- Page 1 Bravo ® Air Fryer and Oven with Temperature Probe Owner’s Manual Model: 20801 / 20802 Rev.02 Questions or Concerns? Toll Free: 1-877-689-2838 • help@nuwavenow.com (Mon-Fri 7:30am-4:30pm CST)
- Page 2 PRODUCT REGISTRATION Thank you for purchasing the NuWave Bravo XL Oven and welcome to the NuWave Family! WELCOME Congratulations on getting your new Bravo XL! We are incredibly excited for you and want to make sure you get the most out of your new oven and your cooking experi- ence.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safeguards & Information ....................4-6 Power-Supply Cords......................6 Ordering Parts ........................6 Parts & Accessories ......................7 Assembly Guide ........................8 Before First Use........................8 Rack Positions ........................8 Getting Started ........................12-17 Key Features ........................12 Control Panel ........................12 Helpful Tips ..........................13 Primary Controls ........................14 Basic Key Functions ......................15 Using the Accessories ......................16 Selectable Cooking Time .....................16... -
Page 4: Safeguards & Information
18. It is normal for some smoke to escape the Bravo XL when heating for the first time. 19. If excess smoke is escaping from the air vent during operation, unplug the Bravo XL immediately and contact NuWave Customer Service at 1-877-689-2838 or email help@nuwavenow.com 20. - Page 5 SAFEGUARDS & INFORMATION ALWAYS KEEP THIS MANUAL HANDY FOR FUTURE REFERENCE. face away from these vents. Be careful of hot steam escaping when opening the Bravo 21. Avoid placing your face near the glass door during use. 22. Never touch the insides of the Bravo XL while it is operating. 23.
-
Page 6: Power-Supply Cords
ORDERING PARTS Over the lifetime of your Bravo XL, you may find yourself needing a new part or accessory, and if you do, NuWave has you covered. Ordering new parts and accessories is quick and easy. Simply take down the name and number for the part you want, then contact Customer Service. -
Page 7: Parts & Accessories
PARTS & ACCESSORIES Pull-Out Crumb Tray Base Part #: 26801 Part #: 26815 2 Heavy-Duty Handle Cooking Racks Part #: 26802 Digital Display Menu Enamel Baking Pan and Enamel Broiler Probe Input (Jack) Rack Part #: 26804 Temperature Probe Air Fry Basket Part #: 26808 Part #: 26806 Dial... -
Page 8: Assembly Guide
ASSEMBLY GUIDE Before First Use Remove and discard any packaging material from the unit. Remove all accessories from their packaging and wash them in warm, soapy water or in the dishwasher, top rack only, except for the Probe. NEVER submerge the main unit in water. -
Page 9: Key Features
PRODUCT FEATURES KEY FEATURES Air Fry Basket Wire Rack Control Panel Door Window Door Temperature Probe CONTROL PANEL 400F LED Display Cooking Function Menu Probe Jack START/PAUSE Dial Unit Function Buttons nuwavenow.com | 9... - Page 10 COOKING FUNCTIONS 12 Preprogrammed Cooking Functions Air Fry Pizza Automatic Preheat to 450F (232C) Automatic Preheats to 450F (232C) • Default Temp: 350F (177C) • Default Temp: 400F (204C) • Default Time: 15 min. • Default Time: 15 min. • Heat Source: High Fan (level 3) •...
- Page 11 COOKING FUNCTIONS Frozen Toast Automatic Preheats to 450F (232C) Automatic Preheats to 450F (232C) • Default Temp: 375F (191C) • Default Temp: 425F (218C) • Default Time: 30 min. • Default Time: 5 min. • Heat Source: Top/Bottom (100/100 • Heat Source: Top/Bottom (100/100 percent) percent) •...
-
Page 12: Selectable Cooking Time
TEMPERATURE CHARTS Probe Temperatures Oven Meats Rare Well Temp. Rare Well Chicken, breast Turkey, breast 165* Duck, breast Chicken, whole Turkey, whole 165* Duck, whole Chicken, thigh Turkey, thigh 165* Duck, thigh Steak 1" thick (25mm) 145* 150* 160* Burgers ½ lb (227g) 145* 155* 160*... - Page 13 UNIT FUNCTION BUTTONS ON/OFF Turns the Bravo ON and OFF. This also cancels any cooking function. ® MENU Accesses the 12 cooking functions (see pages 10–11). Turn START/PAUSE to select. PREHEAT Heats to a desired temperature. By default, the preheat temperature is set to 350F. TEMP/TIME Use START/PAUSE turn clockwise to increase, counterclockwise to decrease.
-
Page 14: Instructions
INSTRUCTIONS With its numerous Cooking Presets and features, the Bravo XL’s suite of unit and cooking functions offers you all you need to make delicious, healthy meals quickly and easily. Press ON/OFF once to turn your Bravo Setting the Clock Press PREHEAT and TEMP/TIME at the same time. - Page 15 INSTRUCTIONS WRM (WARM) TOP/BTM Default – Top 100%, Bottom 100%. This Press ON/OFF. refers to the amount of heat coming from the top and bottom heating elements. Press ON/OFF. 140F Press WRM/FAN. Default is 140F (60C) for 1 hour (“01:00”). •...
