Lorex SHS-2SA Quick Setup Manual

4. Switcher Specifications
Switcher Specifications:
Channels 2
Scan Time 1~30 Seconds
Operating Voltage 12V DC 500mA
Camera Input 2 DIN
AV Output 1 DIN
±
Power Supply DC 12V
90% HM Max.
Operating Humidity
°
Operating Temp 14 F ~ 122
°
(-10 ~ 50
Please refer to the Camera Spec Sheets posted
online at http://www.lorexcctv.com
details on individual Camera Specifications.
Dimensions:
WARNING – REGULATED 12V DC 500mA power supply
REQUIRED for use with this Switcher. Use of a non-regulated,
non-conforming power supply can damage this product and will
void the warranty.
It's all on the web
Product Information
User Manuals
Quick Start Guides
10% 500mA
°
F
°C)
for further
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2007 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
H O M E & B U S I N E S S S E C U R I T Y
2 CHANNEL MINI
SWITCHER BOX
WITH 2 COLOR CAMERAS
Model: SHS-2SA
Quick Set-up Guide
