Code Description
8 Power loss
9 Undercurrent
10 Heat sink overtemperature
11 Motor connection
12 Input A trip
13 FLC too high
14 Unsupported option (function not available in inside delta)
15 Starter communication (between device and soft starter)
16 Network communication (between device and soft starter)
17 Internal fault
23 Parameter out of range
25 Bypass fail (bypass contactor)
26 L1 phase loss
27 L2 phase loss
28 L3 phase loss
29 L1-T1 shorted
30 L2-T2 shorted
31 L3-T3 shorted
33 Time-overcurrent (bypass overload)
35 Battery/clock
36 Thermistor circuit
28 | Danfoss A/S © 2022.11
Modbus Registers
MCD 201 MCD 202
x x
x x
x x
x
AN428736661763en-000101 / 175R1189
MCD 500
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
