- Page 1 USER MANUAL MEDICAL GRADE TOUCH MONITOR DT-170P-M1 Rev 2 April 2022...
-
Page 2: Table Of Contents
Table of Contents About This Document ................. 4 Compliance Information ................5 Important Safety Instructions ..............7 Usage Notice ....................... 7 Precautions ........................7 Installation Tips ..................10 Product Overview ..................11 Key Features ......................11 Unpacking ........................11 Package Contents ..................... 12 Product Setup and Use ................ - Page 3 Appendix ....................29 Cleaning ........................29 Solutions to Common Problems ................30 Warranty Information ....................31 RoHS Declaration ...................... 32...
-
Page 4: About This Document
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of MicroTouch a TES Company. -
Page 5: Compliance Information
Compliance Information For FCC (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 6 Renseighements relatifs à la conformité Pour la FCC (États-Unis) Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe B selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
-
Page 7: Important Safety Instructions
Important Safety Instructions Before using this monitor, please read the user manual thoroughly to help protect against property damage and to ensure your personal safety and the safety of others. Be sure to observe the following instructions. For installation or adjustment, please follow the instructions in this manual and refer all servicing to qualified service personnel. - Page 8 Avis d’utilization Mise en garde Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à la terre. Précautions Veuillez suivre toutes les mises en garde, précautions et entretiens recommandés dans ce manuel d’utilisation pour maximiser la durée de vie de votre unité.
- Page 9 Warnings To turn off monitor power, press “Power” on the OSD (On-Screen Display) keypad on the right rear side of the monitor or on the optional wired remote if it is connected. When turning off the monitor by pressing the POWER button, the main power of the monitor is not turned off completely.
-
Page 10: Installation Tips
Installation Tips No Touch Screen Drivers Required MicroTouch Touch Monitors are plug and play when connected to Windows 7 or later Windows devices; Kernel 3.2 for most builds of Linux; Android 1.0 and most other modern Operating Systems. If you have a non-Plug and Play operating system, please refer to the Technical Support Section of www.microtouch.com or contact MicroTouch Technical Support to inquire about driver support for your... -
Page 11: Product Overview
Product Overview This medical grade desktop monitor is a standard format medical-grade monitor perfect for a wide range of healthcare applications. Key Features Size: 17” TFT LCD Resolution: 1280 x 1024 Contrast Ratio: 1000:1 Aspect Ratio: 5:4 Brightness: 297 cd/m View Angle: H: 170, V: 160 Video Port: 1 VGA (DB15), 1 HDMI, 1 DP 100 mm x 100 mm VESA mount... -
Page 12: Package Contents
Package Contents Part Picture LCD Monitor AC Power Cord IEC C15/C16 (1.8m) AC-dc adapter HDMI Cable (1.8 m) VGA cable (1.8 m) USB A-B CABLE (1.8 m) Stand Cable Cover and Screw... -
Page 13: Product Setup And Use
Product Setup and Use Input and Output Connectors Power Connector 12 VDC: Power connector (Center pin: + 12 volts DC; Barrel: ground). Video Signal Input Connectors DP (Display Port): Digital video input. HDMI: Digital video input. VGA: Analog video input. Optional OSD Remote Connector RJ11: Connector for the on-screen display (OSD) remote controller, which is used to access the on- screen display menu to select the various options, and to turn the monitor on/off. -
Page 14: Turning Monitor On And Off
Turning Monitor On and Off Turning the monitor On Connect the monitor to DC power. If the monitor does not come on within a few seconds, press the power button on the OSD keypad or the optional OSD wired remote. When the monitor is on, pressing the Power button will open a pop-up that asks if the monitor is to be turned off. -
Page 15: On-Screen Display (Osd)
On-Screen Display (OSD) This monitor series provides OSD controls on the right rear side of the monitor, as viewed from the front, as outlined in red below. An optional wired OSD remote is also available. Button Normal Video Display When OSD Menu is Displayed MENU Activate the main menu Exit selection / Exit OSD... -
Page 16: Locking The Osd And Power Button Functions
Locking the OSD and Power button functions Lock OSD prevents all the monitor settings from being changed. When this function is activated, all OSD controls and hotkey operations will be disabled except for the Power button. Lock Power button Prevents monitor from being turned off by the Power button. The monitor will power on automatically when power is applied. - Page 17 Picture Menu This menu is used for making common image adjustments. Note that some of the adjustments may be grayed out, indicating that they are not selectable. This indicates the use of a digital video input signal (DP, HDMI or USB Type-C). These selections are fixed/not adjustable for digital video signals. The VGA video signal (because it is analog) may require all adjustments, so they are all selectable when VGA is being used.
