7.5.1 Registers

Table 5: Description of Registers in Legacy Mode
Register Description
40001 Reserved
40002 Command (single write)
40003 Soft starter state
40004 Trip code
40005 Motor current
40006 Motor temperature
40007 Reserved
40008 Reserved
40009–40200 Parameter management (single or multi-
ple read/ write)
40600 Product information
Danfoss A/S © 2022.11
Bits Details
0–14 Reserved
15 Must be 0
0–2
To send a command to the starter, write the required value:
1 = Start
2 = Stop
3 = Reset
4 = Quick stop (coast to stop)
5 = Forced communication trip
6 = Start using Parameter Set 1
7 = Start using Parameter Set 2
3–15 Reserved
0–3
1 = Ready
2 = Starting
3 = Running
4 = Stopping (including braking)
5 = Restart delay (including temperature check)
6 = Tripped
7 = Programming mode
8 = Jog forward
9 = Jog reverse
4 1 = Positive phase sequence (only valid if bit 6 = 1)
5 1 = Current exceeds FLC
6
0 = Uninitialized
1 = Initialized
7–15 Reserved
0–7 See the chapter Trip Codes
8–15 Reserved
0–7 Average 3-phase motor current (A)
8–15 Reserved
0–7 Motor thermal model (%)
8–15 Reserved
0–7 Manage soft starter programmable parameters
8–15 Reserved
0–5 Binary protocol version
Modbus Registers
