Specifications - Array Solutions PowerMaster Series Manual

SPECIFICATIONS - Specifications subject to change without notice. ( Applies to 3 kW model, similar specs for 10KW)
Frequency Range
Line Impedance
Insertion Loss
Line Connections
Power Ranges
VSWR Range
Accuracy
Resolution
Peak Power Capture Time
VSWR Alarm Relay Actuation time
Bar Graph Response
VSWR Alarm
Low Power Monitor Alarm
High Power Monitor Alarm
Alarm Relay Contacts
Control
Power Required
Temperature of Operation
Regulatory Testing and Certification
Dimensions
Shipping Weight
PowerMaster Series RF Wattmeter
1.5 – 30MHz, 50-54 Mhz
50 ohms nominal, <1.05 V.S.W.R. insertion
.05 dB or less
SO-239 female (Type-N, and 7/16 DIN optional)
1 to 3,005 watts (3KW HF)
1 to 9,999 watts (10 KW HF) - Limited by VSWR to the limits of the connector
1.00 to 99.00
< ±3% as measured against NIST traceable calibrated instruments (see accuracy
section on how to achieve better accuracy)
10 Bit A/D – 4 overlapping channels of auto ranging = 12 Bit effective resolution
< 10 milliseconds
< 45 milliseconds
> 30Hz
Off, 1.5, 2.0, 2.5, 3.0 – relay programmable to open or close on trip
Off, 5, 50, 100, 250, 500, 1,000, 2,000 watts - NC and NO relay contacts are
available
Off, 175, 225, 700, 1,100, 1,600, 2,600, 3,000
.5 Ampere 50 volts AC/DC
Manual front panel (stand alone) or via RS232 – application software
12 - 15V DC at 600 ma
-35C to +25C
Exceeds FCC Class B (tested) and CE - both emissive and conductive (tested) as
well as EMP 4 KV and 8 KV on cables
Display 8 ¼" X 3 ½ "Face, 4 ¼" Deep
Coupler 2 ¾" X 2 ¾" X 6 ½"
5 lbs (2.3 kg)
Array Solutions Rev 3.5 Feb 20, 2007
25
