4-stage reverse osmosis water filtration system

Advertisement

Quick Links

4-Stage Reverse Osmosis Water Filtration System
Installation and Operating Instructions
Model RO-2500
IMPORTANT: Before installing this reverse osmosis system, make
certain your water supply complies with the following operating
specifications. Failure to do so may reduce the effectiveness of the
system and will void the warranty.
Specifications
Thin Film Membrane:
Feed Water Pressure:
Temperature Range:
TDS:
Maximum Hardness*:
Sulfide, Iron and Manganese†:
Chlorine in Water Supply:
pH Limits:
Daily Product Water Rate‡:
TDS Rejection:
Turbidity:
* If the hardness of your water is above 10 gpg (171 mg/L), lime scale
will build up rapidly on the membrane. Scale buildup will plug the
membrane and make the system ineffective. We do not recommend
these reverse osmosis systems to be used with water in excess of
10 gpg (171 mg/L) hardness.
† A maximum total level of approximately 0.01 ppm sulfide, iron or
manganese is permissible. See your local dealer to reduce these
substances in your water.
‡Based on manufacturer's internal testing.
Parts Included:
(See back of manual for diagram)
Pre-assembled filter system (mounting bracket, membrane housing,
membrane, pre- and post-filter housings and pre- and post-filter
cartridges).
• Reverse osmosis membrane
• Inlet supply adapter
• Drain clamp
• 1/4-inch Tubing
• Tank valve
System Dimensions:
Overall Dimensions:
13
(34.29 cm W x 12.7 cm D x 43.8 cm H)
Weight:
17.3 lbs. (7.84 kg)
Tank Dimensions:
13
(34.29 cm W x 20.32 cm D x 22.86 cm H)
Tank Capacity Max:
1.3 gal. (4.9 L)
Tank Air Pressure Empty:
5 to 7 psi (0.34 to 0.48 bar)
Tank Weight (Full):
14.5 lbs. (6.5 kg)
TFM-36
40 to 100 psi (2.75–6.9 bar)
40–100°F (4.4–37.7°C)
2000 ppm
10 gpg (171 mg/L)
0 ppm <0.1 ppm
Less than 2 ppm
3–11
11.76 gpd (44.5 Lpd)
92–99%
5 NTU Max
• Storage tank
• Chrome faucet
• Feed tubing
• Sump wrenches
• 3/8-inch Tubing
-inch W x 5
-inch D x 17
-inch H
1
1
1
2
2
4
-inch W x 8 inch D x 9 inch H
1
2
Technical Support: 1-800-279-9404 (M-F 7:30 am - 5:00 pm CST)
Tools and Materials Required
• Hand or electric drill
(cordless preferred)
• (2) Adjustable wrenches
• Slotted and Phillips screwdrivers
• File
• Safety glasses
• Drill bits: 1/8", 3/16", 1/4", 3/8"
NOTE: All tools may not be necessary for installation.
Read installation procedures before starting to determine what tools
are necessary.
If sink does not have
hole for separate faucet:
• Center punch
• Cone-shaped grinding
wheel
• 1
-inch hole saw or drill bit
1
4
• Safety mask
SH147646 Rev A NO09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PENTEK RO-2500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pentair PENTEK RO-2500

  • Page 1 4-Stage Reverse Osmosis Water Filtration System Installation and Operating Instructions Model RO-2500 IMPORTANT: Before installing this reverse osmosis system, make certain your water supply complies with the following operating specifications. Failure to do so may reduce the effectiveness of the system and will void the warranty.
  • Page 2 Precautions GENERAL HOw REvERSE OSMOSIS wORkS Do not use with water that is microbiologically unsafe The RO-2500 Reverse Osmosis (RO) System uses a semi-permeable wARNING: or of unknown quality without adequate disinfection before or after membrane to reduce dissolved salts and minerals, improving the the system.
  • Page 3: Installation

    Installation • Read all installation and operating instructions before installing and using your RO system. • Numbered diagrams correspond with numbered steps. 1. Installing the water Supply Adapter The supply adapter fits 1/2-inch 14 NPS threads. If local codes permit, it may be used to connect the RO-2500 to the cold water supply line.
  • Page 4 Installation Continued . . . (I) Center the faucet and slip "C" disc between the white extension and the bottom of the counter or sink. Tighten the stem nut with a wrench until it is tight. (J) Firmly insert goose-neck spout into faucet base. 4.
  • Page 5 Installation Continued . . . 1/4" Tube 8. Connecting the Storage Tank to the System CAuTION: When tank is full, it weighs approximately 14.5 lbs. (6.5 kg) Provide ample Apply support under the tank. Teflon tape (A) To prevent leaks, apply 3 or more wraps of Teflon tape to threads on tank. Thread the 5/8"...
  • Page 6 Installation Continued . . . 11. Faucet Operation (A) For controlled water flow, push the handle down. (b) For constant water flow, lift the faucet handle to lock it in the open position. 12. System Start-up NOTE: The reverse osmosis membrane is treated with a food grade sanitizing agent that may cause an undesirable taste.
  • Page 7: Optional Installation

    Optional Installation Connecting your Reverse Osmosis System to Refrigerator Icemaker / water Dispenser CAuTION: If you are connecting this unit to your refrigerator/icemaker with initial RO installation, wait to turn on the icemaker until the post- polishing filter has been flushed according to Step 12. CAuTION: Use plastic tubing and fittings.
  • Page 8: Replacing The Pre-Filter And Post-Filter Cartridges

    Replacing the Pre-Filter and Post-Filter Cartridges 1st Stage Pre-Filter and 2nd Stage Pre-Filter Cartridges: 7. Insert cartridges in the bottom of the housings. Make sure The cartridge should be replaced every six months. If your cartridge slips over standpipe in the bottom of the housing. water contains a high amount of sediment, it may be necessary to NOTE: Be sure to install cartridges in proper housings (see diagram below).
  • Page 9: Replacing The 3Rd Stage Reverse Osmosis Membrane

    Replacing the 3rd Stage Reverse Osmosis Membrane About the Reverse Osmosis Membrane 11. Close the cold water supply and turn on the drinking water faucet. Let the faucet run for about 30 seconds before turning off. When used under operating conditions specified on page 1 of the 12.
  • Page 10: Troubleshooting Guide

    Troubleshooting Guide Leaks between bottom of housing and cap Reduced production Slow or no product water flow usually indicates either a clogged pre- 1. Ensure sump is tightly screwed to cap. If it still leaks close the cold filter or an exhausted membrane. First, replace the pre-filters. If the water supply and tank valves.
  • Page 11: Parts Guide

    Parts Guide 555235-43 3rd Stage RO Membrane TFM-36 SH244796 Drain Clamp 555573-43 4th Stage Post-filter GS-10RO-B with fittings SH244797 Inlet Supply Adapter 150539 SW-1 Wrench SH244820 Faucet 150640 RO Housing Wrench SH153049 Housing 143495 Silicone SH244794 1/4-inch Tubing SH244787 Valve Auto Shut-off SH244795 3/8-inch Tubing 161080...
  • Page 12: Warranty

    THIS WARRANTY GRANTS SPECIFIC LEGAL RIGHTS, AND OTHER RIGHTS MAY APPLY. SUCH RIGHTS VARY FROM STATE TO STATE. 5730 North Glen Park Road, Milwaukee, WI 53209 Technical Support: 800.279.9404 © 2009 Pentair Residential Filtration, LLC SH147646 Rev. A NO09...
