Lorex SG7610B Quick Setup Manual

4. Camera Specifications

Image Device 1/3" Color CCD
Effective Pixels NTSC:768Hx494(410K)
PAL:752Hx582V(470K)
Scanning System 2:1 interlace
NTSC: 525 Lines
PAL: 625 Lines
Resolution Horizontal 480 TV lines
AES Shutter Speed NTSC: 1/60 ~ 1/100,000
PAL: 1/50 ~ 1/100,000
S/N Ratio More than 48dB (AGC off)
Sync. System Internal
Min. Illumination 1 LUX @F1.2 (no LED)
0 LUX (with LED)
White Balance AWB
Video Output 1.0 Vp-p (75 ohms)
Lens Fixed Lens (3.6mm)
±
Power Supply DC 12V
230mA / 3.0W
Power Consumption
°
Operating Temp 14 F ~ 122°F
°
(-10 ~ 50
FOV (Diagonal) 100 Degrees
Dimensions:
It's all on the web
Product Information
User Manuals
Quick Start Guides
10%
°
C)
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2007 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
H O M E & B U S I N E S S S E C U R I T Y
HIGH RESOLUTION
WEATHERPROOF COLOR CCD
CAMERA WITH NIGHT VISION
Model: SG7610 Series
SG7610B (NTSC)
SG7610BP (PAL)
Refer to online Spec Sheet for specific
Packaging Configurations.
Quick Set-up Guide
