Mocka Hamptons Bar Stool Assembly Instructions

Hamptons Bar Stool

Assembly Instructions

Thank you for your purchase.

Please follow the instructions below for correct assembly.

90mm screw

80mm screw

flat washer

32mm screw

x10

Hardware Supplied

Phillips & Flathead screwdrivers required.

For quicker assembly, we recommend the

use of a power drill on a low-speed setting.

mocka.co.nz | mocka.com.au |

35mm screw

spring

washer

x10

allen key

Read the instructions carefully. Refer to the hardware and furniture parts list for

guidance. Be sure all of the pans are complete before assembling. Place all of the

wooden furniture parts on a clean and ﬂat soft surface to prevent scratches.

Refer to the steps provided as an assembling guide.

CAUTION :

1. Do not tighten the nuts or nut bolts completely until they are all in place.

2. To avoid thread damage, avoid overtightening nuts or nut bolts.

3. Hardware is to be kept out of reach of children.
