Operation
Select CTCSS

Select CTCSS Subchannel (00-38)

Subchannel
The CTCSS Subchannel allows the user to utilize a less
used channel range (00-38) within a main channel.
Turn on the microTALK. An audible "tone" will
indicate the unit is on and then the LCD will go
Note
through a 3 second self-test and then go to
Operational Mode.
If you push and hold the Mode
Button,the LCD display will
cycle through
the different functions.
Note
To return to Operational Mode
and not save your last setting
push and release talk
button.
Select main channel by the Channel Button up
or down.
Note
CTCSS (Coded Tone Controlled
Squelch System) is an
advanced subcoding
system that allows
segmentation of a main chan-
nel.
Push and release
bers flash next to channel display on LCD.
6
Page 6
Mode Button. Small num-
Se l e ct s u bcode number by moving the Ch a n n e l
Bu t ton up or dow n.
When desired code is displayed press and
release Lock Button. If key stroke tone is
on,an audible tone will confirm your selection.
Operation
Select CTCSS
Subchannel
Note
Press and hold the Channel
Button up and down for fast
channel advance.
7
