Backlit LCD Display

Features
1
• 60 Channels
• 10 Channel
Weather Radio
16
• Weather Alert
• 121 Privacy Codes
(38 CTCSS codes/
83 DCS codes)
• Hands-Free Operation
(VOX) 15
• VibrAlert Paging
®
• Scan
Channels, privacy codes
• Backlit LCD Display
• LED/S.O.S Flashlight
• Call Alert
Ten selectable tones
• Button Lock
• Speaker/
Microphone/
Charge Jack
• Roger Beep
Selectable On/Off
• Battery/Power Saver
• Keystroke Tones
• Battery Level Indicator
• Low Battery
Audible Alert
• Auto Squelch
• Maximum Range
Extender
• Belt Clip
• Emergency Call
• IP54 Waterproof and
Dustroof
2
4
3
5
2 6
14
13 12
1. Receive/Transmit Icon
2. Battery Level Indicator
3. Hi/Low Power Icon
4. Roger Beep Icon
5. VOX Icon
6. Weather Icon
7. Lock Icon
8. Key Tone Icon
9. Weather Alert Icon
10. DCS/CTCSS Icons
11. DCS/CTCSS Privacy Code
Numbers
12. Power Saver Icon
13. Memory Channel Number
14. Scan/Memory Icon
15. Channel Numbers
16. VibrAlert / Call Alert Icon
®
Maximum range may vary and is based on
unobstructed line-of-sight communication
under ideal conditions.

Caring for Your microTALK

Your microTALK
properly. Handle the radio gently. Keep the radio away from dust. Never put
the radio in water or in a damp place. Avoid exposure to extreme
temperatures.
7
Installing Batteries (Battery already pre-installed)
8
Remove Belt Clip
9
10
11 Remove Screw
Battery connector
Wires alignment
2
USB Charger Jack
Only use the supplied rechargeable batteries and desktop charger for
recharging your Cobra microTALK
Please charge new batteries for 8 hours for rst time of use.
Cobra recommends your radio is turned off while being charged.
Radio
®
radio will give you years of trouble-free service if cared for
®
To install or replace batteries:
1. Remove belt clip by releasing belt clip latch and
sliding clip up.
2. Using a at head screw driver or edge of a coin
(a quarter may be used), remove the screw securing
the back battery panel.
3. Open the battery compartment cover, connect the
connector of the battery to the socket of the radio
inside the battery compartment.
4. Place the battery inside battery compartment and
align the wires as shown.
Ensure the battery connector with cables are tucked
into the hole (keeps the connector to the left) located
at bottom as shown.
(Note: Wires are required to be tucked into the battery
compartment completely and carefully. If any object
interfere the O-ring, its sealing perfomence will be
affected.)
5. Place the battery compartment cover, screw down the
screws mildly.
(Screw nuts may be damaged if overtighten)
6. Re-attach the belt clip.
To charge batteries in radio:
1. Check to see that the batteries have been
inserted properly.
2. Insert the cable into the charge jack located at the
right side of the radio.
3. Plug the cable into USB-compatible power port.
radio.
®
