digitalview SGX-1920 Instructions Manual

Pc, dvi, hdmi, video interface controller for tft panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
Page: 2. Introduction, How to Proceed, Usage Note, Disclaimer
3. System design – Diagram of a suggested system
4. Assembly notes – Important information about system elements
7. Connection & Operation – How to use the controller
14. Connectors, pinouts & jumpers – Essential connection information
26. Controller dimensions
27. Application notes
29. Troubleshooting
30. Specifications
31. Appendix I – Supported graphics modes table
34. Appendix II – RS-232 control protocols
51. Appendix III – Mapping definition
55. Appendix IV – Auto Color Gain
56. Appendix V – DV remote control unit work for SVX-1920
57. Appendix VI – Function description for de-interlacing mode AFM, TNR,
57. Appendix VII – PIP mix table
58. Appendix VIII - Network connection
59. Appendix IX – Digital Ports selection on SGX-1920
64. Appendix X - Specification for inverter Interface Board P/N 416040010-3
67. Appendix XI - Specification for audio add-on board P/N 416940020-3
69. Warranty, Caution & Limitation of Liability, Trademarks
70.Contact details
It is essential that these instructions are read and understood before connecting or
powering up this controller.
Specifications subject to change without notice
© Digital View Ltd – Doc Ver 1.7: 23 April, 2014 (SGX-1920_manual.doc)
Arrow.com.
Downloaded from
PC, DVI, HDMI, VIDEO INTERFACE CONTROLLER
FOR TFT PANEL
Model: SGX-1920
Part number : 41725001X-3 or up
INSTRUCTIONS
MADI, DCDi
1 of 70
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGX-1920 and is the answer not in the manual?

Questions and answers

Related Manuals for digitalview SGX-1920

Summary of Contents for digitalview SGX-1920

  • Page 1 57. Appendix VII – PIP mix table 58. Appendix VIII - Network connection 59. Appendix IX – Digital Ports selection on SGX-1920 64. Appendix X - Specification for inverter Interface Board P/N 416040010-3 67. Appendix XI - Specification for audio add-on board P/N 416940020-3 69.
  • Page 2 Introduction Designed for LCD monitor and other flat panel display applications, the SGX-1920 is a feature rich interface controller for : TFT (active matrix) LCD panels of 1920x1200, 1920x1080, 1920x480, 1680x1050, 1600x1200, 1600x900, 1440x900, 1366x768, 1280x1024, 1280x800, 1280x768 1024x768, 1024x600, 800x600, 800x480 and 640x480 resolutions.

  • Page 3: System Design

    SYSTEM DESIGN A typical LCD based display system utilizing this controller is likely to comprise the following: Summary: LCD panel LCD controller card, SGX-1920 LCD signal cable (use for LVDS panel) Inverter for backlight (if not built into LCD) Inverter cable...

  • Page 4: Assembly Notes

    ASSEMBLY NOTES This controller is designed for monitor and custom display projects using 1920x1200 or 1920x1080 or 1600x1200 or 1680x1050 or 1440x900 or 1366x768 or 1280 x 1024 or 1024 x 768 or 800x600 or 640x480 resolution TFT panels with a VGA, SVGA, WXGA, XGA, SXGA, UXGA or WUXGA signal input.
  • Page 5 22. HDMI audio output : Support HDMI audio with stereo output. The HDMI audio output can be connected to Audio add-on board P/N 416940020-3 by using the audio cable P/N 426451800-3 (310mm) connected between SGX-1920 (connector : CN10) and Audio add-on board P/N 416940020-3 (connector : CN2).
  • Page 6 inverter used. Normally, power supply with 3.5Amp current output should enough for most of 4x CCFT panels. Although the controller provides power regulation for the LCD power this does not relate to the power supplied to the backlight inverter. If an unregulated power supply is provided to an inverter any fluctuations in power may affect operation, performance and lifetime of the inverter and or backlight tubes.

