Summary of Contents for Saf-Fro PRESTOJET 30K
- Page 1 IM3186 10/2022 REV00 PRESTOJET 30K & 45 OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland...
-
Page 2: Table Of Contents
12/05 THANK YOU! For choosing the QUALITY of the Lincoln Electric products. Please check packaging and equipment for damage. Claims for material damaged in shipment must be notified immediately to the dealer. For ease of use, please enter your product identification data in the table below. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Technical Specifications
Technical Specifications NAME INDEX PRESTOJET 30K W100000320 PRESTOJET 45 W100000322 INPUT Input Voltage U Input Power at Rated Output EMC Class Frequency 2,7 kW @ 100% Duty Cycle PRESTOJET 30K 230V±15% 50Hz 3,3 kW @ 60% Duty Cycle 1,6 kW @ 100% Duty Cycle 120V±15%... - Page 4 OTHERS Operating Temperature Storage Temperature PRESTOJET 30K from -10 °C to +40 °C from -25 °C to 55°C PRESTOJET 45 from -10 °C to +40 °C from -25 °C to 55°C Protection Rating PRESTOJET 30K IP23S PRESTOJET 45 English English...
-
Page 5: Eco Design Information
Efficiency and idle power consumption: Efficiency when max power Index Name Equivalent model consumption / Idle power consumption W100000320 PRESTOJET 30K 83,7% / 58W No equivalent model W100000322 PRESTOJET 45 83,7% / 58W No equivalent model Idle state occurs under the condition specified in below table... - Page 6 Typical gas usage for MIG/MAG equipment: DC electrode positive Wire Wire Feeding Gas flow Material type diameter Shielding Gas Current Voltage [m/min] [l/min] [mm] Carbon, low 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO alloy steel Aluminium 0,8 ÷...
-
Page 7: Electromagnetic Compatibility (Emc)
Electromagnetic Compatibility (EMC) 01/11 This machine has been designed in accordance with all relevant directives and standards. However, it may still generate electromagnetic disturbances that can affect other systems like telecommunications (telephone, radio, and television) or other safety systems. These disturbances can cause safety problems in the affected systems. Read and understand this section to eliminate or reduce the amount of electromagnetic disturbance generated by this machine. -
Page 8: Safety
Safety 01/11 WARNING This equipment have to be used by qualified personnel. Be sure that all installation, operation, maintenance and repair procedures are performed only by qualified person. Read and understand this manual before operating this equipment. Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or equipment damage. Read and understand the following explanations of the warning symbols. - Page 9 Cutting sparks can cause explosion or fire. Keep flammables away from cutting. Do not cut or gouge near flammables. Have a fire extinguisher nearby, and have a watch person ready to use it. Do not cut on drums or any closed container.
-
Page 10: Introduction
Normal operation may adversely affect the PRESTOJET 30K & 45 must be connected to a correctly operation of nearby radio controlled machinery, which installed plug-in socket with an earth pin. Input voltage is: may result in injury or equipment damage. - Page 11 1. User Interface PRESTOJET 30K: See User Interface Controls and Operational Features PRESTOJET 30K chapter. Front panel PRESTOJET 30K 2. User Interface PRESTOJET 45 : See User Interface PRESTOJET 45 chapter. 3. Work Lead Connector. 4. Compressor Internal Air Filter: (PRESTOJET 30K only).
- Page 12 User Interface PRESTOJET 30K User Interface PRESTOJET 45 Figure 5 Figure 4 18. Home Button: Allows the user to return to 9. LED Indicator Power Switch: Lights up when the main view. the equipment is ON and connect to the power supply.
- Page 13 PRESTOJET 30K Gouging CUTTING CURRENT PILOT PILOT PREFLOW POSTFLOW Figure 9 Table 2. PRESTOJET 30K – Preflow/Postflow Preflow Current Postflow 15-30 A 15 s Figure 8 27. Selected grid process: To select a process, use the Active Button Control [19].
- Page 14 PRESTOJET 45 – cut PRESTOJET 45 – gouging After pressing the button in the torch: After pressing the button in the torch: Preflow – purge flow before ignition of the pilot current Preflow – purge flow before ignition of the pilot current –...
- Page 15 PRESTOJET 45 enables be cut, grid and gouging. Preparing the equipment PRESTOJET 45 does not include the accessories for gauging, but the one can be purchased separately (see PRESTOJET 30K enables the cutting and grid process. "Accessories" chapter). WARNING WARNING...
- Page 16 Geometrical shape of the cut (whether straight or curved). Table 4. Cutting Speed PRESTOJET 30K PRESTOJET 30K Speed (cm/min.) Material Thickness (mm) Current(A)
- Page 17 ERRORS Table 6 Errors for PRESTOJET 30K Error code Symptoms Cause Recommended Course of Action Check for air pressure are correct. Check and correct condition of fan. turn off the equipment for at least 10 Air flow is blocked.
- Page 18 Please refer case and from the cabinet inside. to www.saf-fro.com for any updated information. If it is required, clean and tighten plasma torch connector and work lead socket.
-
Page 19: Weee
WEEE 07/06 Do not dispose of electrical equipment together with normal waste! In observance of European Directive 2012/19/EC on Waste Electrical and Electronic Equipment (WEEE) and its implementation in accordance with national law, electrical equipment that has reached the end of its life must be collected separately and returned to an environmentally compatible recycling facility. -
Page 20: Accessories
Accessories PRESTOJET 30K W100000325 TORCH LC-30 4M CEN. 5PIN LE W100000355 GROUND CABLE 16MM 6M W0300699A CUTTING CIRCLE W0200002 TWO-WHEELED UNDERCARRIAGE W8800117R FILTER CARTRIDGE PRESTOJET 45 W100000327 TORCH LC-45 6M CEN. 5PIN LE W100000355 GROUND CABLE 16MM 6M W100000338 CUTTING CIRCLE... -
Page 21: Connection Configuration
Connection configuration English English...
