Mobile HDD 5400 RPM - SATA Product Manual Standard models Self-Encrypting Drive models ST2000LM007 ST2000LM009 ST1000LM035 ST1000LM037 ST500LM030 SED (FIPS 140-2) models ST2000LM010 ST1000LM038 100775165, Rev. F November 2016...
Page 2
Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SeaTools and 3D Defense System are either a trademark or registered trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
Seagate® Technology Support Services For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Mobile HDD Product Manual, Rev. F...
This manual describes the functional, mechanical and interface specifications for the following Seagate® Mobile HDD model drives: Standard Standard SED Standard SED models models (FIPS 140-2) models ST2000LM007 ST2000LM009 ST2000LM010 ST1000LM035 ST1000LM037 ST1000LM038 ST500LM030 Previous generations of Seagate Self-Encrypting Drive models were called Full Disk Encryption (FDE) models Note before a differentiation between drive-based encryption and other forms of encryption was necessary.
About the Serial ATA Interface The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include: • Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration options. •...
The specification summaries listed in the following tables are for quick reference. For details on specification measurement or definition, refer to the appropriate section of this manual. Table 1 Drive Specifications Summary ST2000LM007, ST2000LM009 ST1000LM035, ST1000LM037 Drive Specification ST500LM030 and ST2000LM010...
Drive Specifications Physical organization Drive model Read/write heads Number of discs ST2000LM007, ST2000LM009 and ST2000LM010 ST1000LM035, ST1000LM037 and ST1000LM038 ST500LM030 Recording and Interface Technology Interface SATA 6Gb/s Recording method Perpendicular Recording density 2276 Kb/in Track density 580 ktracks/in avg Areal density...
Drive Specifications Start/stop times Table 3 Start/stop times 1-disk models 2-disk models 1-disk models 2-disk models Typical seek times (ms) Typical Max @ 25°C Power-on to ready (sec) Power-on to ready (sec) (SED models) Standby to ready (sec) Power Specifications The drive receives DC power (+5V) through a native SATA power connector (refer to Figure 2.7.1...
Page 13
Drive Specifications 2.7.1.1 Typical current profiles The typical 5V startup and operation current profile is shown in Figure 1 Figure Figure 1 Typical 1D - 5V Startup and Operation Current Profile Seagate Mobile HDD Product Manual, Rev. F...
Page 14
Drive Specifications Figure 2 Typical 2D - 5V Startup and Operation Current Profile Seagate Mobile HDD Product Manual, Rev. F...
Drive Specifications 2.7.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. • Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 20 MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current.
Drive Specifications Environmental Specifications This section provides the temperature, humidity, shock, and vibration specifications for Mobile HDD drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. Table 6 Environmental specifications Parameters...
Drive Specifications 2.8.2 Vibration All vibration specifications assume that the drive is mounted securely with the input vibration applied at the drive mounting screws. Vibration may be applied in the X, Y, or Z axis. 2.8.2.1 Operating vibration The maximum vibration levels that the drive may experience while meeting the performance standards specified in this document are specified below.
Drive Specifications 2.10 Electromagnetic Immunity When properly installed in a representative host system, the drive operates without errors or degradation in performance when subjected to the radio frequency (RF) environment as defined in Table Table 8 Radio Frequency Environments Performance Reference Test Description...
Drive Specifications 2.12 Agency Certification 2.12.1 Safety certification These products are certified to meet the requirements of UL60950-1, CSA60950-1 and EN60950 and so marked as to the certify agency. The following regulatory model number represent all features and configurations within the series: Regulatory Model Numbers: SDC001/SDC003 2.12.2 Electromagnetic Compatibility (EMC)
2.13 Environmental Protection Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. 2.13.1 European Union Restriction of Hazardous Substances (RoHS) Directive The European Union Restriction of Hazardous Substances (RoHS) Directive, restricts the presence of chemical substances, including Lead, Cadmium, Mercury, Hexavalent Chromium, PBB and PBDE, in electronic products, effective July 2006.
Configuring and Mounting Configuring and Mounting the Drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and Static-Discharge Precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards. Observe the following standard handling and static-discharge precautions.
Drive Mounting Users can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. Refer to Figure 4 Figure 5 for drive mounting dimensions. Follow these important mounting precautions when mounting the drive: •...