  • Page 7: Connection And Operation

    10. Power supply & Controller: Plug the DC 12V/24V power in to the connector PP5 or PP2/3. You can consider to use DigitalView mating power cable P/N 426013800-3, 160mm for PP5 connection. 11. External panel power input : Plug power cable : P/N 426013700-3 for external panel power input (3.3 (max 7A) / 5V (max 7A) / 12V (max 5A) / 18V (max3.5))
  • Page 8 LCD DISPLAY SYSTEM SETTINGS NOTE: By way of explanation the following refers to a set of sample buttons that may be obtained as an option. In addition to power on/off and connection for backlight brightness the controller provides an On Screen Display of certain functions which are controlled by 5 momentary type buttons (analog VR type) or 8 momentary type buttons (digital type): Controls Analog VR type...
  • Page 9 OSD functions Picture : Volume Increase/decrease volume level, total: 100 steps Brightness Increase/decrease panel brightness level, total: 100 steps Contrast Increase/decrease panel contrast level, total: 100 steps Saturation Increase/decrease saturation, total: 100 steps Hue ** Increase/decrease Hue level, total: 100 steps Sharpness* Increase/decrease sharpness, total: 30 steps Backlight...
  • Page 10 Source : Select the input video signal Main Port Change 4 HDMI HD/SD SDI 1 HD/SD SDI 2 Composite 1 Composite 2*** S-Video 1 S-Video 2*** Component 1 Component 2*** PIP Port change4 PIP Off / Composite 1 / Composite 2*** / S-Video 1 / S-Video 2*** / Component 1 / Component 2*** / VGA / DVI / HDMI / HD/SD SDI 1...
  • Page 11 Composite 1 Composite 2 S-Video 1 S-Video 2 Component 1 Component 2 The corresponding input port name display on OSD menu will disappear once setting “OFF”. De-interlacing Mode* 4 : Auto Film Mode : Temporal Noise Reduction MADI : Motion Adaptive De-interlacing DCDi : Low Angled De-interlacing [See Appendix VI for AFM, TNR, MADI, DCDi function description]...
  • Page 12 Red Gain : Green Gain : Blue Gain : Red Offset : Green Offset : Blue Offset : Reset to Defaults : Resume to the default values 6500K Red Gain : Green Gain : Blue Gain : Red Offset : Green Offset : Blue Offset : Reset to Defaults : Resume to the default values...
  • Page 13 - B/L Control : D/A / PWM : Selection for voltage level dimming control / PWM dimming control - Backlight Frequency : 100 ~ 440Hz in a step of 20 - Light Detector : : Enable ambient light detector function by using KIT 70220-3 Default Setting 4 Reset to Factory Defaults 4 (Activate when JC1 position 4 sets open)

