- Page 1 User Manual SK-156P-A1 Slimline Kiosk Touch Monitor...
- Page 2 MicroTouch a TES Company. The information in this document is subject to change without notice. MicroTouch TES Company makes no representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
- Page 3 Compliance Information For FCC (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 4 Renseignements relatifs à la conformité Pour la FCC (États-Unis). Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe B selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
- Page 5 Usage Notice Warning - To prevent the risk of fire or shock hazards, and do not expose the product to moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Warning - Power cord shall be connected to a socket-outlet with earthing connection.
- Page 6 Avis d’utilisation Mise en garde — Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde — Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde – Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à...
-
Page 7: Table Of Contents
Table of Contents Chapter 1 ........................7 1.1 Overview ........................8 1.2 Feature ........................8 1.3 Specifications ......................8 1.4 Block Diagram......................9 1.5 Interface Connectors ....................10 1.5.1 Power Connector ..................... 10 1.5.2 Video Signal Connector ................... 10 1.5.3 Signal Connector ....................12 1.6 Package Overview .................... -
Page 8: Chapter 1
Chapter 1 Product Introduction... -
Page 9: Overview
1.1 Overview The SK-156P-A1 series is a 15.6” touchscreen monitor that builds to withstand commercial grade open frame monitor, with stylish thin cable management bracket and versatile design SK-156P-A1 is an exceptional choice for applications for all business sectors and well suited for point-of-sales, point-of-information, point-of-service and interactive signage. -
Page 10: Block Diagram
1.4 Block Diagram For TF1634MC-B7X, T1634MC-B7X, TF1634MC-B8X, T1634MC-B8X... -
Page 11: Interface Connectors
1.5 Interface Connectors 1.5.1 Power Connector The AC/DC converter shall have an IEC320 type male power receptacle for connection to AC mains power. The power cord, exact type to be supplied in the appropriate Option Kit, shall be length of 1.8 0.05 meters, and PC99 compliant. 1.5.2 Video Signal Connector The video signal input via D-type 15-pin female connector. - Page 12 DVI-D Signal Signal TMDS Data 2- TMDS 3+ TMDS Data 2+ +5V DDC Power TMDS Data 2/4 Shield Gnd (+5, Analog V/H Sync) TMDS 4- Hot Plug Detect TMDS 4+ TMDS Data 0- DDC Clock TMDS Data 0+ DDC Data TMDS Data 0/5 Shield No Connection TMDS Data 5-...
-
Page 13: Signal Connector
ML_Lane 2(n) Data 1 - DP_PWR Return ML_Lane 3(p) Data0 + DP_PWR HDMI(1.3) (compatible with HDMI1.4) Signal Signal TMDS Data2+ TMDS Clock Shield TMDS Data2 Shield TMDS Clock– TMDS Data2– TMDS Data1+ Reserved (N.C. on device) TMDS Data1 Shield TMDS Data1– TMDS Data0+ DDC/CEC Ground TMDS Data0 Shield... - Page 14 RJ11 Connector (for Remote Key) (option) Signal Signal MENU SELECT POWER DOWN...
-
Page 15: Package Overview
1.6 Package Overview LCD Display Power Cord DC Power Supply USB cable or USB C-A VGA cable DVI cable cable HDMI cable DP cable... - Page 16 12Vdc, 2A minimum, Tma = 40 degree C minimum, and the altitude of operation = 3048m minimum. If it needs further assistance with purchasing the power source, please contact to MicroTouch for further information. Mise en garde! Cet appareil est conçu avec une alimentation de courant CA, d’une tension nominale de 12Vdc, 2A minimum, Tma = 40 degrés C minimum et l’altitude de...
-
Page 17: Chapter 2
Chapter 2 Product Installation... -
Page 18: About Vesa Mount
2.1 About VESA Mount The SK-156P-A1 series conform to the “VESA Flat Display Mounting Interface Standard” which defines a physical mounting interface for touch monitor, and corresponding with the standards of touch monitor mounting devices. The VESA mount is located on the back of this unit. -
Page 19: On-Screen Display
2.2 On-Screen Display Old OSD Menu off status Menu on status Menu appear Menu disappear/ return to main item MENU ▲ Brightness Main item select up/ Adjust up ▼ Contrast Main item select down/ Adjust down Enter/Select sub-item function SELECT Power On/Off Press the “MENU”... - Page 20 When the OSD Lock function is selected, this indicates that all the buttons except “power” button are now disabled. When the Power Lock function is selected, this indicates that the power key is disabled; user can not to turn off the monitor by "Power" key. To disable the touch function, press “Menu”...
- Page 21 New OSD Menu off status Menu on status Menu appear Menu disappear/ return to main item MENU ▲ Brightness Main item select up/ Adjust up ▼ Contrast Main item select down/ Adjust down Source select Enter/Select sub-item function SELECT Power On/Off 1.
- Page 22 Press and keep pressing “Select” key for 3 seconds, will change to pop up “source select” OSD. Sleep status: Press and keep pressing “Select” key for 1 seconds, will change to pop up “source select” OSD. Please note: When choosing VGA, only VGA signal can wake up monitor. When choosing HDMI, only HDMI can wake up the monitor.
-
Page 23: Osd Function Description
2.2.1 OSD Function Description Item Content Default Contrast The monitor luminance level control. T1634MC-B8X / Brightness The monitor backlight level control. TF1634MC-B8X:75 Other:100 Fine-tune the image to full screen Auto Adjust automatically. Moving screen image horizontal position Left/Right to left or right. Moving screen image vertical position to Up/Down up or down. -
Page 24: Timing Table Chart
2.2.2 Timing Table Chart Polarity H-Freq. Band Width Mode Resolution (KHz) (MHz) 640x480 60Hz 31.47 25.175 800x600 60Hz 37.88 1024x768 60Hz 48.36 1280x1024 60Hz 1280x960 60Hz 1366x768 60Hz 47.7 85.38 1440x900 60Hz 106.5 1680x1050 60Hz 65.2 1920x1080 60Hz 67.5 148.5 Note: If input H-display >... -
Page 25: Dimension
2.3 Dimension 2.3.1 Front View 2.3.2 Side View... -
Page 26: Rear View
2.3.3 Rear View... -
Page 27: Appendix
Appendix... - Page 28 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：觸控螢幕 型號（型式）：SK-156P-A1 Type designation (Type) ：SK-156P-A1 Equipment name：Touch LCD Monitor 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Cadmium Hexavalent Polybrominated Polybrominated Lead...
