Using the OptiView

The OptiView Browser allows you access to OptiView Workgroup and OptiView
through a browseable user interface installed on your PC. Double-click on an analyzer from this list and the
user interface is launched. If an analyzer is password protected, you will be prompted to enter a password.
In order for analyzers that are not in the same local network (subnet) to be displayed in the OptiView
Browser list, you must first configure the Remote Control IP address setting. This is found in the
Setup | Remote screen. The Remote Control IP address should match the IP address of the PC that you
intend to run the OptiView
source IP address back to the controlling PC.
Launch user interface
for selected analyzer
Refresh
analyzer list
Encryption ON
Encryption OFF
OptiView Series III
Integrated Network Analyzer
OptiView Series I and II
Integrated Network Analyzer
Accessing the Analyzer through the Remote User Interface Software
Browser and User Interface Software
TM
TM Workgroup user interface software on. Then, the remote analyzer will send its
Figure 3. OptiView Browser
Workgroup Analyzer
TM Integrated analyzers
Launch Web browser for selected
OptiView Integrated Network Analyzer
Launch firmware for selected
OptiView Workgroup Analyzer
OptiView Workgroup Analyzer
OptiView Series III
Workgroup Analyzer
OptiView WAN Analyzers