  • Page 14: Connectors, Pinouts & Jumpers

    CONNECTORS, PINOUTS & JUMPERS The various connectors are: Summary: Connectors Purpose Description Second RS-232 serial control JST 6-way, B6B-XH-A (Matching type : XHP-6) Reserved for factory use Reserved Panel control signal connector Hirose 10-pin, DF20G-10DP-1V (Matching type : DF20A-10DS-1C) Reserved for factory use Reserved No function Reserved...
  • Page 15 Ethernet for network connection RJ45 connector Panel signal for LVDS panel JAE FI-RE51S-HF (Matching type : FI-RE51HL) External panel power output Molex 53261-0871 (Matching type : 51021-0800) Infra-Red sensor connector JST 3-way, B3B-XH-A (Matching type : XHP-3) LED1 Dual color LED connector Header pin 3x1 VGA analog input DB-15 way high density 3 row...
  • Page 16 Summary: Jumpers setting Purpose Note On board +3.3V logic power enable 1-2 & 3-4 closed, factory set, do not remove Panel power voltage select See panel voltage setting table 1 CAUTION: Incorrect setting can damage panel Panel power voltage select See panel voltage setting table 1 CAUTION: Incorrect setting will cause panel damage...
  • Page 17 Table 1 : Panel voltage setting table : Input voltage via PP2/PP3, PP5 Panel Voltage Jumper on board 3.3V 3V3 closed 1-3 & 2-4 1-3 & 2-4 12VDC 5V closed 1-3 & 2-4 1-3 & 2-4 OPEN 1-3 & 2-4 5-7 &...
  • Page 18 Input voltage via Panel Voltage Jumper on board 3.3V OPEN 3-5 & 4-6 1-3 & 2-4 OPEN 3-5 & 4-6 1-3 & 2-4 3.3 / 5 / 12 / 18VDC* OPEN 3-5 & 4-6 3-5 & 4-6 OPEN 3-5 & 4-6 3-5 &...
  • Page 19 Table 2 : DIP Switch selection – SW3 Pos #1 Pos #2 Pos #3 Pos.#4 Description Panel resolution For WUXGA panels LG LM260WU1-SLB1 1920x1200 LG LM240WU2-SLA1 1920x1200 Sharp LQ445D3LZ19 1920x1080 Samsung LTA460H2-L02 1920x1080 Sharp LQ170M1LZ04 1920x1200 Samsung LTA700HH-LH1 (1 trial testing) 1920x1080 Samsung LTA700HH-LH1 (2 trial testing)
  • Page 20 Table 3 : DIP switch selection – SW4 Pos. # Function Description Reserved Panel pixel format OFF : Double Pixel ON : Single Pixel Panel selection ON : LVDS panel OFF : Reserved LVDS data mapping select If SW4 position 5 = OFF (8 bit) (Refer to Table 2) OFF : Mapping B ON : Mapping A...
  • Page 21 CN1 – Slave RS-232 serial control: JST B6B-XH-A (Matching type : XHP-6) SYMBOL DESCRIPTION SDATA Reserved SCLK Reserved RS-232 Tx data Ground RS-232 Rx data CN4 – Panel connector: HIROSE DF20G-10DP-1V (Matching type : DF20A-10DS-1C) SYMBOL DESCRIPTION Reserved Reserved Reserved Reserved Reserved Reserved...
  • Page 22 CNA2 - Auxiliary power output: JST B2B-PH-K (Matching type : PHR-2) SYMBOL DESCRIPTION Vcc_5V +5V DC, 500mA max with fuse Ground CNB1 – Backlight inverter connector: JST B5B-XH-A (Matching type : XHP-5) SYMBOL DESCRIPTION Ground VBKL +12V / +24V DC, backlight power supply BLCTRL On/Off control (enable) –...
  • Page 23 /RX0 TMDS Data 0- TMDS Data 1+ /RX1 TMDS Data 1- TMDS Data 2+ /RX2 TMDS Data 2- Ground (+5, Analog H/V Sync) Digital Ground EXT_MSTR2_SCL Reserved EXT_MSTR2_SDA Reserved DDC_5V +5V power supply for DDC (optional) Hot plug detect IN_SEC1_SCL DDC Clock IN_SEC1_SDA DDC Data...
  • Page 24 TXA3+ Positive differential LVDS data bit A3 TXA3- Negative differential LVDS data bit A3 Ground TXAC+ Positive LVDS clock for A channel TXAC- Negative LVDS clock for A channel Ground TXA2+ Positive differential LVDS data bit A2 TXA2- Negative differential LVDS data bit A2 TXA1+ Positive differential LVDS data bit A1 TXA1-...
  • Page 25 No connection DDC_CLK DDC Clock DDC_DAT DDC Data No connection /RX1 TMDS Data 1- TMDS Data 1+ Digital Ground No connection No connection DDC_5V +5V power supply for DDC (optional) Ground (+5, Analog H/V Sync) No connection /RX0 TMDS Data 0- TMDS Data 0+ Digital Ground No connection...

  • Page 26: Controller Dimensions

    Ready-made 3D Pro-E (SLDPRT) drawing files - Save time and effort for your system volumetric analysis design. Includes jpg file previews. Please go to download at http://www.digitalview.com/products/sgx-1920-lcd-controller The maximum thickness of the controller is 17.67mm with or without video add-on board (measured from bottom of PCB to top of components, including any underside components &...