- Page 16 INSTRUCTIONS TEMP/TIME PREHEAT Default – 350F, 15 minutes Press ON/OFF. Adjust cooking temperature and cooking time. 00:15 Press TEMP/TIME once. • Turn the START/PAUSE dial • Turn START/PAUSE clockwise to clockwise to increase time in increase temperature in 5F (1C) 1-minute increments.
- Page 17 INSTRUCTIONS AUTO PREHEAT 4. Once delay countdown is complete, the Press PROG and PREHEAT at the Bravo will begin cooking at set cooking same time to turn on/off Auto Preheat. temperature and time (default is 350F • Auto Preheat will automatically (177C) for 15 minutes).
- Page 18 INSTRUCTIONS MENU SEAR: Default — 450F / 5 minutes. SEAR 1 450F This is set to default BEFORE the regular cooking stage. Press ON/OFF. Press SEAR once, 1 will be displayed. Press ON/OFF. Press START/PAUSE. SEAR 1 will be displayed, colon (:) will flash. Press MENU.
-
Page 19: Stage Cooking
INSTRUCTIONS SEAR 2 Press STAGE. • Press TEMP/TIME. Turn START/ PAUSE to adjust this stage’s cooking temperature and time. Press STAGE again to program another stage of cooking. 450F • Press TEMP/TIME. Turn START/ PAUSE to adjust this stage’s cooking temperature and time. - Page 20 INSTRUCTIONS Press PROG and TOP/BTM at the LOCK same time to set delay. Turn START/ Lock is used to stop the function of the PAUSE to adjust time to 1 hour Bravo. While in Lock mode, your Bravo’s (“01:00”). buttons will not respond to any action until the unit is unlocked.
- Page 21 INSTRUCTIONS • If Probe temperature was not reached Press ON/OFF. Adjust desired cooking after preset cooking time finished, temperature. the unit will continue cooking. To see Press and hold PROBE for 1 second. remaining cooking time, press TEMP/ Adjust the Probe temperature to the TIME twice (if not cooking within a timed desired internal cooked temperature.
- Page 22 INSTRUCTIONS TOAST When the temp reaches 110F, the Bravo will TOAST activates the TOAST menu function. beep for 10 minutes, or until deactivated. The default temperature is 425F, and the Place the bowl back into the Bravo and default TOP/BTM heat is 100/100. close the door and press START/PAUSE.
- Page 23 INSTRUCTIONS Turn START/PAUSE to choose your To View Current Program During desired program number to save the Cooking: program to (101-150). During cooking, press PROG. Press and hold the PROG button for The display will show the currently 1 second again to store and save running program for 1 second.
- Page 24 INSTRUCTIONS • Turn START/PAUSE to find the Adjusted temps and times will not be program number to save your edits. saved when a program number (1-100) • Press PROG for 1 second to save is recalled once again. and store the edits. Edit During Cooking: Carryover Cooking: •...
-
Page 25: Care & Maintenance
CARE & MAINTENANCE Before First Use: Never use steel wool pads, etc., on Wash all removable parts in warm, soapy interior or exterior of the Bravo. water or in the dishwasher, top rack only. NEVER HANDLE A HOT PIZZA Remove all the packaging materials. STONE. - Page 26 If the Bravo XL still fails to heat up, contact Customer Service. For further assistance, please contact NuWave’s Customer Service Department at 1-877-689-2838 (Mon–Fri 7:30am–4:30pm CST), or at help@nuwavenow.com .
-
Page 27: Error Messages
NTC Temperature Sensor short circuit. Contact Customer Service. Err2 NTC Temperature Sensor is open. Contact Customer Service. Err8 A button may be jammed. Contact Customer Service. For further assistance, please contact NuWave’s Customer Service Department at 1-877-689-2838 (Mon–Fri 7:30am–4:30pm CST), or at help@nuwavenow.com . nuwavenow.com | 27... -
Page 28: Limited Warranty
LIMITED WARRANTY THE MANUFACTURER WARRANTS NuWave, LLC warrants that Bravo XL will be free from manufacturer defects for 1 year from the date of purchase, under normal household use, and when operated in accordance with the Manufacturer’s written instructions. The Limited Warranty covers the Original Purchaser only. - Page 29 TION OR WARRANTY OF THE PRODUCT, PLEASE CONTACT NUWAVE LLC. DISPUTE RESOLUTION PROCEDURE For disputes relating to use of the website or use or purchase of a NuWave product or ser- vice (collectively “Disputes”), you agree to first contact NuWave LLC at (877) 689-2838, or legal@nuwavenow.com.
- Page 30 Para más información, vaya a www.P65Warnings.ca.gov READ YOUR OWNER’S MANUAL If you still have any questions about operation or warranty of this product, please contact NuWave LLC at 1-877-689-2838 (Mon–Fri 7:30am–4:30pm CST), or email help@nuwavenow.com. 30 | nuwavenow.com...
- Page 31 NOTES nuwavenow.com | 31...
- Page 32 Designed in France & Developed in USA NuWave LLC 560 Bunker Ct. Vernon Hills, IL 60061, U.S.A. Tel: 1-877-689-2838 Mon - Fri 7:30 am to 4:30 pm (CST) Email: help@nuwavenow.com Item No: BM20801-20802 Made in China CB-Rev.02 ©2022 NuWave LLC • All Rights Reserved. 10-10-22...
