Modular, all polymeric, automatic Modular, all polymeric, automatic
disc filters with a patented self- disc filters with a patented self-
cleaning backwash mechanism cleaning backwash mechanism Amiad
Mini Sigma is Amiad's latest automatic self-cleaning
plastic filter. This durable, lightweight filter offers maxi-
mum installation flexibility. The filter can be used any-
where in the water system, so filter screens no longer
have to be manually cleaned. Several filters can easily be
placed in parallel, so unlimited capacities are possible.
GENERAL
Amiad's Mini Sigma filter is the latest addition to our
portfolio. It is a small, lightweight plastic filter with a long
service life. The filter is quick and easy to install, simple
to operate, and requires minimal maintenance. The Mini
Sigma filter was developed for use at low pressure, with
a capacity of up to 80 m ³ /h and with 7 filtration degrees
from 50-500 microns. The filter contains a 40-mm (1.5")
flush valve. The low pressure and high contamination
storage capacity means savings in operational costs.
Open field application
Open field, frost mitigation and inline drip system
Open field, frost mitigation and inline drip system
Greenhouse application
Roof cooling
Manual- / service line
Drain water pre-filtration (not in UV installations)
Low pressure humidification
Online drip systems (i.e.. Kameleon) and overhead sprinklers
After day storage tank
Mixing tank rig
Injection rig
Suction rig, UV decontamination
NETHERLANDS
THE FILTRATION PROCESS
Untreated water enters through the coarse filter on
the inlet side, and then passes through the filter screen
from the inside and the clean water coming through the
outside of the screen then leaves the filter housing.
The gradual accumulation of contamination on the
inside of the filter screen creates a filter cake. As the
filter cake grows, so does the pressure difference across
the filter. A differential pressure switch (DP) detects the
differential pressure, and activates the cleaning process
when it reaches a pre-set level (0.5 bar).
OUTDOOR CULTIVATION APPLICATION
Mini Sigma filters can be used in outdoor irrigation as
the main filter for various irrigation systems, such as
spinkler irrigation and drip irrigation.
INDOOR CULTIVATION APPLICATION
For irrigation in greenhouses, Mini Sigma filters can
be used as a second/extra filter after, for example, an
SAF filter or media filter, or after the day tank.
Suction rig
Pump (+ Mixrite)
Mini Sigma
Mini Sigma
Mini Sigma
Mini Sigma
Mini Sigma (only when fertigation rig is equipped with SAF or media filter)
Mini Sigma pre-filtration (filling pump) +
SAF main filter (system pump)
Media filter pre-filtration (filling pump) +
Mini Sigma filter (system pump)
Mini Sigma in combination with sand filter
n/a (SAF filter application)
