Lorex SHS-2S6183W Quick Setup Manual

4. Specifications
Switcher Specifications:
Channels 2
Scan Time 1~30 Seconds
Operating Voltage 9V DC 300mA
Camera Input 2 DIN
AV Output 1 DIN
Power Supply DC 9V DC 300mA
90% HM Max.
Operating Humidity
°
Operating Temp 14 F ~ 122
°
(-10 ~ 50
Camera Specifications:
Image Sensor 1/4" Color CMOS
Video Format / Pixels NTSC: 510(H) x 492 (V)
Horizontal Resolution 330 TVL
Internal; 2:1 Interlace
Sync. & Scan. Systems
White Balance ATW
Shutter Speed 1/60 ~ 1/15,000 sec.
Iris AES
Minimum Illumination 3.0 LUX
Lens 3.6mm F2.0/ Fixed
FOV (Diagonal) 70 Degree
Termination Video/Audio/Power: 6-Pin
DIN Plug
IR / Night Vision Range 8 IR LED 850nm; 8ft. / 2.5m
Power Requirement 9V DC
Power Consumption Less than 130mA @ 9V DC
°
Operating Temp 14 F ~ 113
°
(-10 C ~ 45
Dimensions (with stand) 3.7" x 2.8" x 3.4"
(H x D x W) 95mm x 71mm x 34mm
Weight 200g / 7.05 oz.
It's all on the web
Product Information
User Manuals
Quick Start Guides
°
F
°C)
VISIT
www.lorexcctv.com
LOREX Technology Inc.
°
F Copyright © 2007 LOREX Technology Inc. As our
° )
C products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
H O M E & B U S I N E S S S E C U R I T Y
2 CHANNEL MINI
SWITCHER BOX
WITH 2 COLOR CAMERAS
Model: SHS-2S6183W
Quick Set-up Guide