  • Page 27: Application Notes

    APPLICATION NOTES USING THE CONTROLLER WITHOUT BUTTONS ATTACHED This is very straightforward: • Firstly setup the controller/display system with the buttons. With controls attached and display system active make any settings for colour, tint and image position as required then switch everything off. •...
  • Page 28 Design Guideline for making VR circuitry : Signal description / Notes : 1) R1 : 470ohm on board 2) RPOT is an external potentiometer (in-line dip style) that can be plugged directly into CNC1 pins 3,4,5. RPOT must be supplied / installed by user. 3) BVR_B : Voltage tapped from “top”...

  • Page 29: Troubleshooting

    TROUBLESHOOTING General A general guide to troubleshooting a flat panel display system it is worth considering the system as separate elements, such as: Controller (jumpers, PC settings) Panel (controller, cabling, connection, panel, PC settings) Backlight (inverter, cabling, backlight tubes) Cabling Computer system (display settings, operating system) Through step by step cross checking with instruction manuals and a process of elimination to isolate the problem it is usually possible to clearly identify the problem area.

  • Page 30: Specifications

    SPECIFICATIONS Panel compatibility Compatible with 1920x1200, 1920x1080, 1920x480, 1680x1050, 1600x1200, 1600x900, 1440x900, 1366x768, 1280x1024, 1280x800, 1280x768 1024x768, 1024x600, 800x600, 800x480 and 640x480 resolutions of TFT LCD panels. A specified BIOS and some factory adjustment may be required for individual panel timings.

  • Page 31: Appendix I - Signal Support Mode Table

    APPENDIX I – SIGNAL SUPPORT MODE TABLE ARGB (P1) PORT : Mode Resolution Clk [MHz] Horizontal Vertical Sync Mode freq [KHz] freq [Hz] T_70 720x400 28.322 31.469 70.087 Digital Separate Sync 70Hz T_70 720x400 28.322 31.469 70.087 Sync On Green 70Hz V_60 640x480...
  • Page 32 X_60 1024x768 65.000 48.363 60.004 Sync On Green 60Hz X_60 1024x768 65.000 48.363 60.004 Composite Sync 60Hz X_70 1024x768 75.000 56.476 70.069 Digital Separate Sync 70Hz X_70 1024x768 75.000 56.476 70.069 Sync On Green 70Hz X_70 1024x768 75.000 56.476 70.069 Composite Sync 70Hz X_75...
  • Page 33 COMPOSITE, S-VIDEO & COMPONENT VIDEO INPUT PORT : System Resolution Horizontal freq Vertical freq [KHz] [Hz] NTSC 720x480i 15.7 NTSC 4.43 720x480i 15.7 720x576i 15.6 PAL M 720x576i 15.6 SECAM 720x576i 15.6 HDMI / DVI / Auxiliary digital video (HD1&HD2) input port : Mode Resolution Clk [MHz] Horizontal...

