDD drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. Table 6 Environmental specifications Parameters...
  • Page 16: Vibration

    Drive Specifications 2.8.2 Vibration All vibration specifications assume that the drive is mounted securely with the input vibration applied at the drive mounting screws. Vibration may be applied in the X, Y, or Z axis. 2.8.2.1 Operating vibration The maximum vibration levels that the drive may experience while meeting the performance standards specified in this document are specified below.
  • Page 17: Electromagnetic Immunity

    Drive Specifications 2.10 Electromagnetic Immunity When properly installed in a representative host system, the drive operates without errors or degradation in performance when subjected to the radio frequency (RF) environment as defined in Table Table 8 Radio Frequency Environments Performance Reference Test Description...
  • Page 18: Reliability

    Drive Specifications 2.11 Reliability 2.11.1 Annualized Failure Rate (AFR) The product will achieve an Annualized Failure Rate (AFR) of 0.55% when operated in an environment of ambient air temperatures of 25°C. Operation at temperatures outside the specifications in Section 2.8, Environmental Specifications may increase the product AFR.
  • Page 19: Agency And Safety Certifications

    Drive Specifications 2.12 Agency and Safety Certifications Each Hard Drive and Solid State Drive ("drives") has a product label that includes certifications that are applicable to that specific drive. The following information provides an overview of requirements that may be applicable to the drive. 2.12.1 Safety certification The drives are recognized in accordance with UL/cUL 60950-1 and EN 60950-1 2.12.2 European Union (EU) CE Marking Requirements...
  • Page 20: Morocco Commodity Mark

    2.12.6 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the devices provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user.
  • Page 21: Environmental Protection

    Drive Specifications 2.13 Environmental protection Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. 2.13.1 European Union Restriction of Hazardous Substance Law 2.13.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate devices are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863.
  • Page 22: Taiwan Requirements - Taiwan Rohs

    2.13.3 Taiwan Requirements — Taiwan RoHS Taiwan RoHS refers to the Taiwan Bureau of Standards, Metrology and Inspection’s (BSMI) requirements in standard CNS 15663, Guidance to reduction of the restricted chemical substances in electrical and electronic equipment. Seagate products must comply with the “Marking of presence”...
  • Page 23: Configuring And Mounting The Drive

    Configuring and Mounting Configuring and Mounting the Drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and Static-Discharge Precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions.
  • Page 24: Drive Mounting

    Configuring and Mounting Drive Mounting Users can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. Refer to Figure 4 Figure 6 for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: •...
  • Page 25 Configuring and Mounting Figure 5 Mounting Dimensions (for 1-disk models) (alternate basedeck) 0.200 100.350 0.250 69.850 ± 0.250 (22.450) 2.499 ± 1.270 7.949 ± 1.270 (16.520) (90.600) (14.000) BASE 2X M3 X 0.5-6H 2X (3.000) MOUNTING HOLES: BOTH SIDES 7.000 0.200 4MM MIN.
  • Page 26 Configuring and Mounting Figure 6 Mounting Dimensions (for 2-disk models) (3.500) 0.20 100.35 0.25 (13.430) 69.850 0.250 22.450 16.520 2.499 1.270 7.949 1.270 (90.600) (14.000) BASE 2X M3 X 0.5-6H MOUNTING HOLES: BOTH SIDES 4MM MIN SCREW DEPTH 2X (3.000) BOTH SIDES 7.000 0.200 FROM M3 PADS.
  • Page 27: Serial Ata (Sata) Interface

    Serial ATA (SATA) Interface Serial ATA (SATA) Interface These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers.
  • Page 28: Supported Ata Commands

    Serial ATA (SATA) Interface Supported ATA Commands Table 13 lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA International Organization: Serial ATA (Revision 2.6). Refer to www.sata-io.org. Refer to S.M.A.R.T.
  • Page 29 Serial ATA (SATA) Interface Table 13 Supported ATA commands ATA-standard commands names Command code (in hex) S.M.A.R.T. Enable/Disable Auto Offline B0h/DBh S.M.A.R.T. Enable One Attribute Modification B0h/E0h S.M.A.R.T. Execute Offline B0h/D4h S.M.A.R.T. Free Fall Protection Host Interface S.M.A.R.T. Read Attribute Thresholds B0h/D1h S.M.A.R.T.
  • Page 30: Identify Device Command

    ST1000VT001 = 0FFFFFFFh This field contains a value that is one greater than the total number of ST2000VT000 = 0FFFFFFFh user-addressable sectors. The maximum value that shall be placed in this field is 0FFFFFFFh. The 0FFFFFFFh value applies to all capacities over 137GB (see Section 2.1, Formatted Capacity...
  • Page 31 ST500VT003 = 976,773,168 ST1000VT001 = 1,953,525,168 (see Section 3.2, Configuring the Drive for related information) ST2000VT000 = 3,907,029,168 These words are required for drives that support the 48-bit addressing feature. Maximum value: 0000FFFFFFFFFFFFh. Streaming Transfer Time - PIO 0000 Reserved 0000 Seagate Video 2.5 Product Manual, Rev.
  • Page 32 Serial ATA (SATA) Interface Table 14 Identify Device command Word Description Value Physical sector size / Logical sector size 6003 Seagate reserved 0000 108-111 The mandatory value of the world wide name (WWN) for the drive. Each drive will have a unique value. NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support.
  • Page 33 Serial ATA (SATA) Interface Table 15 Bit Descriptions Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported. Multiword DMA mode 1 is supported. Multiword DMA mode 2 is supported. Multiword DMA mode 0 is currently active. Multiword DMA mode 1 is currently active.
  • Page 34: Set Features Command

    Serial ATA (SATA) Interface 4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted.
  • Page 35: Commands

    Serial ATA (SATA) Interface 4.3.3 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disk drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable.
  • Page 36 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100813461, Rev. H...
