Assembly Instructions
Model:
Description:
Part Number:
Assembly Time:
Before you begin, read though these instructions and check that all
parts are present. Please note that MB Quart cannot assume any
responsibility for damage resulting from incorrect installation.
No.
1
Subwoofer
2
MB Quart Grill Emblem
3
Poly Fill Sheets
1
T20 & T30 Torx Driver
2
5mm Allen Wrench
3
Pry Tool
4
Utility Knife
Wrangler (JL)
Jeep Wrangler OEM Subwoofer Upgrade Kit Installation
MBQJL-SUBR-1
60 Minutes (1 Hour)
Parts List
Component Name
Tools Required
Page 1 of 17
Qty
1
1
2