- Page 18 V-Position Adjust the vertical position of the picture. Press or to select the desired level, and then press SELECT. Selectable only when VGA input is in use. Range: 0-100 Phase Adjust the pixel phase of the picture. Press or to select the desired level, and then press SELECT.
- Page 19 Advanced Menu This menu is used to adjust color temperature and image sharpness. Color Temp Select the color temperature Options: 5500K, 6500K, 7500K, 9300K, User Adjust the amount of red in color content Range: 0-100 Green Adjust the amount of green in color content Range: 0-100 Blue Adjust the amount of blue in color content...
- Page 20 OSD Menu This menu is used to make set-up adjustments to the OSD itself, as well as other on-screen messages. OSD Timeout Adjusts the time in seconds before the OSD menu disappears after no usage. Range: 0-60 sec OSD Position Selects the OSD Position (center or corners).
- Page 21 Option Menu This menu is used select or display various functions. Reset Restore the factory default settings. Options: Yes, No Language Select the OSD language Options: English, French, Deutsch, Italian, Spanish, Japanese, Traditional Chinese and Simplified Chinese Source Select Select the Video Input Source Options: Auto, VGA, HDMI, DP Display Mode Display the current video source and resolution information.
-
Page 22: Osd Default Settings
OSD Default Settings Note: N/A applies when a digital video input (DP or HDMI) is in use Menu Parameter Default Settings Contrast Brightness H-Positon Picture V-Positon Phase Clock Auto Adjust Color Temp User Advanced Sharpness OSD Timeout OSD Positon User OSD H-Positon OSD V-Positon Reset... -
Page 23: Mounting Options
Mounting options The monitor may be mounted to a stand or other device that has a 100mm x 100mm standard VESA mount hole pattern. VESA Mount The monitor has an integral VESA standard mount pattern that conforms to the “VESA Flat Display Mounting Interface Standard”... -
Page 24: Stand Mount
Stand Mount This monitor may be mounted to a stand using the VESA mount pattern. A MicroTouch optional stand is recommended – see the Accessories section of the MicroTouch web site. -
Page 25: Specifications And Dimensions
Specifications and Dimensions Specifications Item Category Specifications 17” TFT LCD Size Resolution 1280 x 1024 Brightness (typical) 297 cd/m2 LCD Panel Contrast Ratio (typical) 1000 Number of Colors 16.7 million Viewing Angle (typical) Horizontal: 170 degrees; Vertical: 160 degrees Touch Type P-CAP Touch Screen Simultaneous touch points... -
Page 26: Supported Timings
Supported Timings Polarity Mode Resolution H-Freq. (KHz) Bandwidth (MHz) － ＋ 720 x 400 @ 70 Hz 31.47 28.322 － － 640 x 480 @ 60 Hz 31.47 25.175 － － 640 x 480 @ 66 Hz 30.24 － － 640 x 480 @ 72 H) 37.86... -
Page 27: Dimensions
Dimensions Front view Side View... - Page 28 Rear View...
-
Page 29: Appendix
Appendix Cleaning Turn off the product and disconnect from AC power before cleaning. Turning the product off protects against accidental touch selections that could cause problems or hazardous results. Disconnecting power protects against hazardous interaction between accidental liquid entry and electricity. To clean the case, dampen a clean cloth lightly with water and a mild detergent and wipe gently. -
Page 30: Solutions To Common Problems
Check that the DC power connector is fully seated. Check that the AC cable is securely connected to the wall outlet and to the AC to DC converter. Make sure the MicroTouch power converter is being used. Try another MicroTouch-approved power converter if possible. -
Page 31: Warranty Information
Warranty Information Except as otherwise stated herein, or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchscreen display and their components is three years. Seller makes no warranty regarding the model life of components. -
Page 32: Rohs Declaration
RoHS Declaration Type designation (Type) ： Equipment name：Touch LCD Monitor DT-170P-M1 Restricted substances and their chemical symbols Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (PBDE) (PBB) ○ ○ ○ ○ ○ ○ Plastic Parts ○... - Page 33 TES AMERICA LLC | 215 Central Avenue, Holland, MI 49423 | (616) 786-5353 The information presented in this user manual is intended as general information about MicroTouch products and is subject to change. Product specifications and warranties will be governed by TES America, LLC. Standard terms and conditions of sale. Products are subject to availability.
