Pushing the menu button again takes us to the first menu item.
Pushing the menu button again takes us to the next menu.
PowerMaster Series RF Wattmeter
VSWR Bargraph Mode
Used to allow easy adjustment of a tuner for minimum VSWR.
Dip it for minimum VSWR.
VSWR Alarm Menu
Push the mode select button to select the VSWR alarm trip point:
Off
1.5
2.0
2.5
3.0
Push the mode select button to reset the
VSWR alarm and LED
Array Solutions
Rev 3.5 Feb 20, 2007
10
