- Page 1 Scion Tech SC08.4100 User Manual HDMI over IP Extender With Looped Output User Manual Version 1.2 www.scion-tech.co.uk sales@scion-tech.co.uk Tel: +44 (0) 1635 862484...
-
Page 2: Table Of Contents
Scion Tech SC08.4100 User Manual Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
Scion Tech SC08.4100 User Manual 1. Introduction HDMI over IP Extender is based on AV over IP solution for distribution of one HD content to one HD display device or to multiple HD display devices over a standard 1G network switcher, and extends distance up to 100m/328ft between encoder and decoder via CAT5e/6 cable. -
Page 4: Specifications
Scion Tech SC08.4100 User Manual 4. Specifications Connectivity Transmitter HDMI Input: 1 x HDMI Type A, 19-Pin Female HDMI Output (Looped): 1 x HDMI Type A, 19-Pin Female CAT5e/6 Output: 1 x RJ45 Data Socket Infra-Red Out: 1 x 3.5mm Jack Socket Power: 1 x 2.1mm DC Jack... -
Page 5: Front Panel Description
Scion Tech SC08.4100 User Manual 5. Front Panel Description CAT5e Out DC/12V Reset IR Out HDMI Out HDMI In Number Name Function / Description HDMI Out Looped HDMI output for connection to a local screen. Connect the HDMI source device using a Premium High Quality HDMI cable to HDMI In achieve the best results. -
Page 6: Application Drawing 1 (One To One Extender)
Scion Tech SC08.4100 User Manual 7. Application Drawing 1 Transmitter and Receiver connected using a CAT5e/6 cable. Satellite Receiver Remote Display Local Display Remote Satellite Receiver HDMI Out HDMI Out HDMI In Reset Reset Decoder / Receiver Encoder / Transmitter... -
Page 7: Application Drawing 2 (One To Many Using 1G Ethernet Switch)
Scion Tech SC08.4100 User Manual 8. Application Drawing 2 Transmitter and Receiver connected using 1G Ethernet Switch. Local Display Satellite Receiver Encoder / Transmitter CAT5e Out IR Out DC/12V HDMI Out HDMI In Reset Remote Display 1 Remote Display 2... -
Page 8: Maintenance And Warranty
Scion Tech SC08.4100 User Manual 9. Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices. Servicing Damage requiring service: This product should be serviced by a qualified service engineer if: ●... - Page 9 Scion Tech SC08.4100 User Manual Limited warranty limits and exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages...
