- Page 1 USER MANUAL DIGITAL SIGNAGE TOUCH MONITOR M1-156DT-A1 M1-215DT-A1 M1-238DT-A1 Rev 1091922.1...
-
Page 2: Table Of Contents
Table of Contents About This Document ..................... 4 Compliance Information ..................5 Important Safety Instructions ................. 7 Usage Notice ....................... 7 Precautions ........................7 Warnings ........................9 Installation Tips ...................... 10 Product Overview ....................11 Key Features ......................11 Unpacking ........................11 Package Contents ..................... - Page 3 Appendix ......................... 32 Cleaning ........................32 Solutions to Common Problems ................33 Warranty Information ....................35 RoHS Declaration ...................... 36...
-
Page 4: About This Document
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of MicroTouch a TES Company. -
Page 5: Compliance Information
Compliance Information For FCC (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 6 Renseighements relatifs à la conformité Pour la FCC (États-Unis) Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe B selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
-
Page 7: Important Safety Instructions
Important Safety Instructions Before using this monitor, please read the user manual thoroughly to help protect against property damage and to ensure your personal safety and the safety of others. Be sure to observe the following instructions. For installation or adjustment, please follow the instructions in this manual and refer all servicing to qualified service personnel. - Page 8 Avis d’utilization Mise en garde Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à la terre. Précautions Veuillez suivre toutes les mises en garde, précautions et entretiens recommandés dans ce manuel d’utilisation pour maximiser la durée de vie de votre unité.
-
Page 9: Warnings
Warnings To turn off monitor power, press the “Power” button on the OSD keypad. When turning off the monitor by pressing the POWER button on the OSD wired remote, the main power of the monitor is not turned off completely. To disconnect power completely, remove the power plug from the outlet. -
Page 10: Installation Tips
Installation Tips No Touch Screen Drivers Required MicroTouch Touch Monitors are plug and play when connected to Windows 7 or later Windows devices; Kernel 3.2 for most builds of Linux; Android 1.0 and most other modern Operating Systems. If you have a non-Plug and Play operating system, please refer to the Technical Support Section of www.microtouch.com or contact MicroTouch Technical Support to inquire about driver support for your... -
Page 11: Product Overview
Product Overview These products are wide format LCD desktop touch monitors with optically bonded projected capacitive (PCAP) touch screens. Key Features Size (diagonal): 156DT: 15.6"; 215DT: 21.45”; 238DT: 24” Resolution: 1920 x 1080 Contrast Ratio: 3000:1 Aspect Ratio: 16x9 Brightness: 298 cd/m View Angle: H:178˚, V:178˚... -
Page 12: Package Contents
Package Contents Part Picture LCD Monitor AC power cable IEC C13 (1.8m) AC-DC Converter HDMI cable (1.8m) USB C-C cable (1.8m) USB C-A cable (2m) Cable Cover... -
Page 13: Product Setup And Use
Product Setup and Use Control Buttons I/O Port Locations... -
Page 14: Input/Output Connectors
USB Type-C sources have all the functionality; consult the documentation for your equipment. It is important that the MicroTouch-supplied USB Type-C cable be used when using the single cable option. Multiple-cable options: If a Type-C power source is not available, power is supplied by the included AC-to-DC power converter’s fixed 12 volt DC cable connector. -
Page 15: Turning Monitor On And Off
Turning Monitor On and Off If the monitor does not come on when power is applied, press the power switch (left side of the bottom of the monitor as viewed from the front, see figure above). The monitor should come on within 10 seconds. -
Page 16: On-Screen Display (Osd)
On-Screen Display (OSD) The On-Screen Display, or OSD, button controls on the bottom of the monitor allow the user to make changes to the video. Button Normal display mode When OSD Menu is displayed Power On/Off MENU Activate the main menu Exit Menu / Exit selection ▲... - Page 17 Locking the OSD and Power button functions Lock OSD prevents all the monitor settings from being changed. When this function is activated, all OSD controls and hotkey operations will be disabled except for the Power and RS232 buttons. 1. Press the MENU and Down arrow keys simultaneously; the Lock menu appears, showing OSD “Active”...
- Page 18 Picture Menu This menu is used for making common image adjustments. Contrast Increases or decreases the contrast of the picture. Press or , select the desired level, and then press SELECT. Range: 0-100 Brightness Increases or decreases the brightness of the picture. Press or , select the desired level, and then press SELECT.
- Page 19 Advanced Menu This menu is used to adjust color temperature and image sharpness. Color Temp Select the color temperature Options: 5500K, 6500K, 7500K, 9300K, User Adjust the amount of red in color content Range: 0-100 Green Adjust the amount of green in color content Range: 0-100 Blue Adjust the amount of blue in color content...
