Lock & Roll Soft Tonneau Cover
1 / 10
610.701.3336 ext. 3746
404.558.8652 cell
610.701.2402 fax

Advertisement

loading
Need help?

Need help?

Do you have a question about the Lock & Roll Soft Tonneau and is the answer not in the manual?

Questions and answers

Summary of Contents for Tactik Lock & Roll Soft Tonneau

  • Page 1 Lock & Roll Soft Tonneau Cover Lock & Roll Soft Tonneau 1028 Saunders Lane 610.701.3336 ext. 3746 West Chester, PA 19380 404.558.8652 cell 610.701.2402 fax 1 / 10...
  • Page 2 Lock & Roll Soft Tonneau Cover Parts included in the Assembly: Item Description Picture Tonno Tarp, with Front Bar,Rear Bar and Front/Central/Rear Crossbow Left Side Rail Right Side Rail RD Adjustable Setting Knob RG Clamp Assembly Clamp-A is for truck bed without Utility Track System only;...
  • Page 3 Lock & Roll Soft Tonneau Cover Check contents of carton with the list above. Clean truck thoroughly before installation. Step1 Put the Tono Tarp(Item A) on the bed front rail. Item RA Step2 Place the right side-rail (Item RC) and Left side rail (Item RB) on each side of truck bed.
  • Page 4 Lock & Roll Soft Tonneau Cover Step3 Insert the two side rails(Item RB and Item RC) into front bar(Assembled in the Tarp, Item RA). Item RA Item RB Insert Front Bar (item RA) into the 2 Side rails (item RB and RC), and tighten the Knobs (RD).
  • Page 5 Lock & Roll Soft Tonneau Cover Step4 Insert the clamps (Item RG) inside the side rail inner groves. Distribute evenly the clamps on each side of the cover (see picture). Tighten loosely the clamps with the Allen wrench. *For truck with Ultility Track system, please read page 9/10 for side rail installation.
  • Page 6 Lock & Roll Soft Tonneau Cover Step5 Measure the length between the outside of 2 metal Locking Tongues (The metal locking tongue is on each side of Rear Bar), record the length. Step6 Adjust the distance between 2 Side Rails on the truck bed, make sure the distance between the 2 Locking Bases is adjusted to same length as the result of Step 5.
  • Page 7 Lock & Roll Soft Tonneau Cover Step7 Then tighten the Clamps tightly on the side rails with the Allen wrench. Step8 Pull the Tonno Tarp, push down the Rear Bar, close and lock the Rear Bar NOTE: When push down the rear bar, DO NOT push the center of the bar.
  • Page 8 Lock & Roll Soft Tonneau Cover Step10 To open the cover, open the truck bed tailgate, pull the handle in the middle of the cover Rear Bar, unlock the bar, roll up the whole cover to the front of truck bed, then use the buckles to secure the rolled tarp. WARNING-CARE OF THE COVER TARP a) Do not use cleaners for plastic or detergents.
  • Page 9 Lock & Roll Soft Tonneau Cover Attention: For Nissan/Toyota trucks (With Utility Tracks) only Item RG(B)-C Item RG(B)-A The Item RG (Clamp assembly) will become a bracket set as below photo (Item RG(B)- A,B,C). Follow bellow steps to assemble the side rails (RB, RC) on the truck bed: Item RG(B)-B Place the side rail (Item RB&RC) on the truck bed, and insert the clamps...
  • Page 10: Intended Use

    Lock & Roll Soft Tonneau Cover WARNINGS CLEANING READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO FOLLOW Clean with cold water and a cloth. Do use a ALL INSTRUCTIONS LISTED, FAIL TO READ MAY RESULT SERIOUS neutral soap and detergents. Do not expose INJURY.
