- Page 1 Video Surveillance System with 2 Indoor/Outdoor Night Vision Cameras MODEL: SHS-2S © Copyright 2006 LOREX Technology Inc. Instruction Manual www.lorexcctv.com English Version 1.0...
- Page 2 Thank you for purchasing the SHS-2S. Lorex is committed to providing our customers with a high quality, reliable security product. The SHS-2S Video Surveillance System with 2 Indoor/Outdoor Night Vision Cameras is easy to set up (connects to any TV, VCR or Monitor) making this security system perfect for protecting your home, family and personal property.
-
Page 3: Important Safeguards
Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your video product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to assure your enjoyment and proper use of the video product and accessory equipment. - Page 4 Important Safeguards Service 13. Servicing - Do not attempt to service this video equipment yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 14. Conditions Requiring Service - Unplug this video product from the wall outlet and refer servicing to qualified service personnel under the following conditions.
-
Page 5: Fcc Class B Notice
4. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked 5. During lightning storms, or when the unit is not used for a long time, disconnect the power supply, antenna, and cables to protect the unit from electrical surge LOREX TECHNOLOGY INC. http://www.lorexcctv.com General Precautions... -
Page 6: Shs-2S Features
Sensor (Optional) • 2 Indoor/Outdoor Night Vision Color Cameras allow you to monitor multiple locations in and around your home with both video and audio * Functions with the addition of a Lorex PIR Accessory or PIR Camera - not included. -
Page 7: Table Of Contents
Camera Stand Installation: ... 13 Connecting Cameras ... 14 Connecting the SHS-2S A/V Cable ... 15 Connectivity Diagram ... 15 SHS-2S System Specifications - Appendix #1 ... 16 Control Box Specifications ... 16 Camera Specifications ... 16 Table of Contents... -
Page 8: Getting Started
Getting Started Getting Started The SHS-2S comes with the following components: 2 x Weatherproof Color Day/Night IR Cameras AV Cable CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM, INCLUDING ALL COMPONENTS SHOWN ABOVE. 2-Channel Camera Switcher 2 x 57’... -
Page 9: Shs-2S - Front View
SHS-2S - Front View 1. MULTICOLORED LED INDICATORS- Three LED indicators with different colors: • Green - Indicates the Power Status (On/OFF) • Yellow - Indicates the Alarm Status (Alarm Detected) • Orange - Indicates the Intercom Status (Intercom is ON/OFF) 2. - Page 10 OFF. NOTE: The PIR Functionality ONLY works with PIR Cameras or with the Camera PIR Accessory. Not included with the SHS-2S. 4. BUZZER ON/OFF - Turns the Alarm buzzer ON or OFF 5.
-
Page 11: Shs2S - Side View
3. ALARM TIME DURATION - Sets the Alarm Time Duration from 5 Seconds to 30 seconds by moving the switch left or right. SHS-2S - Rear View 1. CAM1 - CAM2 DIN INPUTS - Camera inputs (for cameras with 6 pin DIN connection). -
Page 12: Shs-2S Cameras
SHS-2S Cameras SHS-2S Cameras The SHS-2S switcher includes 2 CMOS Color IR Day/Night Indoor/Outdoor Cameras* INFRA-RED LEDs - Provides illumination for low light conditions CAMERA LENS MICROPHONE - Picks up sound near the camera and transmits to the SHS-2S switcher... -
Page 13: Camera Installation
Camera Installation Before you install the camera, carefully plan where and how you will position the camera, and where you will route the cable that connects the camera to the SHS-2S switcher. Installation Warnings: • Select a location for the camera that provides a clear view of the area you want to monitor, which is free from dust, and is not in line-of-sight to a strong light source or direct sunlight. -
Page 14: Connecting Cameras
2. Connect the male end of the supplied 57’ extension cable to an open camera input on the back of the SHS-2S switcher. Continue connecting additional DIN cameras. NOTE: The arrow on the DIN Camera should be facing up... -
Page 15: Connecting The Shs-2S A/V Cable
Connecting the SHS-2S A/V Cable Connecting the SHS-2S A/V Cable Connect the DIN end of the A/V Cable to the SHS-2S Switcher. Connect the RCA Video and Audio cables to the TV, VCR or Monitor. TV / VCR / MONITOR... -
Page 16: Shs-2S System Specifications - Appendix #1
SHS-2S System Specifications - Appendix #1 SHS-2S System Specifications - Appendix #1 Control Box Specifications Channels Alarm Time Scan Time Operating Voltage Camera Input AV Output Camera Specifications Image Sensor Input Voltage Lens Angle Resolution Minimum Illumination IR LEDs Operating Temperature... - Page 17 It’s all on the web Product Information User Manuals Quick Start Guides VISIT www.lorexcctv.com Strategic Vista International Inc. Specification Sheets Software Upgrades Firmware Upgrades wwwlorexcctv.com...
