- Page 1 Scion-Tech Ltd Digital Video Distribution SC07.1016 HDMI over Fibre 4K/60Hz, 4:4:4, HDR User Manual Version: 1.0...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Table Of Contents
CCTV cameras etc. The units are only 20mm in height making them a perfect solution for installing behind any display. The SC07.1016 is supplied as a pair and includes 3-Pin Phoenix connectors and PSU’s, Fibre Transceiver modules sold separately. These units are ideal for home, office and general retail display screens. -
Page 4: Specifications
4. Specifications Transmitter Connectivity HDMI Input: 1 x HDMI Type A, 19-Pin Female Output: 1 x SFP Slot (fibre module not included) RS232: 1 x 3 Pin Phoenix Terminal Power: 1 x DC Jack Receiver Connectivity Input: 1 x SFP Slot (fibre module not included) Output: 1 x HDMI Type A, 19-Pin Female RS232: 1 x 3 Pin Phoenix Terminal Power: 1 x DC Jack... -
Page 5: Panel Description
5. Panel Description Transmitter HDMI Link Power Reset HDMI Input Tx Gnd Rx Update DC/12V Fibre Out 1. HDMI In/Out LED Indicator 6. RS232 2. Link Tx/Rx LED Indicator 7. Upgrade Mini USB 3. Power LED Indicator 8. HDMI Input 4. -
Page 6: Edid
6. EDID (Extended Display Identification Data) 6.1 Automatic EDID The extenders have automatic EDID copying from the display to the source removing the need for settings and providing a seamless connection. 6.2 EDID Reset Press the EDID reset button for 5 seconds using a paper clip or similar pointed device. -
Page 7: Application Drawing
9. Application Drawing 4K/60Hz Display HDMI 4:4:4 Link Power SC07.1016 Receiver HDMI Out Upgrade Power RS232 Fibre In RS232 HDMI Fibre (60Km max) HDMI IN RS232 Camera Upgrade HDMI In Power Fibre Out RS232 SC07.1016 Transmitter HDMI Link Power Reset... -
Page 8: 10. Maintenance
10. Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzine to clean these devices. 10.1 Servicing Damage requiring service: This product should be serviced by a qualified service engineer if: ● The DC power cord or AC adaptor has been damaged. ●... -
Page 9: 10.4. Warranty Limits And Exclusions
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY. This returns policy does not affect your legal rights. Details of your legal rights are available from Trading Standards or Citizens Advice Consumer Service. Scion-Tech Limited Thatcham, Berkshire United Kingdom Tel: +44 (0) 1635 862484 Email: sales@scion-tech.co.uk...
