- Page 1 USER MANUAL OPEN FRAME TOUCH MONITOR OF-240P-A1 Rev 2072722.1...
-
Page 2: Table Of Contents
Table of Contents About This Document ................. 4 Compliance Information ................5 Important Safety Instructions ..............7 Usage Notice ....................... 7 Precautions ........................7 Warnings ........................9 Installation Tips ..................10 Product Overview ..................11 Key Features ......................11 Unpacking ........................11 Package Contents ..................... - Page 3 Appendix ....................32 Cleaning ........................32 Solutions to Common Problems ................33 Warranty Information ....................35 RoHS Declaration ...................... 36...
-
Page 4: About This Document
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of MicroTouch a TES Company. -
Page 5: Compliance Information
Compliance Information For FCC (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 6 Renseighements relatifs à la conformité Pour la FCC (États-Unis) Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe B selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
-
Page 7: Important Safety Instructions
Important Safety Instructions Before using this monitor, please read the user manual thoroughly to help protect against property damage and to ensure your personal safety and the safety of others. Be sure to observe the following instructions. For installation or adjustment, please follow the instructions in this manual and refer all servicing to qualified service personnel. - Page 8 Avis d’utilization Mise en garde Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à la terre. Précautions Veuillez suivre toutes les mises en garde, précautions et entretiens recommandés dans ce manuel d’utilisation pour maximiser la durée de vie de votre unité.
-
Page 9: Warnings
Warnings To turn off monitor power, press “Power” on the OSD wired remote. When turning off the monitor by pressing the POWER button on the OSD wired remote, the main power of the monitor is not turned off completely. To disconnect power completely, remove the power plug from the outlet. -
Page 10: Installation Tips
Installation Tips No Touch Screen Drivers Required MicroTouch Touch Monitors are plug and play when connected to Windows 7 or later Windows devices; Kernel 3.2 for most builds of Linux; Android 1.0 and most other modern Operating Systems. If you have a non-Plug and Play operating system, please refer to the Technical Support Section of www.microtouch.com or contact MicroTouch Technical Support to inquire about driver support for your... -
Page 11: Product Overview
Product Overview This product is a commercial grade wide format open frame touch monitor solution that is particularly well suited for point-of-sales, point-of-information, point-of-service and interactive signage applications. Designed for kiosk installations, it incorporates a rugged, tapered, high-density closed-cell foam gasket surround that compresses on installation , resulting in an attractive sealed finish. -
Page 12: Package Contents
Package Contents Part Picture LCD Monitor AC Power Cord IEC C13 (1.8m) AC-DC converter VGA cable (1.8m) DP (Display Port) cable (1.8m) HDMI cable (1.8m) USB A-B CABLE (1.8m) 6 sets, Brackets 2 per set OSD Wired Remote... -
Page 13: Product Setup And Use
Product Setup and Use Input/Output Connectors Audio Output AUDIO: A standard PC audio jack supplies audio output if a digital video/audio input cable (HDMI or DP) is in use. This audio output is intended to supply a speaker that has amplification and volume control. -
Page 14: Configuration And Cable Options
Configuration and Cable Options A cable management bracket, outlined in red below, is attached to the back of the monitor: It has five cable slots and a central opening below, centered. The bracket, attached by a single screw, can be removed if desired to facilitate cable connections, then reattached. The slots can hold smaller diameter cables;... -
Page 15: Turning Monitor On And Off
Turning Monitor On and Off Connect the monitor to DC power. The monitor should come on within 10 seconds. If the monitor does not come on within 10 seconds, press the power button on the OSD wired remote. The monitor should power on within 5 seconds. When the monitor is on, pressing the Power button will open a pop-up that asks, “Do you want to turn off?”... -
Page 16: On-Screen Display (Osd)
On-Screen Display (OSD) The open frame monitor series requires that the wired remote be connected to make changes to the video or touch settings and to turn the monitor on and off. Controls and options are detailed below. Button Normal Video Display When OSD Menu is Displayed MENU Activate the main menu... -
Page 17: Locking The Osd And Power Button Functions
Locking the OSD and Power button functions Lock OSD prevents all the monitor settings from being changed. When this function is activated, all OSD controls and hotkey operations will be disabled except for the Power button. Lock Power button Prevents monitor from being turned off by the Power button. The monitor can be powered off by disconnecting from power;... -
Page 18: Using The Osd Menus
Using the OSD Menus Navigating through the Menu System With the power on, press MENU and the on-screen menu will pop up. Within the menu, use , and SELECT to navigate through the menus and adjust options. Press MENU to return to the previous menu or exit the OSD menu The OSD menu will automatically close if left idle for a pre-set time. - Page 19 Picture Menu This menu is used for making common image adjustments. Note that some of the adjustments may be grayed out, indicating that they are not selectable. This indicates the use of a digital video input signal (DP, HDMI or USB Type-C). These selections are fixed/not adjustable for digital video signals. The VGA video signal (because it is analog) may require all adjustments, so they are all selectable when VGA is being used.
- Page 20 V-Position Adjust the vertical position of the picture. Press or to select the desired level, and then press SELECT. Selectable only when VGA input is in use. Range: 0-100 Phase Adjust the pixel phase of the picture. Press or to select the desired level, and then press SELECT.