Page 23
Configuring and Mounting Figure 5 Mounting Dimensions (for 2-disk models) 0.20 100.35 0.25 (13.430) 69.850 0.250 22.450 16.520 2.499 1.270 7.949 1.270 (90.600) (14.000) BASE 2X M3 X 0.5-6H 2X (3.000) BOTH SIDES 7.000 0.200 MOUNTING HOLES: BOTH SIDES 3.505 +.075 -.3 X90 Seagate Mobile HDD Product Manual, Rev.
About FIPS About FIPS The Federal Information Processing Standard (FIPS) Publication 140-2, FIPS PUB 140-2, is a U.S. government computer security standard used to accredit cryptographic modules. It is titled “Security Requirements for Cryptographic Modules”. The initial publication was on May 25, 2001 and was last updated December 3, 2002.
About (SED) Self-Encrypting About (SED) Self-Encrypting Drives Self-encrypting drives (SEDs) offer encryption and security services for the protection of stored data, commonly known as "protection of data at rest." These drives are compliant with the Trusted Computing Group (TCG) Opal Storage Specifications as detailed in the following: Trusted Computing Group (TCG) Documents (apply to Self-Encrypting Drive models only) TCG Storage Architecture Core Specification, Version 2.0 TCG Storage Security Subsystem Class Opal Specification, Version 2.0...
About (SED) Self-Encrypting Random Number Generator (RNG) The drive has a 32-byte hardware RNG that it is uses to derive encryption keys or, if requested to do so, to provide random numbers to the host for system use, including using these numbers as Authentication Keys (passwords) for the drive's Admin and Locking SPs. Drive Locking In addition to changing the passwords, as described in Section 5.2.3, Default...
Serial ATA (SATA) Interface Serial ATA (SATA) Interface These drives use the industry-standard Serial ATA interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–6. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers.
Serial ATA (SATA) Interface Supported ATA Commands Table 12 lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA International Organization: Serial ATA (Revision 2.6). Refer to www.sata-io.org. Refer to S.M.A.R.T.
Page 29
Serial ATA (SATA) Interface Table 12 Supported ATA commands ATA-standard commands names Command code (in hex) S.M.A.R.T. Enable/Disable Auto Offline B0h/DBh S.M.A.R.T. Enable One Attribute Modification B0h/E0h S.M.A.R.T. Execute Offline B0h/D4h S.M.A.R.T. Free Fall Protection Host Interface S.M.A.R.T. Read Attribute Thresholds B0h/D1h S.M.A.R.T.
8000 Obsolete 0004 23–26 Firmware revision: (8 ASCII character string, padded with blanks to end of string) x.xx 27–46 Drive model number: ST2000LM007 (40 ASCII characters, padded with blanks to end of string) ST2000LM009 ST2000LM010 ST1000LM035 ST1000LM037 ST1000LM038 ST500LM030 (Bits 7–0) Maximum sectors per interrupt on Read multiple and Write multiple (16)
Page 31
Description Value 60–61 Total number of user-addressable sectors ST2000LM007 = 0FFFFFFFh ST2000LM009 = 0FFFFFFFh This field contains a value that is one greater than the total number of ST2000LM010 = 0FFFFFFFh user-addressable sectors. The maximum value that shall be placed in this field is ST1000LM035 = 0FFFFFFFh 0FFFFFFFh.
Page 32
Value 98-99 Streaming Performance Granularity 0000 100–103 Total number of user-addressable LBA sectors available ST2000LM007 = 3,907,029,168 ST2000LM009 = 3,907,029,168 (see Section 3.2, Configuring the Drive for related information) ST2000LM010 = 3,907,029,168 These words are required for drives that support the 48-bit addressing ST1000LM035 = 1,953,525,168 feature.
Page 33
Serial ATA (SATA) Interface Table 14 Bit Descriptions Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported. Multiword DMA mode 1 is supported. Multiword DMA mode 2 is supported. Multiword DMA mode 0 is currently active. Multiword DMA mode 1 is currently active.
Serial ATA (SATA) Interface 6.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted.
Serial ATA (SATA) Interface 6.3.3 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disk drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable.
