MODEL IDENTIFICATION

TD3 __ __ __ - __ __
COMMAND SET
0 = LOGIC CONTROLS*
1 = LOGIC CONTROLS
WITH PASS-THRU
2 = SPECIAL COMMAND SET 1 (Aedex emulation)
3 = SEPCIAL COMMAND SET 2 (Noritaki emulation)
4 = SPECIAL COMMAND SET 3 (Epson D202 emulation)
5 = SPECIAL COMMAND SET 4 (Ultimate PD1100XL/XLT)
9 = OPOS COMMAND SET
* Default Values
** Call for description of Command Sets

CARTON CONTENTS

1. Table display, pre-assembled.
2. Interface cable, comes with a DB9F connector (to computer) and
an RJ11 connector (to table display) as standard equipment.
Optional DB25F connector (to computer) is available.
Note: This cable is only supplied with standard serial table
displays with no pass-thru function.
3. Transformer adapter 120VAC to 6.0VAC (optional 220VAC).
4. Quick Installation Guide.
Blank = No Pass Thru
PT = Pass Thru
25 = DB25F connector to computer
POWER ADAPTER
0 = 120VAC*
1 = 220VAC
SERIAL/PARALLEL INTERFACE
0 = SERIAL 9600 BAUD*
1 = SERIAL 600 BAUD
2 = SERIAL 1200 BAUD
3 = SERIAL 2400 BAUD
4 = SERIAL 4800 BAUD
5 = SERIAL 19200 BAUD
