- Page 1 SATA Product Manual Standard models ST6000VN001 100856098, Rev. A July 2019...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. IronWolf and SeaTools are either trade- marks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Contents Seagate® Technology Support Services ............. . . 5 Introduction . - Page 4 Contents 2.12 Agency and Safety Certifications ............. 17 2.12.1 Safety certification .
- Page 5 Figures Figure 1 Attaching SATA cabling............... . 22 Figure 2 Mounting dimensions (6TB models) .
-
Page 6: Seagate® Technology Support Services
Seagate® Technology Support Services For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate IronWolf Product Manual, Rev. A... -
Page 7: Introduction
1.0 Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate® IronWolf® and model drives: IronWolf models ST6000VN001 These drives provide the following key features: • 1M hour MTBF - designed for high write duty cycle across IronWolf •... -
Page 8: About The Sata Interface
www.seagate.com Introduction About the SATA interface The Serial ATA (SATA) interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include: • Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration options. -
Page 9: Drive Specifications
2.0 Drive Specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: IronWolf models ST6000VN001 Specification summary tables The specifications listed in... - Page 10 www.seagate.com Drive Specifications Table 1 Drive specifications summary (continued) Drive Specification* ST6000VN001 30°C max (operating) Wet bulb temperature (max) 40°C max (non-operating) –304m to 3048m Altitude, operating (–1000 ft to 10,000 ft) Altitude, non-operating –304m to12,192m (below mean sea level, max) (–1000 ft to 40,000+ ft) Operational shock (max) 70 Gs at 2ms...
-
Page 11: Formatted Capacity
www.seagate.com Drive Specifications Formatted capacity Model Formatted capacity* Guaranteed sectors Bytes per sector 4096 6000GB 11,721,045,168 *One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. 2.2.1 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. -
Page 12: Physical Characteristics
www.seagate.com Drive Specifications Physical characteristics Maximum height 26.1mm / 1.028 in Maximum width 101.6mm / 4.0 in (± 0.010 in) Maximum length 146.99mm / 5.787 in Typical weight 610g / 1.345 lb Cache buffer 256MB Start/stop times The start/stop times are listed below. 6TB models Power-on to ready 15 (typical) -
Page 13: Power Specifications
www.seagate.com Drive Specifications Power specifications The drive receives DC power (+5V or +12V) through a native SATA power connector. Refer to Figure 1 on page 22 2.7.1 Power consumption Power requirements for the drives are listed in . Typical power measurements are based on an average of drives Table 2 tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient temperature. -
Page 14: Voltage Tolerance
www.seagate.com Drive Specifications 2.7.3 Voltage tolerance Voltage tolerance (including noise): • 5V ±5% • 12V ±10% 2.7.4 Power-management modes The drive provides programmable power management to provide greater energy efficiency. In most systems, users can control power management through the system setup program. The drive features the following power-management modes:: Power modes Heads... -
Page 15: Environmental Specifications
www.seagate.com Drive Specifications Environmental specifications This section provides the temperature, humidity, shock, and vibration specifications for IronWolf drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000ft. (305 meters), the maximum temperature is derated linearly by 1°C every 1000 ft. Refer to for base plate Section 3.4 on page 23 measurement location. -
Page 16: Altitude
www.seagate.com Drive Specifications 2.8.4 Altitude Operating –304m to 3048m (–1000 ft. to 10,000 ft.) Non-operating –304m to 12,192m (–1000 ft. to 40,000+ ft.) 2.8.5 Shock All shock specifications assume that the drive is mounted securely with the input shock applied at the drive mounting screws. -
Page 17: Acoustics
www.seagate.com Drive Specifications Acoustics Drive acoustics are measured as overall A-weighted acoustic sound power levels (no pure tones). All measurements are consistent with ISO document 7779. Sound power measurements are taken under essentially free-field conditions over a reflecting plane. For all tests, the drive is oriented with the cover facing upward. For seek mode tests, the drive is placed in seek mode only. -
Page 18: Warranty
www.seagate.com Drive Specifications 2.11 Warranty To determine the warranty for a specific drive, use a web browser to access the following web page: http://www.seagate.com/support/warranty-and-replacements/ From this page, click on “Is my Drive under Warranty”. Users will be asked to provide the drive serial number, model number (or part number) and country of purchase. -
Page 19: Australian Rcm Compliance Mark
