- Page 1 SATA 2.5" Product Manual Standard models ST5000LM000 ST4000LM024 ST3000LM024 100804767, Rev. H January 2019...
- Page 2 Seagate, Seagate Technology, BarraCuda and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. MTC Technology and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Contents Seagate® Technology Support Services..............5 1. - Page 4 Contents 3. Unpacking, Configuring and Mounting the Drive ................20 3.1 Handling and Static-Discharge Precautions .
- Page 5 Figures Figure 1. Attaching SATA Cabling ............... 20 Figure 2.
-
Page 6: Seagate® Technology Support Services
Seagate® Technology Support Services For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate BarraCuda Product Manual, Rev. H... -
Page 7: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following: Seagate® BarraCuda® model drives: Standard models ST5000LM000 ST4000LM024 ST3000LM024 These drives provide the following key features: 128MB buffer. • 5400-RPM spindle speed. • 650 Gs non-operating shock and 300 Gs of operating shock. •... -
Page 8: Specifications
Specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: The specification summaries listed in the following tables are for quick reference. For details on specification measurement or definition, refer to the appropriate section of this manual. -
Page 9: Formatted Capacity
Table 1 Drive Specifications Summary (continued) Drive Specification ST5000LM000 ST4000LM024 ST3000LM024 5% to 95% (operating) Relative humidity 5% to 95% (non-operating) 20°C per hour max (operating) Relative humidity gradient 30°C per hour max (non-operating) 37.7°C max (operating) Wet bulb temperature (max) 40.0°C max (non-operating) Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft) -
Page 10: Lba Mode
2.2.1 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. Refer to Unpacking, Configuring and Mounting the Drive on page 20 (words 60-61 and 100-103) for additional information about 48-bit addressing support of drives with capacities over 137 GB. -
Page 11: Seek Time
Seek time Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The specifications in the table below are defined as follows: • Average seek time is determined by averaging the time to complete 1,000 seeks of random length. •... -
Page 12: Power Specifications
Power Specifications The drive receives DC power (+5V) through a native SATA power connector (refer to1). 2.8.1 Power consumption Power requirements for the drives are listed in the table in Table 4. Typical power measurements are based on an average of drives tested, under nominal conditions, at 25°C ambient temperature. -
Page 13: Power-Management Modes
2.8.4 Power-management modes The drive provides programmable power management to provide greater energy efficiency. In most systems, users can control power management through the system setup program. The drive features the following power-management modes: Power modes Heads Spindle Electronics Active Tracking Rotating Full Power... -
Page 14: Environmental Specifications
Environmental Specifications This section provides the temperature, humidity, shock, and vibration specifications for Seagate BarraCuda drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. Table 5: Environmental specifications Parameters Operating... -
Page 15: Acoustics
2.10 Acoustics Drive emission of sound is measured consistent with the ECMA-74 and its referenced standards. Testing is conducted at room temperature (approximately 25°C). Emission levels are reported as the total A-weighted sound power levers for steady state, idle, and active seeks modes of operation. -
Page 16: Reliability
2.12 Reliability Nonrecoverable read errors 1 per 10 bits read, max Load/Unload (U/UL) 25°C, 50% relative humidity 600,000 software-controlled power on/off cycles 20,000 hard power on/off cycles Rated workload Average annualized workload rating: <55 TB/year. The specifications for the product assumes the I/O workload does not exceed the average annualized workload rate limit of 55 TB/year. -
Page 17: Agency And Safety Certifications
2.13 Agency and Safety Certifications Each Hard Drive and Solid State Drive ("drives") has a product label that includes certifications that are applicable to that specific drive. The following information provides an overview of requirements that may be applicable to the drive. 2.13.1 Safety certification The drives are recognized in accordance with UL/cUL 60950-1 and EN 60950-1. -
Page 18: Morocco Commodity Mark
2.13.6 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 19: Environmental Protection
2.14 Environmental protection Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. 2.14.1 European Union Restriction of Hazardous Substance Law 2.14.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate drives are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863. -
Page 20: Taiwan Requirements - Taiwan Rohs
2.14.3 Taiwan Requirements — Taiwan RoHS Taiwan RoHS refers to the Taiwan Bureau of Standards, Metrology and Inspection’s (BSMI) requirements in standard CNS 15663, Guidance to reduction of the restricted chemical substances in electrical and electronic equipment. Seagate products must comply with the “Marking of presence”... -
Page 21: Unpacking, Configuring And Mounting The Drive
Unpacking, Configuring and Mounting the Drive This chapter describes how to unpack, mount, configure and connect a BarraCuda. It also describes how to install the drive in systems. Handling and Static-Discharge Precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions. -
Page 22: Drive Mounting
Drive Mounting Users can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. Refer to2 Figure 2 for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: Allow a minimum clearance of 0.030 in (0.76 mm) around the entire perimeter of the drive for cooling. -
Page 23: Serial Ata (Sata) Interface
Serial ATA (SATA) Interface These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers. -
Page 24: Supported Ata Commands
Notes All pins are in a single row, with a 1.27 mm (0.050 in) pitch. The comments on the mating sequence apply to the case of backplane blindmate connector only. In this case, the mating sequences are: • the ground pins P4 and P12. •... - Page 25 Table 11 Supported ATA commands ATA-standard commands names Command code (in hex) Read Verify Sectors Extended Read Verify Sectors without Retries Seek Set Features Set Max Address Note: Individual Set Max commands are identified by the value Address: placed in the Set Max Features register as defined to the right. Password: Lock: Unlock:...
- Page 26 Table 11 Supported ATA commands ATA-standard commands names Command code (in hex) Write Long without Retries Write Multiple Write Multiple Extended Write Sectors Write Sectors Extended ATA-standard power-management commands Check Power Mode Idle Idle Immediate Sleep Standby Standby Immediate ATA-standard security commands Security Set Password Security Unlock Security Erase Prepare...
-
Page 27: Identify Device Command
4.3.1 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in Table 12. All reserved bits or words should be set to zero. Parameters listed with an “x” are drive-specific or vary with the state of the drive. - Page 28 Table 12 Identify Device command Word Description Value 60–61 Total number of user-addressable sectors ST5000LM000 = 0FFFFFFFh ST4000LM024 = 0FFFFFFFh This field contains a value that is one greater than the total number of ST3000LM024 = 0FFFFFFFh user-addressable sectors. The maximum value that shall be placed in this field is 0FFFFFFFh.
- Page 29 Table 12 Identify Device command Word Description Value Streaming Transfer Time - DMA 0000 Streaming Access Latency - DMA and PIO 0000 98-99 Streaming Performance Granularity 0000 100–103 Total number of user-addressable LBA sectors available ST5000LM000 = 9,767,541,168 ST4000LM024 = 3,907,029,168 (see Section 3.2, Configuring the Drive for related information)
- Page 30 Table 13 Bit Descriptions Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported. Multiword DMA mode 1 is supported. Multiword DMA mode 2 is supported. Multiword DMA mode 0 is currently active. Multiword DMA mode 1 is currently active. Multiword DMA mode 2 is currently active.
-
Page 31: Set Features Command
4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. -
Page 32: Commands
4.3.3 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disk drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable. - Page 33 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100804767, Rev. H...