  • Page 34: Appendix Ii - Rs-232 Control Protocols

    The RS-232 program can be custom-made to fit for application or it can be used the serial control program, like Accessport, Telix or Serial Utility program developed by DigitalView. Please contact your local support for information. Specifications subject to change without notice 34 of 70 ©...
  • Page 35 1. Commands to implement switch mount control buttons Function Command Description Remark Menu button 0xf7 Menu button pressed Button equivalent Select-down 0xfa Select-down button pressed Button equivalent button Select-up button 0xfb Select-up button pressed Button equivalent Right/+ button 0xfc Right/+ button pressed Button equivalent Left/- button 0xfd...
  • Page 36 nnnn | “+” | “-” | value/increment/decrement (In PC mode only) “?” Query Image V position 0x87, Set img_vpos = Image vertical position. nnnn | “+” | “-” | value/increment/decrement (In PC mode only) “?” Query Sharpness 0x8a, Set sharpness = Sharpness.
  • Page 37 “0” | “1” | Disable/ Enable “0x42,0x31”- Composite “?” | Query “0x42,0x32”- Composite 2 ”o” Valid Source query “0x43,0x31”- S-video “0x43,0x32”- S-video 2 “0x44,0x31”- Component “0x44,0x32”- Component 2 “0x45,0x31”- HDSDI “0x45,0x32”- HDSDI2 “0x46,0x31”- DVI “0x48,0x31” HDMI Source Layout 0x9a, Select source layout = Query: Single, PIP, PBP, PBPT “0”- Single...
  • Page 38 “E” – Aspect Ratio “G” – Hue “H” – Backlight “I” – Auto Picture Setup Hotkey 2 0xa0, “2”, Set Hotkey 2 = “1” – volume. value “2” – brightness. “r” | “R” | Reset “3” – contrast. “?” Query “4”...
  • Page 39 “r” | “R” | Reset Min : 0x30 0x30 0x30 0x30 “?” Query (Default) Max : 0x30 0x30 0x41 0x33 Zoom H position 0xa9, Set Zoom_hpos = Zoom window horizontal nnnn | “+” | “-” | value/increment/decrement position. “r” | “R” | Reset “?”...
  • Page 40 “m” Maximum query *1 “n” Minimum query *1 c – reference by Color “i” , ss, c, nn Set, Source, Temperature Temperature Group, value *1 ss - reference by Input main “o”, ss, c Query, Source *1 select(0x98) Green level for 0xb5, Set the level of the green Green level for selected colour...
  • Page 41 index mm. (If c= 3, then gamma data for red, green & blue will be set at the same time.) Query External 0xcb, “2” Check External Menory 24c256 “0” – Not Installed Memory “1” – Installed “?” – Not Support Query Revision 0xcb, “3”...
  • Page 42 320Hz : “1”,”4”,”0” 340Hz : “1”,”5”,”4” 360Hz : “1”,”6”,”8” 380Hz : “1”,”7”,”C” 400Hz : “1”,”9”,”0” 420Hz : “1”,”A”,”4” 440Hz : “1”,”B”,”8” Backlight Invert 0xe7 Set On or Off “0” – Off “0” | “1” | “1” – On “R” | “r” Reset ”?”...
  • Page 43 AspectMarker “0xee”, “0x44” Preliminary “0”- 4:3 “0” |”1” 4:3 /16:9 “1”- 16:9 Marker “0xee”, “0x45” Preliminary “0”- 0% Background “0” |”1” |”2” |”3” 0% /25%/50%/95% “1”- 25% Transparency “2”- 50% “3”- 95% Safe Area Marker* “0xee”, “0x47” Preliminary “36”, “33”- 99% “0x53”~”0x63”...
  • Page 44 e.g Clear Display Mark RS232 Code: “0xF1 0x43” Return Code: “0xF1 0x43 0x31” Display Mark 0xF1, “H” = “0x48 or 0x68” “H” – Horizontal Position command Horizontal |”H” |”ss”| ------------------------------------------ “ss” – Set Horizontal Position number Position Return “nn” “nn” = “0x30,0x30~0x46,0x46” “nn”...
  • Page 45 “F”,”1” DVI “H” “1” HDMI “xx,nn”= PIP input status: “0”,”0”: invalid “A”,”1” ARGB “B”,”1” Composite “B”,”2” Composite 2 “C”,”1” S-video “C”,”2” S-video 2 “D”,”1” Component “D”,”2” Component 2 “E”,”1” HDSDI “E”,”2” HDSDI 2 “F”,”1” DVI “H” “1” HDMI Video de-interlace 0xca, De-interlace mode “3”...
  • Page 46 “3”- 95% Safe Area Marker “0xee”, “0x46” Preliminary “36”, “33”- 98% “0x53”~”0x63” 64%~98% “36”, “32”- 96% “36”, “31”- 94% “36”, “30”- 92% “35”, “46”- 90% “35”, “45”- 88% “35”, “44”- 86% “35”, “43”- 84% “35”, “42”- 83% “35”, “41”- 81% “35”, “39”- 79% “35”, “38”- 77% “35”, “37”- 76%...
  • Page 47 The following commands for sending texts by using RS-232 command. Function Command Description Acknowledge (if enabled) Send Line 0xF0, “S” = “0x53 or 0x73” “S” – Send Command |”S” |”LL”|”TEXT”| Send command “LL” – Line Number “0x0A” ------------------------------------------- “Text” – Character Return “1”...
  • Page 48 Left offset 0xF0, “O” = “0x4F or 0x6F” “O” – Left Offset Command |”O” |”SSS”| Set Left Offset command “SSS”- Offset Value (pixels) Return “nnn” ------------------------------------------- “nnn”- Return Value(pixels) “SSS” = “0x30,0x30,0x30~ 0x33,0x46,0x46” Offset Value (Rang 000~3ff) e.g Set Left Offset = 100 pixels ( 0x64 (HEX)) RS232 Code: “0xF0 0x4F 0x30 0x36 0x34”...
  • Page 49 Display Mark Command Function Command Description Acknowledge (if enabled) Send Display Mark 0xF1, “S” – Send Command ”S” | “S” = “0x53 or 0x73” “Text” – Character ”0x21” | ”0x40” ASCII “0x21,0x40,0x60,0x7E” ”0x60” | ”0x7E” Return “1” Return “ 0x31” “1”...
  • Page 50 The RS-232 command strings sent in one time can support up to 380 bytes via CN8 port The RS-232 command string sent in one time can support up to 50 bytes via CN1 or J1 port. n = 1-byte ascii-coded hex number, e.g., parameter value of 0x1 is represented by “1” (0x31). mn or nn = 2-byte ascii-coded hex number, e.g., parameter value of 0x1e is represented by “1”, “e”...