www.seagate.com Drive Specifications 2.12.3 Australian RCM Compliance Mark If these models have the RCM marking, they comply with the Australia/New Zealand Standard AS/NZ CISPR32 and meet the Electromagnetic Compatibility (EMC) Framework requirements of the Australian Communication and Media Authority (ACMA). 2.12.4 Canada ICES-003 If this model has the ICES-003:2016 marking it complies with requirements of ICES tested per ANSI C63.4-2014. -
Page 20: Fcc Verification
www.seagate.com Drive Specifications 2.12.8 FCC verification These drives are intended to be contained solely within a personal computer or similar enclosure (not attached as an external device). As such, each drive is considered to be a subassembly even when it is individually marketed to the customer. -
Page 21: China Requirements -China Rohs 2
2.13.1.2 Substances of Very High Concern (SVHC) The European Union REACH (Registration, Evaluation, Authorization and Restriction of Chemicals) Regulation (EC) 1907/ 2006 regulates chemicals shipped into and used in Europe. A number of parts and materials in Seagate products are procured from external suppliers. -
Page 22: Taiwan Requirements - Taiwan Rohs
www.seagate.com Drive Specifications 2.13.3 Taiwan Requirements — Taiwan RoHS Taiwan RoHS refers to the Taiwan Bureau of Standards, Metrology and Inspection’s (BSMI) requirements in standard CNS 15663, Guidance to reduction of the restricted chemical substances in electrical and electronic equipment. Seagate products must comply with the “Marking of presence”... -
Page 23: Configuring And Mounting The Drive
3.0 Configuring and Mounting the Drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. -
Page 24: Drive Mounting
www.seagate.com Configuring and Mounting the Drive Drive mounting Users can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom- mounting holes. Refer to Figure 2 for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: •... -
Page 25: Sata Interface
www.seagate.com SATA Interface 4.0 SATA Interface These drives use the industry-standard Serial ATA (SATA) interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0 to 4; multiword DMA modes 0 to 2, and Ultra DMA modes 0 to 6. For detailed information about the SATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment”... -
Page 26: Supported Ata Commands
www.seagate.com SATA Interface Supported ATA commands The following table lists SATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA International Organization: Serial ATA Revision 3.2 (http://www.sata-io.org). See “S.M.A.R.T. commands” on page 33 for details and subcommands used in the S.M.A.R.T. - Page 27 www.seagate.com SATA Interface Table 8 SATA standard commands (continued) Command name Command code (in hex) Seek Set Features Set Max Address Note: Individual Set Max Address Address: commands are identified by the value Password: placed in the Set Max Features register as Lock: defined to the right.
-
Page 28: Identify Device Command
www.seagate.com SATA Interface 4.3.1 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in Table 8 on page 25. - Page 29 www.seagate.com SATA Interface Table 9 Identify Device commands (continued) Word Description Value PIO data-transfer cycle timing mode 0200 Retired (Obsolete) 0200 15:8 Free-fall Control Sensitivity 7:3 Reserved 2 the fields reported in word 88 are valid 0007 1 the fields reported in words (70:64) are valid 0 Obsolete Number of current logical cylinders (Obsolete) xxxx...
- Page 30 www.seagate.com SATA Interface Table 9 Identify Device commands (continued) Word Description Value 70–74 ATA-reserved 0000 Queue depth 001F SATA capabilities xxxx Reserved for future SATA definition xxxx SATA features supported xxxx SATA features enabled xxxx Major version number 07F0 Minor version number 006D Command sets supported 306B...
- Page 31 www.seagate.com SATA Interface Table 9 Identify Device commands (continued) Word Description Value SCT Command Transport 10A5 207-208 ATA-reserved 0000 Alignment of logical blocks within a physical block 4000 210-216 ATA-reserved 0000 Nominal media rotation rate 175C 218-221 ATA-reserved 0000 Transport major version number 107F 223-229 ATA-reserved...
- Page 32 www.seagate.com SATA Interface Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported. Multiword DMA mode 1 is supported. Multiword DMA mode 2 is supported. Multiword DMA mode 0 is currently active. Multiword DMA mode 1 is currently active. Multiword DMA mode 2 is currently active.
-
Page 33: Set Features Command
www.seagate.com SATA Interface 4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. -
Page 34: Commands
www.seagate.com SATA Interface 4.3.3 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disk drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable. S.M.A.R.T. predictability is limited to the attributes the drive can monitor. - Page 35 Seagate Technology LLC AMERICAS Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 Publication Number: 100856098, Rev. A July 2019...
