5-Port VPN Security Router
VR-100 & VR-300 Series
Quick Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VR-100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Planet VR-100 Series

Summary of Contents for Planet VR-100 Series

  • Page 1 5-Port VPN Security Router VR-100 & VR-300 Series Quick Installation Guide...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1. Package Contents ..............3 Chapter 2. Hardware Installation ..............5 Wireless Antennas Installation SIM Card Installation 5G NR Antenna Installation Chapter 3. Setup of the VPN Router ............10 Requirements Logging in to the VPN Router Chapter 4.

  • Page 3: Chapter 1. Package Contents

    CHAPTER 1. PACKAGE CONTENTS Thank you for purchasing PLANET VPN Router, VR-100 or VR-300 Series. The descriptions of these models are as follows: VR-100 5-Port 10/100/1000T VPN Security Router VR-300 Enterprise 5-Port 10/100/1000T VPN Security Router Enterprise 4-Port 10/100/1000T 802.3at PoE + 1-Port...
  • Page 4 Open the box of the VPN Router and carefully unpack it. The box should contain the following items for each of the above models:  VPN Router x 1  Quick Installation Guide (QR code) x 1  Power Cord x 1 ...

  • Page 5: Chapter 2. Hardware Installation

    CHAPTER 2. HARDWARE INSTALLATION Refer to the illustration and follow the simple steps below to quickly install your VPN router. 2.1 Wireless Antennas Installation Step 1: For wireless models, fasten the 2.4G/5G antennas to the 2.4G/5G antenna connectors. And you can bend the antennas to fit your actual needs.
  • Page 6 The UTP Category 5e/6 network cabling with RJ45 tips is recommended. Step 5: Connect your VPN Router to internet. Connect one end of a standard network cable to the WAN port (port 5) on the front panel of the VPN router. Connect the other end of the cable to the xDSL/x PON modem/ONU LAN port or an upper layer port to outer network layer.

  • Page 8: Sim Card Installation

    2.2 SIM Card Installation For VR-300FW-NR only A. Insert an ejector pin into the yellow button next to the tray to loosen the tray. B. Pull out the tray gently from the tray slot. Place the SIM card on the tray with the gold-colored contacts facing upwards.

  • Page 9: Nr Antenna Installation

    2.3 5G NR Antenna Installation For VR-300FW-NR only Step 1: Connect 5G NR antennas to the 5G NR antenna extender.

  • Page 10: Chapter 3. Setup Of The Vpn Router

    CHAPTER 3. SETUP OF THE VPN ROUTER 3.1 Requirements Please confirm the following items before configuration: 1. Please confirm the network is working properly: It is strongly suggested to test your network connection by connecting your computer directly to ISP. 2.
  • Page 11 The DHCP server of the VPN Router is enabled. Therefore, the LAN PC will get IP from the VPN Router. If user needs to set IP address of LAN PC manually, please set the IP address within the range between 192.168.1.2 and 192.168.1.254 inclusively, and assigned the subnet mask of 255.255.255.0.
  • Page 12 Administrators are strongly suggested to change the default admin and password to ensure system security. Step 3. After entering the password, the main screen appears as shown in Figure 3-3. Figure 3-3: Web-based Main Screen of Cellular Gateway Now, you can use the Web management interface to continue the VPN Router management.

  • Page 13: Chapter 4. Recovering Back To Default Configuration

    CHAPTER 4. RECOVERING BACK TO DEFAULT CONFIGURATION  IP address has been changed or admin password has been forgotten To reset the IP address to the default IP address “192.168.1.1” or reset the login password to default value, press the hardware-based reset button on the front panel for about 10 seconds.

  • Page 14: Chapter 5. Appendix

    Default Login User Name admin Default Login Password admin Default DHCP Server Default LAN Port Ethernet Ports 1~4 Default WAN Port Ethernet Port 5 Default SSID (2.4G) PLANET 2.4G Default SSID (5G) PLANET_5G Appendix B: User’s Manual VR-100 VR-300 VR-300P VR-300W5 VR-300PW5 User’s...

  • Page 15: Chapter 6. Further Information

    CHAPTER 6. FURTHER INFORMATION Thank you for purchasing PLANET VPN Router. The above steps introduce the simple configuration of the VPN Router. If you have other questions, please contact the local dealer where you purchased this product or you can contact PLANET directly at the following email address: support@planet.com.tw.