  • Page 51: Appendix I - Mapping Definition

    Appendix I – Mapping definition • Definition of Mapping A : Specifications subject to change without notice 51 of 70 © Digital View Ltd – Doc Ver 1.7: 23 April, 2014 (SGX-1920_manual.doc) Page Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 52 • Definition of Mapping B : Specifications subject to change without notice 52 of 70 © Digital View Ltd – Doc Ver 1.7: 23 April, 2014 (SGX-1920_manual.doc) Page Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 53 • Definition of VESA : Specifications subject to change without notice 53 of 70 © Digital View Ltd – Doc Ver 1.7: 23 April, 2014 (SGX-1920_manual.doc) Page Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 54 • Definition of JEIDA : Specifications subject to change without notice 54 of 70 © Digital View Ltd – Doc Ver 1.7: 23 April, 2014 (SGX-1920_manual.doc) Page Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 55: Appendix Iv - Auto Color Gain

    The reference pattern can be downloaded at : http://www.digitalview.com/support/downloads/TestPattern_1280.BMP This reference pattern is for 1280x1024 resolution and it needs to set your ARGB input source to 1280x1024 resolution before performing the Auto Color Gain function. The position of the black vertical bar in the pattern at the right side is important.
  • Page 56 Appendix V – DV remote control unit work for SGX-1920 P/N 559000106-3 : DigitalView remote control unit (without DV logo silk screen printing) P/N 559000105-3 : DigitalView remote control unit (with DigitalView logo silk screen printing) BUTTON FUNCTION POWER BUTTON Soft power ON/OFF button.
  • Page 57 Appendix VI – Function description for de-interlacing mode AFM, TNR, MADI, DCDi AFM = Auto Film Mode : It is a frame based method which used for the input ODD and EVEN fields have a fixed relation between each other, such as static image, 3:2 pull down mode. If two fields are correctly merged, it can get the best quality.