- Page 21 Advanced Menu This menu is used to adjust color temperature and image sharpness. Color Temp Select the color temperature Options: 5500K, 6500K, 7500K, 9300K, User Adjust the amount of red in color content Range: 0-100 Green Adjust the amount of green in color content Range: 0-100 Blue Adjust the amount of blue in color content...
- Page 22 OSD Menu This menu is used to make set-up adjustments to the OSD itself, as well as other on-screen messages. OSD Timeout Adjusts the time in seconds before the OSD menu disappears after no usage. Range: 0-60 sec OSD Position Selects the OSD Position (center or corners).
- Page 23 Touch Switch Adjusts the sensitivity of the touch function. Press or to select any of the three sensitivities, then press SELECT. Normal: Standard touch sensitivity, up to 10 simultaneous touch points. Glove: Increases touch sensitivity for use with or without cotton or similar gloves; up to 10 simultaneous touch points.
- Page 24 Option Menu This menu is used select or display various functions. Reset Restore the factory default settings. Options: Yes, No Language Select the OSD language Options: English, French, Deutsch, Italian, Spanish, Japanese, Traditional Chinese and Simplified Chinese Source Select Select the Video Input Source Options: Auto, VGA, HDMI, DP Display Mode Display the current video source and resolution information.
-
Page 25: Osd Default Settings
OSD Default Settings Note: N/A applies when a digital video input (DP or HDMI) is in use Menu Parameter Default Settings Contrast Brightness H-Positon Picture V-Positon Phase Clock Auto Adjust Color Temp User Advanced Sharpness OSD Timeout OSD Positon User OSD H-Positon OSD V-Positon Touch Switch... -
Page 26: Mounting Options
Mounting options The monitor is commonly mounted to a cross bar in an enclosure, the crossbar having a 100mm x 100mm standard VESA mount hole pattern. It may also be panel mounted using the included bracketry. A tapered foam surround gasket, thinner at the rear than at the front, compresses as the monitor is pushed into the front of the panel opening. -
Page 27: Bracket Mounting
Bracket Mounting The included MicroTouch bracket kit OF-BRKT-24A can be used to flush-mount the monitor in a panel. The kit includes six smaller monitor brackets and six larger slotted panel-mount brackets. Two of the smaller brackets are mounted to the sides of the monitor and the other four of the smaller brackets are mounted to the top and bottom of the monitor using the included screws. - Page 28 Press-in threaded M4 Stud Method The studs should be pressed into the back of the panel. The brackets slip onto the studs using the through-holes in the brackets. Nuts (not included/customer supplied) secure the brackets to the back of the panel. Threaded M4 holes in thick panel method Holes are drilled into the back of the panel, stopping short of the panel front to preserve invisibility.
-
Page 29: Specifications And Dimensions
Specifications and Dimensions Specifications Item Category Specifications 23.8” TFT LCD Size Resolution 1920 x 1080 Brightness (typical) 215 cd/m2 LCD Panel Contrast Ratio (typical) 3000:1 Number of Colors 16.7 million Viewing Angle (typical) Horizontal: 178 degrees; Vertical: 178 degrees Touch Type P-CAP Touch Screen Simultaneous touch points... -
Page 30: Supported Timings
Supported Timings Polarity Mode Resolution H-Freq. (KHz) Bandwidth (MHz) 720 x 400 @ 70Hz 31.47 28.322 640 x 480 @ 60Hz 31.47 25.175 640 x 480 @ 66Hz 32.24 640 x 480 @ 72Hz 37.86 31.5 640 x 480 @ 75Hz 37.5 31.5 800 x 600 @ 56Hz... -
Page 31: Dimensions
Dimensions Front view Side View... -
Page 32: Appendix
Appendix Cleaning Turn off the product and disconnect from AC power before cleaning. Turning the product off protects against accidental touch selections that could cause problems or hazardous results. Disconnecting power protects against hazardous interaction between accidental liquid entry and electricity. To clean the case, dampen a clean cloth lightly with water and a mild detergent and wipe gently. -
Page 33: Solutions To Common Problems
Check that the DC power connector is fully seated. Check that the AC cable is securely connected to the wall outlet and to the AC to DC converter. Make sure the MicroTouch power converter is being used. Try another MicroTouch-approved power converter if possible. - Page 34 Neither the OSD nor power buttons respond when pressed. See the Lock/Unlock section to check if both functions are locked. If the wired OSD remote is in use, make sure it is securely connected.
-
Page 35: Warranty Information
Warranty Information Except as otherwise stated herein, or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchscreen display and their components is three years. Seller makes no warranty regarding the model life of components. -
Page 36: Rohs Declaration
RoHS Declaration Type designation (Type) ： Equipment name：Touch LCD Monitor OF-240P-A1 Restricted substances and their chemical symbols Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (PBDE) (PBB) ○ ○ ○ ○ ○ ○ Plastic Parts －... - Page 37 TES AMERICA LLC | 215 Central Avenue, Holland, MI 49423 | (616) 786-5353 The information presented in this document is intended as general information about MicroTouch products and is subject to change. Product specifications and warranties will be governed by TES America, LLC. Standard terms and conditions of sale. Products are subject to availability.
