Quick Connection Diagram
Quick Connection Diagram
ON 1
Switches 1 and 2 UP
Factory Harness
2
(Part # NT-TL10)
NavTool.com | Call: +1-877-628-8665 | Text: +1-646-933-2100
Click
Click
Vehicle's Navigation
System Location
Sedans: Trunk
SUVs: Under Front Seat
Do Not Connect
Behind Radio or
Behind Screen
4