  • Page 58: Appendix Viii - Network Connection

    Use the IP-50 IP Locator utility available from the IP-50 web-page. http://www.digitalview.com/media/downloads/IPLocator.zip (Windows only) • Double click on the IP address in the IP Locator window, it will open the SGX-1920 browser page in your default browser. Alternatively copy the IP address into your browser address line. •...
  • Page 59 Appendix IX – Digital Ports selection on SGX-1920 Port definition : P2 : DVI P3 : HDMI HD1 : Auxiliary digital input port HD2 : Auxiliary digital input port DVI-D – P2 HDMI – P3 Auxiliary digital input port - HD1 Auxiliary digital input port –...
  • Page 60 (1) SGX-1920 without connect any I C control on CN8 (i.e : HD-1000/-2000/-3000S/-3000) (i) The board allows the user to configure the digital signal path via P2, P3, HD1, HD2. Press and hold “MENU” button on the OSD switch mount and turn on the controller to enter the “Programming mode”.
  • Page 61 Digital signal path – Digital signal path – Auxiliary Port HD1 Auxiliary Port HD2 (iii) Choose the Auxiliary port HD1/HD2 configuration selection : Auxiliary port HD1 : 1. Set DVI Input from HD1 : Input DVI signal from HD1 port and disable P2 (DVI) port. 2.
  • Page 62 (2) SGX-1920 connect with HD-1000/-2000/-3000S via I C control on CN8 (i) The board allows the user to configure the digital signal path via P2, P3, HD1, HD2. Press and hold “MENU” button on the OSD switch mount and turn on the controller to enter the “Programming mode”.
  • Page 63 3. Set HDMI Input from P3 : Input DVI signal from P3 (HDMI) port and disable HD2 port. *** The controller will factory default to HD2 for digital signal coming from HD-1000/-2000/-3000S (3) SGX-1920 connect with HD-3000 via I C control on CN8 The controller will disable P2 (DVI) &...
  • Page 64 Appendix X - Inverter Interface Board P/N 416040010-3 [OPERATE UNDER 12VDC POWER INPUT ENVIRONMENT] The Inverter interface board provides interface to drive up the high current consumption panel inverter in excess of 3.5A. This board enables current of up to 8 Amps to be managed safely while retaining the capability for inverter dimming and management of the inverter enable signal according to VESA DPMS standards.
  • Page 65 Illustrated Diagram PP1 - 12VDC power supply – input, Power header 4 ways 0.156” pitch DESCRIPTION +12VDC +12VDC Ground Ground PP2 – Alternate 12VDC power supply – input, Terminal Block 2 poles DESCRIPTION +12VDC +12VDC Ground Ground PP3 – 12VDC power supply to controller – Output, Power header 2 ways, 0.156” pitch DESCRIPTION +12VDC Ground...
  • Page 66 CNB3 – Inverter interface to backlight inverter, JST B8B-XH-A SYMBOL DESCRIPTION VLCD12 Panel power VLCD12 Panel power Ground Ground VLCD12 Panel power BLCTRL Backlight on/off control signal BVR_WIP Backlight brightness VR pin WIP BVR_A Backlight brightness VR pin A Specifications subject to change without notice 66 of 70 ©...
  • Page 67 Appendix XI - Audio Add-on Board P/N 416940020-3 [OPERATE UNDER 12VDC POWER INPUT ENVIRONMENT] The Audio add-on board P/N 416940020-3 design for connection with DV controllers on the audio connector CN7. It provides audio input ports and output port for sound amplification. Electrical Specification : Supply Voltage : +12V, +5V Supply current : 35mA for +12V, 6mA for +5V...

  • Page 68: Mechanical Drawing

    CN3 : Controller interface connector Pin Number Description Left trimpot chip select Right trimpot chip select Trimpot serial data Trimpot serial clock Digital Ground +12V Audio input left Audio input right Audio Ground Mechanical Drawing : Specifications subject to change without notice 68 of 70 ©...

  • Page 69: Warranty

    TRADEMARKS The following are trademarks of Digital View Ltd: • Digital View • SGX-1920 Specifications subject to change without notice 69 of 70 © Digital View Ltd – Doc Ver 1.7: 23 April, 2014 (SGX-1920_manual.doc) Page Arrow.com.

  • Page 70: Contact Details

    Digital View Inc. 18440 Technology Drive Building 130 Morgan Hill, California, 95037 Tel: (1) 408-782 7773 Fax: (1) 408-782 7883 Sales: ussales@digitalview.com EUROPE Digital View Ltd. The Lake House Knebworth Park Herts, SG3 6PY Tel: +44-(0)20-7631-2150 Fax: Fax: +44-(0)20-7631-2156 Sales: uksales@digitalview.com...