- Page 20 OSD Menu This menu is used to make set-up adjustments to the OSD itself, as well as other on-screen messages. OSD Timeout Adjusts the time in seconds before the OSD menu disappears after no usage. Range: 0-60 sec OSD Position Selects the OSD Position (center or corners).
- Page 21 Touch Switch Adjusts the sensitivity of the touch function. Press or to select any of the three sensitivities, then press SELECT. Normal: Standard touch sensitivity, up to 10 simultaneous touch points. Glove: Increases touch sensitivity for use with or without cotton or similar gloves; up to 5 simultaneous touch points.
- Page 22 Option Menu This menu is used select, adjust or display various functions. Reset Restore the factory default settings. Options: Yes, No Language Select the OSD language Options: English, French, Deutsch, Italian, Spanish, Japanese, Traditional Chinese and Simplified Chinese Source Select Select the Video Input Source Options: Auto, USB, HDMI Display Mode...
- Page 23 Volume Set the speaker volume. Range: 0-100 Mute Mute the speakers Factory Enter factory mode This is only for maintenance by service personnel only.
-
Page 24: Osd Default Settings
OSD Default Settings Note: N/A applies when a digital video input (DP or HDMI) is in use Menu Parameter Default Settings Contrast Picture Brightness Color Temp User Advanced Green Blue Sharpness OSD Timeout OSD Positon User OSD H-Positon OSD V-Positon Touch Switch Normal Reset... -
Page 25: Mounting
Mounting The monitor has an integral 100 mm x 100 mm VESA standard mount pattern that conforms to the “VESA Flat Display Mounting Interface Standard” which defines a physical mounting interface and corresponds to the standards for monitor mounting devices. The monitor may be mounted horizontally (output connectors facing down) or vertically (output connectors facing right). -
Page 26: Specifications And Dimensions
Specifications and Dimensions Specifications Model M1-156DT-A1 M1-215DT-A1 M1-238DT-A1 LCD Panel Type TFT LCD Size (Diagonal) 15.6 inch 21.45 inch 23.8 inch Resolution 1920 x 1080 Contrast (typ.) 1500:1 3000:1 4000:1 Brightness (typ.) 425 nits 298 nits 301 nits Response Time (typ.) 16 ms 6.5 ms... - Page 27 Model M1-156DT-A1 M1-215DT-A1 M1-238DT-A1 Mounting VESA Mount Pattern (mm) 100 x 100 Environmental Operating Temperature 0°C ~ 40°C Operating Humidity 35% ~ 85% RH. (non-condensing) Storage Temperature -20°C ~ 60°C Storage Humidity 35% ~ 85% RH. (non-condensing)
-
Page 28: Supported Timings
Supported Timings Polarity Mode Resolution H-Freq. (KHz) Bandwidth (MHz) 720 x 400 @ 70Hz 31.47 28.322 640 x 480 @ 60Hz 31.47 25.175 640 x 480 @ 66Hz 32.24 640 x 480 @ 72Hz 37.86 31.5 640 x 480 @ 75Hz 37.5 31.5 800 x 600 @ 56Hz... -
Page 29: Dimensions
Dimensions M1-156DT-A1 Front Side... - Page 30 M1-215DT-A1 Front Side...
- Page 31 M1-240DT-A1 Front Side...
-
Page 32: Appendix
Appendix Cleaning Turn off the product and disconnect from AC power before cleaning. Turning the product off protects against accidental touch selections that could cause problems or hazardous results. Disconnecting power protects against hazardous interaction between accidental liquid entry and electricity. To clean the case, dampen a clean cloth lightly with water and a mild detergent and wipe gently. -
Page 33: Solutions To Common Problems
Check that the DC power connector is fully seated. Check that the AC cable is securely connected to the wall outlet and to the AC to DC converter. Make sure the MicroTouch power converter is being used. Try another MicroTouch-approved power converter if possible. - Page 34 Neither the OSD nor power buttons respond when pressed. See the Lock/Unlock section to check if both functions are locked. If the wired OSD remote is in use, make sure it is securely connected.
-
Page 35: Warranty Information
Warranty Information Except as otherwise stated herein, or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchscreen display and their components is three years. Seller makes no warranty regarding the model life of components. -
Page 36: Rohs Declaration
RoHS Declaration Type designation (Type) ：M1-156DT-A1 Equipment name：Touch LCD Monitor M1-215DT-A1 M1-238DT-A1 Restricted substances and their chemical symbols Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (PBDE) (PBB) ○ ○ ○ ○ ○ ○... - Page 37 TES AMERICA LLC | 215 Central Avenue, Holland, MI 49423 | (616) 786-5353 The information presented in this document is intended as general information about MicroTouch products and is subject to change. Product specifications and warranties will be governed by TES America, LLC. Standard terms and conditions of sale. Products are subject to availability.
